Step 2 - Mattress Support - Foundations SERENITY COMPACT STATIONARYSIDE CRIB Assembly Instructions

STEP 1 - STATIONARY SIDE ASSEMBLY
IMPORTANT SAFETY NOTICE: When assembling the crib, labels on the End Panels
MUST face toward the inside of the crib. If crib is assembled incorrectly, it could create an
entrapment hazard between the mattress and end panels.
1. Remove Barrel Nut (H) from M6 x 60mm Machine Screw (G).
2. Insert plain end of Barrel Nut (H) into the hole located at one end of Stationary Side
Top Rail.
3. Standing outside crib, position the Stationary Side (A) with the barrel nut holes to the
inside of crib and plastic teething protector at top.
4. Insert one M6 x 60mm Machine Screw (G) through hole near top of End Panel, into the
hole in the end of the Stationary Side and into the barrel nut. (If necessary, turn the
barrel nut to align the barrel nut with the screw by using a screwdriver in the end slots of
the barrel nut.) Turn the machine screw into the barrel nut.
5. Repeat at opposite end of Stationary Side to secure to other End Panel.
6. Repeat steps 1. through 5. above to attach the bottom rail of the Stationary Side to the
End Panels (B).
7. Repeat steps 1. through 6. above for the second Stationary Side.
8. Securely tighten all screws on Stationary Side using Hex Wrench (L).

STEP 2 - MATTRESS SUPPORT

1. Determine which mattress height will be used in the crib.
Note: If child is able to pull to standing position, set mattress to lowest position.
2 While standing at the stationary side rail, place the hook bracket on the opposite side of
Mattress Support (C) over lower rails of Stationary Side.
Note: Hook brackets and instruction label on Mattress Support MUST be toward
opposite side as shown.
3. Swing Mattress Support down until hook brackets contact the lower tracks for the
opposite stationary side.
4. Standing on one side, lift Mattress Support vertically to desired height position, insert
Connector Bolt (E) in End Panel, and secure with Connector Nut (F).
5. Walk around the crib to the opposite side and repeat step 4.
6. Securely tighten all Connector Bolts and Connector Nuts.
Note: When using crib with evacuation frame, mattress support must be in lowest
position.
S 1
TEP
•
P 1
ASO
H.
G.
C.
E.
S 2
F.
TEP
•
P
ASO
Hook Bracket
Soporte de
gancho
2
Sheet 2 of 5
