2.10

Process images

4 Byte Process image

Inputs
I1
I2
I3
I4
I5
I6
I7
I8
Error M1
Error M2
Error M3
Error M4
Fuse blow M1
Fuse blow M2
Fuse blow M3
Fuse blow M4
Voltage Error
Temperature Error
Motor
Speed M1
Speed M2
Speed M3
Speed M4
Version 1.0 (10/2022) Online
Translation of the original operating manual
Byte 0, Bit 0
Byte 0, Bit 1
Byte 0, Bit 2
Byte 0, Bit 3
Byte 0, Bit 4
Byte 0, Bit 5
Byte 0, Bit 6
Byte 0, Bit 7
Byte 1, Bit 0
Standard Input
Byte 1, Bit 1
Byte 1, Bit 2
Byte 1, Bit 3
Byte 2, Bit 0
Byte 2, Bit 1
Byte 2, Bit 2
Byte 2, Bit 3
Byte 2, Bit 5
Byte 2, Bit 6
Byte 0
Byte 1
Analog Output
Byte 2
Byte 3
Interroll MultiControl ASi Bus 24V
I1 Standard Input
I2 Standard Input
I3 Standard Input
I4 Standard Input
I5 Standard Input
I6 Standard Input
I7 Standard Input
I8 Standard Input
Error M1 Standard Input
Error M2 Standard Input
Error M3 Standard Input
Error M4 Standard Input
Fuse blow M1 Standard Input
Fuse blow M2 Standard Input
Fuse blow M3 Standard Input
Fuse blow M4 Standard Input
Voltage Error Standard Input
Temperature Error Standard Input
Speed M1 Analog Output
Speed M2 Analog Output
Speed M3 Analog Output
Speed M4 Analog Output
