Siemens SIMATIC NET RUGGEDCOM RS1600T Installation Manual page 12

1
2
1
2
3
4
5
6
7
8
9
10
11
Figure 1.1
Power LEDs
RESET Button
Port Status LEDs
RS232 Serial Console Port
Communication Ports
Failsafe Alarm Relay
RUGGEDCOM RS1600T
Installation Manual, 11/2022, C79000-G8976-1015-04
3 3
8
Front
Rear
Port Status LED
RESET Button
100Base-FX Fiber Optic Ethernet Ports
10/100Base-TX Copper Ethernet Ports
Power LEDs
Power Terminal Block
Chassis Ground Connection
Failsafe Alarm Relay
RS232 Serial Console Port (DB9)
Front and Rear Panels
9 4
10
Illuminate when power is being supplied to the device by either PS1
(Power Supply 1) or PS2 (Power Supply 2).
Color
Green
Off
Shuts down and restarts the device. For more information, refer to
"Resetting the Device" (Page
Indicate when the associated port is active.
Color
Green
Off
The serial console port is for interfacing directly with the device
and accessing initial management functions. For information
about connecting to the device via the serial console port, refer to
"Connecting to the Device" (Page
Receive and transmit data. For more information about the
various ports available for the RUGGEDCOM RS1600T, refer to
"Communication Ports" (Page
Latches to default state when a power disruption or other alarm
condition occurs. For more information, refer to:
5
8
11
Description
The power supply is supplying
power
Power is off
18).
Meaning
Link detected
No link detected
17).
19).
Introduction
1.2 Description
7
6
9
3
