Assembly (Dining Chairs)
1
Attaching armrests to the back panel
□ Attach the armrests (A) and (B) to the back panel (D) with washers (BB) and bolts (CC) using the hex wrench (DD).
Do not fully tighten bolts until the end of step 2.
□
□
Use another two washers (BB) and bolts (CC) to secure the armrests
Do not fully tighten bolts until the end of step 2.
CC
BB
DD
A
2
Attaching the seat panel
□ Attach the seat panel (C) to the tabs (2) of the armrests (A) and (B)
with washers (BB) and bolts (CC) using hex wrench (DD).
□
Note that the leg rest tube (1) is curved and shall stay in front.
Fully tighten all bolts (CC) when all bolts are in place.
B
A
1
C
th surface.
to the back panel using the hex wrench (DD).
D
B
3
□
□
□
AA
2
AA
5
Turning over the chair
Cover all bolts with bolts caps (AA).
Turn the chair upright.
Repeat st eps 1 through 3 for the other chairs.
Please contact 1-800-245-2217 for further assistance.
