ClearClick Video2Digital 2.0 MINI EDITION Users Manual & Quick Start Manual page 4

1. LCD Screen: LCD screen for preview/playback.
2. Panel Buttons:
Menu : Press this button to enter menu.
Back: Press this button to exit menu
Vol+/-: Press these buttons to control the built-in speaker volume.
Mode: Press this button to switch among Record/Photo/Playback
mode. Hold down longer to delete a recording in playback mode.
Rec/Stop: A single press will start/stop recording in recording
mode. Hold down longer to capture a snapshot.
OK: Select an option. Or in Record mode, press "OK" to
pause/resume while recording.
USB: insert a USB flash drive for recording.
3.
microSD card slot : insert an microSD card (with the gold contacts
4.
5. S-Video: s-video input (optional).
6. AV IN: input jack for RCA input (from VCR, camcorder, etc.)
7. HDMI OUT: HDMI output port (optional – output only, not an input).
8. USB-C port: power input for USB power adapter.
facing you) for recording.
4
