Wittmann Spring Assembly Instruction

Assembly instructions for Wittmann Spring Bases:
1. Place both bases alongside to each other (picture no. 1).
2. Turn the folded connectors sticks (attached underneath the right base) outwards so that it is at a
90° angle to the left base (picture no. 2).
3. Connect both bases by pushing them together tightly, making sure that the connector sticks match
the clamp brackets of the left base. (picture no. 3).
4. Attach the fabric/leather cover to the base (picture no. 4).
5. Screw the base connectors to the base on the headboard side (picture no. 5 & 6).
6. Mount the headboard to the base (picture no. 5)
*Working steps only for split bases
Assembly instruction for
Wittmann Spring / Spring Slim
(after the assmebling oft he feet and/or skids)

Assembly instructions for the skids

Parts overview

Base connector
countersunk screw M6x50
barrel washer
Wittmann Möbelwerkstätten GmbH
1 pcs
2 pcs
2 pcs
