- Page 1 HARDWARE RELOCATE THE HANDLE OF KEYLOCK 6600 SUGGESTIONS & SOLUTIONS FOR HARDWARE LAST UPDATE 29 MAY 2006 Copyright 2006 by FingerTec Worldwide Ltd. All rights reserved. LAST UPDATE 29 MAY 2006 Copyright 2006 by FingerTec Worldwide Ltd. All rights reserved.
- Page 2 Unlock the ring at the end of the handle. Take the cover out from the handle. Step 2 Disconnect the supply wire from the battery. Unscrew the screws located at the upper and bottom of the handle. LAST UPDATE 29 MAY 2006 Copyright 2006 by FingerTec Worldwide Ltd. All rights reserved.
- Page 3 Take out the front panel by moving the handle towards you. Then turn to the back of the front panel and unscrew all the 8 screws at the back. LAST UPDATE 29 MAY 2006 Copyright 2006 by FingerTec Worldwide Ltd. All rights reserved.
- Page 4 Take out the small spring but be careful with the thick spring. Change the position of the thick spring using mirror method. For example, MIRROR During the changing process, take out the handle. LAST UPDATE 29 MAY 2006 Copyright 2006 by FingerTec Worldwide Ltd. All rights reserved.
- Page 5 Follow the steps below for other side of the reader. Turn to the back of the handle and unscrew all the 4 screws to dismantle the handle from the panel. LAST UPDATE 29 MAY 2006 Copyright 2006 by FingerTec Worldwide Ltd. All rights reserved.
- Page 6 4 screws back to the panel. Then connect the wire back to the battery. Then, assemble to the door and lock the ring. LAST UPDATE 29 MAY 2006 Copyright 2006 by FingerTec Worldwide Ltd. All rights reserved.
