Page 1
Motor type 3T35-RB (For shafts from 60 mm) (For shafts from 40 mm) 3T45-10RB 3T35-10RB 3T45-20RB 3T35-13RB 3T45-30RB 3T45-40RB Attention: It is important for the safety of persons to follow these instructions. Keep these instructions for future reference. www.3t-components.de WEEE-Reg.-Nr.: DE 77028333...
All contents of these instructions, in particular texts, photographs and graphics, are protected by copyright. Unless expressly indicated otherwise, the copyright is held by 3T-Components GmbH & Co. KG. Please ask us if you wish to use the contents of this document.
Page 3
GUIDELINE With this guide, you can determine the ideal torque in Newton meters (Nm) for the shutter motor. DETERMINE WEIGHT ROLLER SHUTTER 1.) Determine roller shutter area Width (Height + 150 mm) x Width = Roller shutter area (m²) 2.) Determine weight roller shutter material Material kg / m²...
SAFETY INSTRUCTIONS Please read these important safety instructions before commissioning! Incorrect installation can cause serious personal injury and damage to property. The warranty claim expires in case of non-observance of this user information with all contained notes and regulations. In case of non-observance of these instructions, the manufacturer or supplier shall not be liable for any personal injury or property damage incurred. GENERAL SAFETY INSTRUCTIONS WARNING: Important safety instructions.
FUNCTION OVERVIEW SCOPE OF DELIVERY – MOTOR TYPE 3T45-RB SCOPE OF DELIVERY – MOTOR TYPE 3T35-RB Motor Motor Limit switch adapter Limit switch adapter Shaft adapter Shaft adapter Connection cable 3 meters Connection cable 3 meters Universal bearing & cotter pin Universal bearing &...
INSTALLATION NOTES Before installation, all non-essential electrical wiring must be removed, all mechanisms that are not necessary for motorized operation must be deactivated. Do not expose the tubular motor to crushing, impact, falling or contact with any liquids. • Do not punch holes in the entire length of the tube (motor casing) or attach screws to it. Please use suitable suspension springs to fasten the roller shutter curtain to the roller shutter shaft.
INSTALLATION INSTRUCTIONS Please note: The motor can be installed on the right-hand side as well as on the left-hand side. • If the direction of rotation is reversed, please exchange the wires for the up and down direction. The setting of the end positions is only possible in the installed state (motor in shutter shaft). •...
Page 8
INSTALLATION INSTRUCTIONS Motor type 3T45-RB Motor type 3T35-RB Installation with universal bearing or cover cap bearing / clip bearing Installation with universal bearing or clip bearing Clip bearing Universal bearing Clip bearing Universal bearing Cover cap bearing Installation with universal bearing: Installation with universal bearing: Push the motor with the square into the opening of the bearing Push the motor with the square into the opening of the bearing...
INSTALLATION INSTRUCTIONS Remove shutter shaft: Lower the roller shutter. • Open the cover of the roller shutter box. • Release the suspension springs from the roller shutter shaft. • Lift roller shutter shaft incl. ball bearing out of the holder. •...
INSTALLATION INSTRUCTIONS On the opposite side of the motor, push the roller capsule out of the roller shutter shaft until it fits into the ball bearing inserted in the wall bearing. • Fix roller capsule to roller shutter shaft with self-tapping screw. Position the screw at a punched hole. This prevents the screw from slipping. •...
Page 11
INSTALLATION INSTRUCTIONS MOUNTING INSTRUCTIONS FOR 3T-MOTORS MINI-TUBE MOTORS MOTOR TYPE 3T35-RB Use proper suspension springs: To fasten the roller shutter curtain to the roller shutter shaft, please be sure to use • suitable suspension springs for motor operation. These special mini suspension springs only protrude approx.
INSTALLATION INSTRUCTIONS INSTALLATION RADIO AWNING MOTOR Preparation: Attention: Screw in awning & secure with straps or ropes. • Awning arms are under strong tension! Remove awning from wall bracket & place on safe surface. • Prepare motor for installation: Slide limit switch adapter flush against motor head. >...
Page 13
INSTALLATION INSTRUCTIONS Slide the side bearing with universal bearing onto the support tube & fasten. > fig. 3.9 • Ensure that the motor square spigot is properly engaged in the universal bearing. > fig. 3.10 • Secure the motor square spigot with the supplied cotter pin. >...
NOTES ON THE SETTTING OF THE MOTOR Important explanations on setting and programming the motor. Please read carefully before setting the motor. Programming: The programming interval for radio transmitters is 6 seconds. After 6 seconds, the radio transmitter terminates programming. •...
Page 15
PROGRAMMING RADIO TRANSMITTER Important when teaching, changing or deleting transmitters: Only one relevant motor may be switched to voltage! Several radio motors or radio receivers can be programmed to form a group with the same transmission channel. For multi-channel transmitters, channel by channel must be taught or transferred. Pairing handheld transmitters After switching on the power supply / Pressing P1 button the programming (pressing the buttons) must be done within 10 sec.
PROGRAMMING END POSITIONS 1. Initialization of the Attention! If the upper end point is set, do not move the motor upwards! The motor will not stop at the upper end point until the end point setting: lower end point has also been set. Beep from motor Beep from motor + down and up...
Page 17
PROGRAMMING END / INTERMEDIATE POSITIONS Change end points: 3 x Beep from motor + down and up The motor confirms the programming with 3 beeps and down and up Move to end point with Hold down Up- + Down-button Move to new end point with Press and hold Up- or Down-button simultaneously for 5 sec.
Page 18
PROGRAMMING RADIO TRANSMITTER Pairing another handheld transmitter: Handheld transmitter already paired New handheld transmitter / not paired Beep from motor Beep from motor + down and up + down and up The motor confirms the programming with 3 beeps and down and up 1 x Press button 1 x Press button...
Page 19
PROGRAMMING Jog mode: Note: In jog mode, press and hold the up or down button Beep from motor Beep from motor for 2 seconds to activate continuous up or down travel. + down and up + down and up The motor confirms The motor confirms the programming the programming...
Page 20
PROGRAMMING Quick overview programming commands Setting Programming Pairing handheld transmitter P1 or switch on power supply > P2 > P2 > Up oder Down Change direction of rotation Up + Down simultaneously (2 sec.) Setting end points Initialization of the end point setting P2 >...
ROCKER SWITCH Attention! Do not use blind switches, they 1 x Press Motor moves in Motor Motor moves in Motor can cause damage to the system Rocker switch upward direction stops downward direction stops and the motors. TROUBLESHOOTING WHAT TO DO WHEN ..
EU Konformitätserklärung Wir, die Firma 3T Components GmbH & Co. KG Bahnhofstr. 34 55578 Wallertheim Deutschland erklären in alleiniger Verantwortung, dass das weiter unten genannte Produkt Geräteart: Rohrmotor mit integriertem Funkempfänger 433MHz und elektronischen Endschaltern Modell Artikelnummer 3T35-10RB 3T35-13RB 3T45-10RB 3T45-20RB 3T45-30RB 3T45-40RB...
Page 23
OPTIONAL ACCESSORIES TUBULAR MOTORS ANTI-LIFT DEVICE | SHUTTER SHAFTS | ROLLER CAPSULE | SUSPENSION SPRINGS | BALL BEARINGS OCTOCLICK Anti-lift device 2-link / 2,5-link Burglar-resistant • The pushing up of a closed motorized roller shutter is prevented • For tubular motors with electronic or mechanical limit switching •...
