- Page 1 User MPA 60 Manual Media player aplifier...
-
Page 2: Safety Instructions
RISK OF ELECTRIC SHOCK with liquids, such as vases, shall be placed on the apparatus. DO NOT OPEN USER MANUAL MPA 60 Media player amplifier... -
Page 3: Table Of Contents
Table of contents Before you start Introduction ..............................2 Features ................................2 Operation Front panel ................................3 Rear panel................................4 Media player ..............................5 Front panel operation ..........................6 Rear panel operation ..........................7-8 Media player operation........................9-11 Specifications General specifications ..........................12 USER MANUAL MPA 60 Media player amplifier... -
Page 4: Before You Start
Before you start MPA 60 user-friendly mixing amplifier with integrated media player. Supports compressed audio files and is an excellent device for small size applications where amplification with music source or audio signal mixing is required. FEATURES • 3.5 mm Jack AUX input •... -
Page 5: Operation
Operation Front Panel 1. Input level control 2. Media player 3. Aux input 4. Tone control 5. Master level control | 6. Led indicators | 7. Power switch USER MANUAL MPA 60 Media player amplifier... -
Page 6: Rear Panel
2. Antenna connector 3. Outputs 4. Telephone-paging input 5. Music on hold output | 6. Line level audio input 7. Microphone input 8. Gain control 9. Priority microphone input 10. Priority switch 11. Phantom power switch USER MANUAL MPA 60 Media player amplifier... -
Page 7: Media Player
4. Preset 5. Backward | 6. Play/Pause 7. Forward 8. Power 9. Repeat 10. Play 1 11. Mute 12. Mode 13. Random 14. Record 15. Record play 16. Delete 17. Number keyboard 18. Volume control USER MANUAL MPA 60 Media player amplifier... -
Page 8: Front Panel Operation
10 second and control knob (BASS) and treble tone control knob (TREBLE) clockwise to raise then turn on again. If LED still indicates after power reset it means amplifier is tone level approximately +10 dB; turn counterclockwise to lower tone level by damaged and need to send to service for repairing. approximately -10 dB. USER MANUAL MPA 60 Media player amplifier... -
Page 9: Rear Panel Operation
ANTENNA CONNECTORS The MIN position disables priority function meanwhile MAX totally mute audio MPA 60 amplifier is supplied with the music source module and FM tuner. We from music player and all other inputs when audio signal is detected in tele are highly recommended to use outdoor FM antenna in order to ensure reliable paging input. - Page 10 Set phantom power switch to “ON” position to activate phantom power to Input This control allows precisely adjust inputs gain. Microphone inputs can be 1 XLR. Maximum phantom power voltage is +14V. To disable phantom power adjusted from -6dBu to -50dBu, line level from +14dBu to -30dBu. set switch to “off” position. USER MANUAL MPA 60 Media player amplifier...
-
Page 11: Media Player Operation
If button is held for a few seconds in FM tuner mode it starts radio station auto searching. Single short press will add 0.05 MHz step to the radios station frequency. In USB and SD card mode holding this button reduce volume level of media player. USER MANUAL MPA 60 Media player amplifier... - Page 12 MUTE Press “Mute” button to mute audio output, to disable mute press “Mute” again. RECORD Record function allows to record audio signal which is playing in the main out- put. Function can be activated by pressing REC button if AUX mode is selected in media player. USER MANUAL MPA 60 Media player amplifier...
- Page 13 Bluetooth devices. In order to play audio, select and pair device named “Audio Bluetooth” at your smart phone or tablet screen. Next time your device will be paired automatically. At the Bluetooth searching moment media player screen displays blinking lines - - - - . Lines stops blinking if media player and smart device connection is successful. USER MANUAL MPA 60 Media player amplifier...
-
Page 14: General Specifications
TELE PAGING Connector: Phoenix The specifications are correct at the time of printing this manual. For improvement purposes, all specifications for this unit, including design and appearance, are subject to change without prior notice. USER MANUAL MPA 60 Media player amplifier...
