MIC iMIX page station user manual
Front panel
1
2
3
4
5
1. Microphone connector
|
2. Signal LED
7. AUX input
|
8. AUX level control
USER MANUAL
MIC iMIX page station
6
|
3. All button
|
4. Talk indication
|
9. Microphone level control
|
10. Chime volume
Rear panel
7
8
9
10
11
|
5. Talk button
|
6. Zone selector
|
11. RJ45 port
|
12. Power connector
12
