- Page 1 BG-UHD-88M 8x8 HDMI 2.0a Matrix with Audio Extractor & ARC User Manual Contact 1.888.499.9906 | support@bzbgear.com | bzbgear.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ......................... 1 FEATURES .......................... 1 PACKAGE CONTENTS ....................... 1 SPECIFICATIONS ....................... 2 PANEL DESCRIPTIONS ..................... 3 CONNECTION DIAGRAM ....................4 HARDWARE INSTALLATION ....................4 OPERATION APPROACH ....................5 EDID LEARNING ........................18 FAQ ............................19 NOTICE ..........................20 TECH SUPPORT........................20 WARRANTY ........................21 MISSION STATEMENT ......................21... -
Page 3: Introduction
RS-232, Web Interface, Control 4, IP control and cloud control Easy installation with rack-mounting Fast response time – 3~4 seconds for channel switch PACKAGE CONTENTS 1x BG-UHD-88M 1x Rack-mounting ear set 1x IR receiver 1x Installation software CD ... -
Page 4: Specifications
SPECIFICATIONS BG-UHD-88M Model Name Technical Role of usage True 8x8 matrix HDMI compliance HDMI 2.0a HDCP compliance HDCP1.4/HDCP 2.2 Video bandwidth Single-link 594MHz [18Gbps] Video support HDR 4K2K@60(4:2:0 10bits) / 4K2K@60 (4:4:4 8bits) Audio support Surround sound (up to 7.1ch) or stereo digital audio ESD protection Human body model —... -
Page 5: Panel Descriptions
PANEL DESCRIPTIONS 1. Source Status: Input source detection LED 2. Display Status: Output display detection LED 3. IR SENSOR: IR sensor for receiving the IR commands from IR remote 4. Output Push Button & 7-segment LED: Front panel push buttons used to select the number of display channel &... -
Page 6: Connection Diagram
BG-UHD-88M as master 1. Connect all sources to HDMI Inputs on the 8x8 HDMI BG-UHD-88M. 2. Connect all displays to HDMI Outputs on the 8x8 HDMI Matrix BG-UHD-88M. 3. Connect the +12V 7.5A DC power supply to the 8x8 HDMI Matrix BG-UHD-88M... -
Page 7: Operation Approach
OPERATION APPROACH Method A: Push-in Button IN/OUT MAP Use the “+”or “-“ output push button to select the number of display (2) Use the “+”or “-“ input push button to select the number of input source “+”: change selected input/output port in ascending order “-”... - Page 8 IN/OUT Switch 7-Segment LED Operation Procedure IN/OUT Switch Output Number (1~8) + Input Number (1~8) 1.Press output number key “3” to select Output 3 Ex: Input 2 2.Press input number key “2” to select Input 2 To Output 3 3.Press “TAKE” button...
- Page 9 Example of function key Operation Procedure 7-Segment LED Output Status Status + Output Number (1~8) + Take 1.Press “STATUS” button Ex: Output 4 2.Press output number key “4” to select Output 4 (Input 2) 3.Press “TAKE” button Save Current Save + Output Number (1-8 storage site) + Take Mapping 1.Press “SAVE”...
- Page 10 Method C: Software Control through RS-232 port 1. System Requirement (1) OS Information: MS Win XP/7/8.1/10 (2) Baud rates: 115200 (3) Software size: 2 MB (4) Minimum RAM requirement: 256 MB Power ON/ Standby mode I/O Routing Tab Control SW via RS-232 EDID Tab Control SW via Network Rename I/O Tab...
- Page 11 1. I/O Routing Button I/O: Switch the input for each output ARC: Enable/ Disable ARC Recall Mapping: Select the stored Mapping (1-16) Click “Recall” button to recall previous mapping which are saved Save Mapping: ...
- Page 12 2. EDID Button Learn EDID from Default to Input Select Default EDID(1-17 Default EDID) Select designated Input Click “Apply” button to learn from default EDID Learn EDID from Display to Input Select output Select designated Input ...
- Page 13 3. Rename I/O Button Rename I/O: Rename the Inputs Rename the Outputs Rename Mapping: Rename the Mappings -11-...
- Page 14 4. System Button Network-DHCP mode After selecting DHCP, device will reboot automatically Click “Read” button to automatically get the IP address Information Network-Static mode After selecting static, device will reboot automatically Key in the “IP”, “MASK”, “GATEWAY” information. ...
- Page 15 Cloud setting-Association Code To get an “association code”. The device can use this code to pair with cloud server. Cloud setting-Reset Cloud To reset cloud after a successful pairing Cloud setting-MAC Read the device’s MAC address information ...
- Page 16 Firmware Update-Input Click “Input” button and another window will pop-up Click “FILE” button to load firmware Click “Start” button to do firmware update Please power cycle after firmware update complete Firmware Update-Output Click “Output” button and another window will pop-up ...
- Page 17 Method D: Cloud Control (Eagleyes) through Ethernet port Create Account The first time to use the Eagleyes service, please create a new account. 1. Access Eagleyes (http://www.eagleyes.io) and click “Create new account”. 2. The Registration page will pop up and please fill in your email and password information to create your private account.
- Page 18 Add Device to Eagleyes 1. Firstly, please make sure the device is connected to the Ethernet. Then please executing the software with device to get the association code (Note: the status of software is connected). 2. Access Eagleyes (http://www.eagleyes.io) or download Eagleyes APP, and then log in your account on the right top corner.
- Page 19 Method E: Web Interface Control The default IP address: 192.168.1.70 -17-...
-
Page 20: Edid Learning
EDID LEARNING The EDID learning function is only necessary whenever you encounter any display on the HDMI output port that cannot play audio and video properly. Because the HDMI source devices and displays may have various level of capability in playing audio and video, the general principle is that the source device will output the lowest standards in audio format and video resolutions to be commonly acceptable among all HDMI displays. -
Page 21: Faq
Q Can every TV work with the HDMI matrix? A Basically, the answer is YES. But if your TV cannot support 1080p, please refer the EDID LEARNING section to learn EDID from your TV. Q What is EDID? Why do I need to learn EDID? A EDID contains the whole information of the display such as the resolution and audio setting which this display can support. -
Page 22: Notice
8. Solid cable is preferred. TECH SUPPORT Before contacting tech support, we may have answered your question already! Visit our BZBGEAR support page (bzbgear.com/support) for valuable information on our products. Here you will find our Knowledge Base (bzbgear.com/knowledge-base) consisting of tutorials, quick start guides, and step-by-step troubleshooting instructions. -
Page 23: Warranty
Our team offers system design consultation and expert tech support seven days a week for all BZBGEAR products. Our unparalleled support is our way of showing we care for every one of our customers. Whether you’re an integrator, home theater enthusiast, or a do-it- yourselfer, BZBGEAR offers solutions allowing you to focus on your project and not your budget.
