Chart 2-6 Continued
ALARM AND TRANSFER WIRING (P10) INSTALLATION
STEP PROCEDURE
• Terminate the black wire associated with the white wire and designate as XPE.
• Terminate the black wire associated with the red wire and designate as CPE.
• Store the braided wire (connected only in the cabinet to suppress EMI).
5 Terminate and designate cable 2 (if provided) at the cross connect terminal as follows
(Fig. 2-11):
• Terminate the black wire associated with the red wire and designate as REM A.
• Terminate the black wire associated with the white wire and designate as REM B.
• Terminate the red wire and designate as MJ.
• Store the remaining white wire (not used) and the braided wire (connected only in
the cabinet to suppress EMI).
6 Connect cable 1 (if provided) to the terminals on TB2 at the rear of the QUX19 unit in
the cabinet as follows:
• red wire to terminal 5 (AUX) on TB2.
• white wire to terminal 4
• black wire associated with the white wire to terminal 8 (XPE).
• black wire associated with the red wire to terminal 9 (XCE).
• braided bare wire to terminal 4.
7 Connect cable 2 (if provided) to terminals on TB2 at the rear of the QUX19 unit as
follows:
• black wire associated with the red wire to terminal 6 (REMA).
• black wire associated with the white wire to terminal 7 (REMB).
• red wire to terminal 10 (MJ).
• braided bare wire to terminal 4.
• store the white wire (not used).
8 If required, reinstall EMI shield and cabinet cover.
