SERVICE MANUAL
Ver 1.0 2003.02
SPK-DVF5
SPECIFICATIONS
Material
Plastic (PC, ABS), glass
Waterproof
Waterproof gasket, buckles
Bult-in microphone
Stereo
Dimension
Approx. 169 × 174 × 261 mm (w/h/d)
× 6
× 10
3
7
3
(6
/
/
/
inches)
4
8
8
Mass
Approx. 990 g (2 lb 3 oz) (only sports
pack)
Supplied accessories
Shoulder strap (1)
Camera mounting shoe (2)
Tripod screw plate (1, pre-installed on the
camera mounting shoe)
Reflex prevention ring Large (1), Small (1)
Grease (1)
Anti-fogging lens solution (1)
Operating Instructions (1)
Design and specifications subject to change
without notice.
AEP Model
SPORTS PACK
