Pre-Assembly; Planning Assembly; Hardware Included - Home Decorators Collection Gabriel 151-100-7D Use And Care Manual

Pre-Assembly

PLANNING ASSEMBLY

It will take two people about 45 minutes to complete the assembly process.

HARDWARE INCLUDED

NOTE: Hardware not shown to actual size.
AA
EE
II
MM
Part Description
AA
Bolt cap (M6)
BB
Washer (M6)
CC Bolt (M6x18)
Hex wrench
DD
BB
FF
JJ
Quantity
Part
32
EE
32
FF
32
GG
1
HH
II
JJ
KK
LL
MM
3
CC
GG
KK
Description
Washer plate
Washer
Lock washer
Nut
Bolt (M8x42)
Bolt (M8x35)
Nut cap
Bolt cap
Spanner
Please contact 1-800-245-2217 for further assistance.
DD
HH
LL
Quantity
6
8
8
8
4
4
16
16
2
