- Page 1 Pilot’s Operating Handbook Wing Type : iFun XL 615 Route de l’Aérodrome, 07200 Lanas, France Telephone: +33 (0)4 75 93 66 66 • Fax: +33 (0)4 75 35 04 03 • info@aircreation.fr http://www.aircreation.fr GDMUiFXL-evo-1G Version 0010...
-
Page 2: Table Of Contents
General ................... 4 About this Document ................4 3-Perspective Diagram ................. 5 Figure 3-1: iFun XL in 3 Perspectives ..................5 Technical Specifications – Performance ......6 Technical Specifications............... 6 Maximum Added Load / Trikes Adjustment ......... 7 Performance at Maximum Take-Off Weight ......... 8 Instructions for Use ............... -
Page 3: Amendment Record Sheet
Amendment Record Sheet Table of Amendments Review Date Comment Section 0010 09-2021 Reference document Amendments The information in this manual is based on the data that was available at the time of its publication. The latest amendments to this manual will be issued on the Air Création website (http://www.aircreation.fr) in PDF format. -
Page 4: General
General About this Document This manual is a legal document which is approved for use with Air Creation iFun XL wing. It must be used in conjunction with the particular trike’s operating handbook. It must remain with the aircraft, and not be amended or altered without authority from Air Creation. -
Page 5: 3-Perspective Diagram
3-Perspective Diagram Figure 3-1: iFun XL in 3 Perspectives GDMUiFXL-evo-1G Version 0010... -
Page 6: Technical Specifications - Performance
Technical Specifications – Performance Technical Specifications Area 18.5 sq m (199.1 sq ft) Maximum wing loading kg/sq.m. (5.3 lbs/sq.ft.) 25,7 Airfoil type Double surface 30% Span 9.5 m (31.2 ft) Nose angle 120° Aspect ratio Empty weight 49 kg (108 lbs) Ultimate load factors + 6g - 3g Maximum take-off... -
Page 7: Maximum Added Load / Trikes Adjustment
Maximum Added Load / Trikes Adjustment The maximum load that may be added under the wing is 426 kg (939 lbs). The following chart defines the useful load of our various trike models with the iFun XL wing. Trike Skypper evo... -
Page 8: Performance At Maximum Take-Off Weight
Performance at Maximum Take-Off Weight The indicated speeds are CAS corrected speeds. (*) The indicated performances were measured with the standard propellers that equip the trikes. The performances obtained with the optional propellers proposed are at least equivalent. Skypper evo Skypper evo TANARG neo TANARG neo... -
Page 9: Instructions For Use
Instructions for Use Rigging 5.1.1 Assembly Open the wing bag, make sure that the A-frame is on top, and remove fastenings and paddings. At this point, do not assemble the trapeze with the control bar to avoid the risk of damaging the sail with the upright profile! Lift the wing from the front and rotate it so that the wing is laying with the folded control frame flat on the ground. -
Page 10: Disassembly
Pull the cross tube swan catch tensioner towards the trailing edge, then hook it to the rail screw at the keel tip (Figure 5-2). To ease the operation, carefully center the A-frame, ensure that the tabs and heat shrink coverings of the lower lateral cables do not get stuck in the sail opening at the cross tube/leading edge connection and that the stainless steel tabs line up with the control bar. -
Page 11: Preflight Check
Preflight Check The wing preflight check will be easier if made before lifting the wing above the trike. The following is a brief summary of the minimum pre-flight inspection, which assumes that the scheduled maintenance checks outlined in the maintenance manual has been performed. If you are unsure, it does no harm to increase the number of items in your inspection in accordance with the recommendations of the maintenance manual. -
Page 12: Flight Specifications
Flight Specifications 5.3.1 Operational Limitations Warning: This wing is not designed for aerobatics. It is imperative to respect the flight envelope ! Maximum Pitch attitudes 30° nose up, 30° nose down Maximum Bank angle 60° Aerobatics and deliberate spinning prohibited ... -
Page 13: Flight Techniques
5.3.3 Flight Techniques Taxiing: Avoid turning sharply as this generates large amounts of torque and hence wear, transmitted to the pylon, hang point and keel. Always try to keep the wing aligned with the trike when turning by bracing the control bar. Turning circle is very small, but beware –... - Page 14 and low cruise speed adjustment, it may be necessary to increase the speed before the wing is put into banking to avoid stalling the lower wing. An increase in engine power is also advised to maintain the flight level during the turn. talling: The stalling point is reached more easily with a backward hang point position.
- Page 15 Ground-runs Keep the sail flat into a headwind. Push the control bar against the trike front strut with a tailwind. This will avoid flipping. With a side wind, be careful to always tilt the wing so that the windward edge is slightly lower than the rest of the wing. It may be difficult to hold the A-frame in its position.
- Page 16 Flight in Turbulence: Compared to other flexwing microlights, the iFun XL handles turbulence very well. However in common with all microlight aircraft, care must be taken in turbulent conditions, particularly when close to the ground. As previously stated high airspeed will enhance maneuverability in these situations.
-
Page 17: Appendix
Appendix Wing – Quality Form Anxious to ensure the perfection of our products, we have set up a sequence of controls covering all steps of production. We are continuously working on their improvement and we are in need of your help. Please return this reply form accurately filled in if you find any issues or problems concerning your trike that could affect its quality or finish, even if it is a minor matter. - Page 18 615 Route de l’Aérodrome, 07200 Lanas, France Phone: +33 (0)4 75 93 66 66 • Fax: +33 (0)4 75 35 04 03 • info@aircreation.fr http://www.aircreation.fr GDMUiFXL-evo-1G Version 0010...
