Summary of Contents for keymaXX SDP-155
- Page 1 SDP-155 02/2023 EPI0001202-000 user manual...
- Page 2 Intended use: The keymaXX SDP-155 is a digital home keyboard, designed to play sounds on the keyboard and make them audible through built-in speakers or headphones. Improper use of the product is considered improper and can lead to personal injury or property damage. No liability is assumed for damage resulting from improper use.
- Page 3 Important safety instructions! Please read before connection! CAUTION! (Electro Magnetic Interference) The normal function of the product may be disturbed by Strong Electro Magnetic Interference. If so, simply reset the product to resume normal operation by following the owner‘s manual. In case the function could not resume, please use the product in other location.
- Page 4 Hint! (Operating conditions) Due to its structural characteristics, the device is designed for indoor operation (IP20). Never expose the device to rain, moisture or liquids as this may cause damage. Vibrations, dust or solar radiation can also lead to damage, avoid them! Do not apply excessive force to the switches or controls.
- Page 5 Hint! (Interferences with other electrical devices) Radios and televisions placed nearby may experience reception interference. Operate this unit at a suitable distance from radios and televisions. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ...
- Page 6 Cleaning: A regular cleaning of the device from impurities and dust increases the durability of the product. Always disconnect the device from the power supply before cleaning it! Never clean the appliance wet! Optical lenses should be cleaned with a dry microfiber cloth to optimize light output. Ventilation grilles and openings should always be cleaned of dust and dirt.
-
Page 7: Installation
INSTALLATION Power Supply This product can be supplied by standard indoor wall socket, please use only the power cord specified by this product. When you do not use, please be sure to turn off the power supply, if you do not use it for a long time, please pull out the power cord and keep it properly. - Page 8 JACK SOCKET [1] Power line connection 1. When used aqccording tot he access power line, one end is inserted into the socket a the bottom oft he piano operation plate. The other end is inserted into the 220V household power socket (Fig.
- Page 9 [3] BLE-MIDI BLE-MIDI can be connected piano to equipment with MIDI Bluetooth. [4] Double headset socket Connecting the headset will automatically cut off the output of the built-in loudspeaker, so it won’t disturb others when playing. This product has two headphone sockets, which can insert two headphones at the same time.
- Page 10 OPERATION GUIDE [1] Piano performance 1. Press the power switch to the open position, you can enter the playing state, playing music on the keyboard. 2. When not in use, please turn off the power supply. This product processor chip is complex, similar to the computer system, and sometimes can not res.
- Page 11 OPERATION GUIDE [4] Voice selector Press and hold the tone/demo button, while pressing the tone of the area in the one corresponding white keys C4-C5, can play different musical instrument tone. Every time you power, the default tone is grand piano tone. [5] set double tone 1.
- Page 12 OPERATION GUIDE [6] Metronome function 1. Press and hold the effect button, while pressing white keys F1 start and close the metronome. 2. Press and hold the effect button, while pressing 1 corresponding white keys G1-E in beat selection area, then you can choose the beat type, a total of 6. 3.
- Page 13 OPERATION GUIDE [10] Recording function Recording function can record and play the track, a total of 2 tracks. Track 1 recording and playback: 1. Press and hold the effect button is not put while pressing the 1 area of the track of the white key A2, you can start track 1 recording.
- Page 14 OPERATION GUIDE [11] Transpose Transpose function can change the pitch of the play keyboard under without changing the keyboard operation. 1. Press and hold MIDI/transpose button and press the white keys F2 and F3, then you can choose transpose function. 2.
- Page 15 OPERATION GUIDE [12] MP3 play function 1. Put flash disk into usb socket which have mp3 songs, automatically play mp3 songs three seconds later. 2. Pres the pause/play button to pause or replay MP3 songs. 3. Light press MP3 selection button to select first/next MP3 song. 4.
