- Page 1 BG-UHD-44M 4X4 4K 60Hz HDR HDMI Matrix Switcher with Auto Downscaling and RS-232/IP/Cloud User Manual...
- Page 2 BZBGEAR BG-UHD-44M PRODUCT MANUAL · · Address: 830 National Drive #140, Sacramento, CA 95834, USA Tel: +1(888)499-9906 Email: support@bzbgear.com...
-
Page 3: Table Of Contents
BZBGEAR BG-UHD-44M PRODUCT MANUAL TABLE OF CONTENTS Statement Safety Precaution Introduction Features Packing List Specifications Operation Controls and Functions Remote Control Application Diagram RS-232 Pin Assignment RS232 and Telnet Commands GUI Control Tech Support Warranty Mission Statement Copyright · ·... -
Page 4: Statement
● This product does not contain parts that can be maintained or repaired by users. Damage caused by dismantling the product without authorization from BZBGEAR is not covered under the warranty policy. ● Installation and use of this product must strictly comply with local electrical safety standards. -
Page 5: Introduction
PRODUCT MANUAL Introduction The BG-UHD-44M is a 4x4 HDMI matrix switch, supporting resolutions up to 4K@60Hz 4:4:4. Equipped with 4 HDMI 2.0a inputs and 4 HDMI 2.0a outputs, this unit offers 18Gbps uncompressed bandwidth on all HDMI ports. Additionally, the auto-scaling feature provides the ability to downscale from 4K to 1080P, ensuring that multiple displays are supported. -
Page 6: Specifications
BZBGEAR BG-UHD-44M PRODUCT MANUAL Specifications Signal HDMI Compliance HDMI 2.0 HDCP Compliance HDCP 2.2 and HDCP 1.x Video Resolutions 18Gbps (4K@60Hz 4:4:4 8bit) HDMI Cable Distance 1.5 meters for 4K@60Hz 4:4:4 (HDMI 2.0 certified cable) RS232 Baud Rate 57600 IR Carrier Frequency... -
Page 7: Operation Controls And Functions
BZBGEAR BG-UHD-44M PRODUCT MANUAL Operation Controls and Functions Front Panel Name Power switch - Power on/off the matrix. Input LED indicator 1 to 4 - Lit when the corresponding input is selected. Output selection button 1 to 4 - Press to select the input source from 1 to 4. -
Page 8: Remote Control
BZBGEAR BG-UHD-44M PRODUCT MANUAL Remote Control Output and Input select 1. Change Output source: a. Press OUTPUT-# b. Press INPUT-# 2. All outputs select same input: a. Press ALL button OUTPUT b. Press INPUT-# 3. Pass Through: a. Press PTP button in Zone OUTPUT EDID Set Up 1. -
Page 9: Application Diagram
BZBGEAR BG-UHD-44M PRODUCT MANUAL Application Diagram RS-232 Pin Assignment BG-UHD-44M (DCE) Remote Control Console (DTE) Assignment Assignment Baud Rate: 57600 bps Data Bit: 8-bit Parity: None Stop Bit: 1-bit Flow Control: None NOTE: Use Straight Through DB9 Cable to connect the matrix to a computer, DO NOT use a Crossover Cable (Null Modem Cable). -
Page 10: Rs232 And Telnet Commands
BZBGEAR BG-UHD-44M PRODUCT MANUAL RS232 and Telnet Commands Command Action Print Help Information HELP Print Help Information STATUS Print System Status And Port Status Power On, System Run On Normal State POFF Power Off, System Run On Power Save State IR ON/OFF Set System IR Control On Or Off... -
Page 11: Gui Control
BZBGEAR BG-UHD-44M PRODUCT MANUAL GUI Control System Requirements Microsoft Windows 1. Power ON/ Standby mode 2. Control SW via RS-232 3. Control SW via Network 4. COM Port Selection 5. I/O Routing Tab 6. EDID Tab 7. Rename I/O Tab 8. - Page 12 BZBGEAR BG-UHD-44M PRODUCT MANUAL “Mapping” Page On this page you can change the HDMI mapping of the matrix. I/O Mapping 1. Choose which output you would like to modify. 2. Select an Input# from the dropdown menu. 3. Select an Input# in All Outputs to change all outputs to display the selected input source.
- Page 13 BZBGEAR BG-UHD-44M PRODUCT MANUAL EDID On this screen you can modify the EDID settings for the matrix. Learn EDID 1. Use either the “From Default,” “From Display,” or select a “File Name” to choose a default resolution, information from a connected display or a previously save/created EDID bin file.
- Page 14 BZBGEAR BG-UHD-44M PRODUCT MANUAL Rename On this screen you can modify the display names of the Inputs, Outputs, and Preset Mappings up to a total of 7 characters. 1. Type in the desired name in the box whose name you would like to modify.
- Page 15 BZBGEAR BG-UHD-44M PRODUCT MANUAL System On this page you can modify Network settings, view Cloud information, check firmware version, and factory reset the unit. Network 1. Select the DHCP radial to have the network/router assign an IP address from your network.
- Page 16 BZBGEAR BG-UHD-44M PRODUCT MANUAL Cloud Setting The first time to use the Eagleyes service, please create a new account. 1. Access Eagleyes (http://www.eagleyes.io) and click “Create new account”. 2. The Registration page will pop up and please fill in your email and password information to create your private account.
- Page 17 BZBGEAR BG-UHD-44M PRODUCT MANUAL Add Device to Eagleyes 1. First, please make sure the device is connected to the Ethernet. Then please execute the software with device to get the association code 2. Access Eagleyes (http://www.eagleyes.io) or download Eagleyes APP, and then log in your account on the right top corner.
- Page 18 BZBGEAR BG-UHD-44M PRODUCT MANUAL 3. Enter the Installer Email for online support in the future, and the Association Code for pairing with your device. 4. After adding the device, the list of devices related to your account will show on the right top corner.
- Page 19 BZBGEAR BG-UHD-44M PRODUCT MANUAL Firmware Use this page to update the device firmware. Firmware Update-Main Board ● Click “Main Board” button and another window will pop-up ● Click “File” button to load firmware ● Click “Start” button to do firmware update ●...
- Page 20 BZBGEAR BG-UHD-44M PRODUCT MANUAL Firmware Update-Input ● Click “Input” button and another window will pop-up ● Click “FILE” button to load firmware ● Click “Start” button to do firmware update ● Please power cycle after firmware update complete Firmware Update-Output ●...
-
Page 21: Tech Support
Tech Support Have technical questions? We may have answered them already! Please visit BZBGEAR’s support page (bzbgear.com/support) for helpful information and tips regarding our products. Here you will find our Knowledge Base (bzbgear.com/knowledge-base) with detailed tutorials, quick start guides, and step-by-step troubleshooting instructions. -
Page 22: Warranty
BZBGEAR BG-UHD-44M PRODUCT MANUAL Warranty BZBGEAR Pro AV products and cameras come with a three-year warranty. An extended two-year warranty is available for our cameras upon registration for a total of five years. For complete warranty information, please visit bzbgear.com/warranty. -
Page 23: Mission Statement
AVoIP, professional broadcasting, conferencing, home theater, to live streaming solutions. We pride ourselves on unparalleled customer support and services. Our team offers system design consultation, and highly reviewed technical support for all the products in our catalog. BZBGEAR delivers quality products designed with users in mind. ·... -
Page 24: Copyright
PRODUCT MANUAL Copyright All the contents in this manual and its copyright are owned by BZBGEAR. No one is allowed to imitate, copy, or translate this manual without BZBGEAR’s permission. This manual contains no guarantee, standpoint expression or other implies in any form. Product specification and information in this manual is for reference only and subject to change...
