Page 9: Operation
111111 " Operation LINK IN AND LINK OUT CONNECTORS MICROPHONE INPUT LINK OUTPUT - line level output linked from unit preamplifier. LINK INPUT - line This is balanced input with XLR and 6.3mm Jack connectors. Gain of this input can be adjusted by using gain control knob located above connector. The level input linked to device power amplifier.
