INSTALLATION MANUAL
Mounting Overview
The BPRZR2S is designed specifically for the Polaris RZR. Bluetooth audio receiver BPS1RS is designed for
the rocker switch locations on the RZR dash. The RZR-FSA front internally amplified speaker pods are specific
to the Polaris RZR footwell.
BPS1RS Bluetooth
audio receiver
RZR-FSA left and right
amplified speaker pods
Disassembly
Some disassembly of the dash is required for the BPRZR2S installation.
1.
Disconnect the negative battery cable. The battery can be accessed by removing the driver seat in two seat
vehicles and left rear seat in four seat vehicles.
2.
Remove the hood by disengaging the twist locks on it. Then the bus bar under the hood can be accessed
for power connection to the BPS1RS and the RZR-FSA.
IPX6 RATED 200 WATTS TRUE PLUG-N-PLAY
POLARIS RZR TWO SPEAKER AUDIO SYSTEM
- 4 -
BPRZR2S
Bus bar
