- Page 1 DAIKIN INSTALLATION MANUAL OPERATION MANUAL CEILING CONCEALED SPLIT TYPE AIR-CONDITIONER FDKR200AV16 FDKR300AV16 FDKR400AV16 3P724053-2...
-
Page 2: Table Of Contents
DAIKIN Ceiling Concealed Split Type Air Conditioner Installation Manual & Operation Manual CONTENTS Installation Manual ........................02-16 Safety Precautions ........................02 Installation of the Indoor Unit....................03 Installation of the Outdoor Unit.................... 04-05 Outline and Dimensions ...................... 06-08 Refrigerant Piping ....................... -
Page 3: Installation Manual
INSTALLATION MANUAL This manual provides the procedures of installation to ensure a safe and good standard of operation tor the air conditioner unit. Special adjustment may be necessary to suit local requirements. Before using your air conditioner, please read this instruction manual carefully and keep it for future reference. -
Page 4: Installation Of The Indoor Unit
Drain trap Do not leave in water 2. INSTALLATION OF THE INDOOR UNIT Mounting Ensure that the overhead supports are strong enough to Provide clearance for servicing and optimal air flow as shown in the diagram. hold the unit's weight. Position hanger rods and check for alignment with the unit. -
Page 5: Installation Of The Outdoor Unit
3. INSTALLATION OF THE OUTDOOR UNIT Location For Installation Install the outdoor unit in such way that air distributed by the outdoor unit cannot be drawn in again (as in the case of short cycling of discharge air). Allow sufficient space for maintenance around the unit. Select the coolest possible place where intake air should not be higher than the outside temperature (maximum °... - Page 6 INSTALLATION CLEARANCE When two or more outdoor units are installed in a location, they must be positioned such that one unit will not be taking the hot discharge air from another to avoid hot air short cycling.This also applies when two or more units are installed one above the other.
-
Page 7: Outline And Dimensions
4. OUTLINE AND DIMENSIONS Indoor Unit FDKR200AV16 1270 All dimensions are in mm 152 16 3 _ 7 _ 8 �. ,..+ -- 3 - 3 � � ---�. _ 4_ 6 _ 2 �. ----i =i=t �co�-�� � •... - Page 8 Indoor Unit FDKR400AV16 1804 1647 All dimensions are in mm 1211 �· · � M CC � � 14 HOLE r/;7...
- Page 9 Outdoor Unit RZR200AY16 Horizontal Air Discharge All dimensions are in mm 1060 1100 Outdoor Unit RZR300AY16 Horizontal Air Discharge All dimensions are in mm 0::, 1236 1200 O"' N<Xl '° 1276 ;:,!: Outdoor Unit RZR400AY16 Horizontal Air Discharge All dimensions are in mm r-...
-
Page 10: Refrigerant Piping
Q E OUTDOOR UNIT � o ::,;C\I ..I Field Connection pipe size detail Indoor Liquid Pipe Gas Pipe Outdoor Liquid Pipe Gas Pipe 7/8" 1/2" 7/8" FDKR200AV16 1/2" RZR200AY16 1/2" 1-1/8" 1/2" 1-1/8" FDKR300AV16 RZR300AY16 5/8" 1-1/8" 5/8" 1-1/8" FDKR400AV16... - Page 11 Piping Works & Brazing Technique • Do not use contaminated or damaged copper tubing. If any pipings, evaporator or condenser had been exposed or had been opened for 15 seconds or more, 1/4t then vacuum and purge with field supplied refrigerant. Generally, do not remove plastic, rubber plugs and brass nuts from the valves, fittings, tubings and coils until it is ready to connect suction or liquid line into...
-
Page 12: Electrical Wiring Work
IMPORTANT: * These values are for information only, they should be checked and selected to comply with the local and/or national codes and regulations. They are also subjected to the type of installation and size of conductors. ** The appropriate voltage range should be checked with data label on the unit. FDKR200AV16 FDKR300AV16 FDKR400AV16 Indoor unit Model... - Page 13 5.5Tr Outdoor Unit Field Wiring Instruction: lq, Power Supply to Indoor unit Clamp for (HV) Clamp for (LV) lq, and 3q, Wire Communication Wire Field Earth Wire (LV) Communication Wire to indoor unit lq, to indoor & 3q, Power Supply Field Wire 8.5Tr Outdoor Unit Field Wiring Instruction: Field Earth Wire...
-
Page 14: Oil Refill Charge Guidelines
1. In case of majority Oil spill/Loss by Leakage in field ------ Remove all remaning oil from the compressor. Add fresh oil charge in the compressor as per below table. Refill oil charge Indoor Outdoor ltr/30m pipe length 1.656 FDKR200AV16 RZR200AY16 FDKR300AV16 RZR300AY16 2.395 FDKR400AV16 RZR400AY16 2.632... -
Page 15: Vacuuming And Charging
Charging with an unstable substance may cause explosions and accidents, so always ensure that the appropriate refrigerant R41 0A is charged. SYSTEM REFRIGERANT CHARGE LEVEL GUIDELINES Cooling only Refrigerant Charge Indoor Outdoor Liquid Pipe Gas Pipe (kg/7.5m pipe length) FDKR200AV16 RZR200AY16 1/2" 7/8" FDKR300AV16 RZR300AY16 1/2" 1-1/8" FDKR400AV16 RZR400AY16 5/8" 1-1/8"... -
Page 16: Special Precautions When Charging Unit With Scroll Compressor
9. SPECIAL PRECAUTIONS WHEN CHARGING UNIT WITH SCROLL COMPRESSORS These precautions are intended for use with scroll compressors only with R22, R407C, R 134A, R404A, R507 and R41 0A refrigerants but are not applied to reciprocating compressors or competitive scroll compressors. Scroll compressors have a very high volumetric efficiency and quickly pump a deep vacuum if there is insufficient refrigerant in the system or if refrigerant is added too slowly. -
Page 17: Standard Operating Conditions
I 10. STANDARD OPERATING CONDITIONS Cooling only [Cool i i ng) ------ ---- ---- ..__, ,.._ ,.._ "'O 19 20 1 4 15 24 28 30 ° Indoor temp. ( CWIB) NOTES: The graph is based on the fol lowing conditions: Equivalent piping length: 7,Sm Level difference... -
Page 18: Operation Manual
OPERATION MANUAL 1. SAFETY PRECAUT I O N S To gain full advantage of the air conditioner's functions and to avoid malfunction due to mishandling, please read this operation manual carefully before use. Read the precautions thoroughly to avoid misuse of the equipment. This product comes under the term "appliances not accessible to the general public". - Page 19 • Be sure to use fuses with the correct ampere reading. Do not use improper fuses, copper or other wiring as a substitute, as this may result in electric shocks, fire, damage to the air conditioner. • Consult your local dealer if the air conditioner submerges owing to a natural disaster, such as flood or typhoon.
- Page 20 • Be sure to install an earth leakage breaker. Failure to install an earth leakage breaker may result in electric shocks or a fire. • Be sure to use a dedicated power supply for the air conditioner. The use of any other power supply may cause heat generation, a fire, or air conditioner failures. •...
- Page 21 • Do not remove the outdoor unit's outlet side grille. The grille protects against the unit's high speed fan, which may cause injury. • To avoid injury, do not touch the air inlet or aluminium fins of the air conditioner. •...
-
Page 22: Installation Site
If it occurs, stop the air conditioner and consult with your local dealer for assistance. System relocation • Consult your Daikin dealer about remodelling and relocation. OPERATION PROCEDURE • Operating procedure varies with heat pump type and cooling only type. Contact your local dealer to confirm your system type. -
Page 23: Operation Characteristics
4. OPERATION CHARACTERISTICS ■ CHARACTERISTICS OF THE COOLING OPERATION • If the COOLING OPERATION is used when the indoor temperature is low, frost forms on the heat exchanger of the indoor unit. This can decrease the cooling capacity. In this case, the air conditioner automatically switches to the DEFROST OPERATION for a while. -
Page 24: Operating Instruction
OPERATING INSTRUCTION c:::::) FAN COOL @--+---10 =-,-, 1----+---- [MQ] [fill� [IB] [ffi] [Ml • DAILY ON TNE ,,-, fLf ·L Lf OFFTNE IERRORI &m.,..Oe) � --,-----------::::::::::i- ,-----------+--- 7 .._ ---+---(•I* MODE// -----+--( ◄ TIMER ( RESET 5 -----+--- CANCEL 1. TEMPERATURE (LCD Display) •... - Page 25 3) Factory Reset:- [;�ii ln Menu mode, user can reach to -symbol by left and right key and can do Factory Reset by pressing ,.J l ; ��i Enter key when symbol blinks. On Factory Reset, below setting gets applied: °...
-
Page 26: Malfunction Codes
MALFUNCTION CODES Malfunction Description and Measures Code IDU Antifreeze - Low Evaporator Temperature Alarm Indoor Unit power supply voltage abnormal Indoor heat exchanger liquid pipe tempearture sensor malfunction Indoor Suction air thermistor malfunction High pressure malfunction (Outdoor unit) Low pressure malfunction (Outdoor unit) High pressure difference Alarm (Outdoor unit) Compressor envelope protection (Outdoor unit) High condensing temperature alarm (Outdoor unit) -
Page 27: Troubleshooting
1 9 . TROUBLESHOOTING If any malfunction of the air conditioner unit is noted, immediately switch off the power supply to the unit. Check the following fault conditions and causes for some simple troubleshooting tips. Fault Causes/Action 1. The compressor does not operate 3 minutes after Protection against frequent starting. - Page 28 DAIKIN AIRCONDIT/ON/NG IND/A PVT. LTD. 12th Floor, Building No. 9, Tower A, DLF Cyber City, DLF Phase - 111 Gurgaon - 122002, Haryana (India) Tel: +91-0124-4555444 Fax: +91-0124-4555333 3P724053-2...
