- Page 1 Reyee EW PoC Guide V1.0 Ruijie Networks Fuzhou, China...
- Page 2 This document is provided “as is”. The contents of this document are subject to change without any notice. Please obtain the latest information through the Ruijie Networks website. Ruijie Networks endeavors to ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.
- Page 3 Thank you for using our products.
- Page 4 Audience ⚫ Network Engineers ⚫ Network Administrator Obtain Technical Assistance ⚫ Ruijie Networks Websites: http://www.ruijienetworks.com ⚫ Ruijie Service Portal: http://caseportal.ruijienetworks.com Welcome to report error and give advice in any Ruijie manual to Ruijie Service Portal Related Documents Documents Description...
- Page 5 PoC Guide Reyee EW PoC Guide Revision History Date Change contents Reviser 2021.6 Initial publication V1.0 Ruijie GTAC...
-
Page 6: Table Of Contents
PoC Guide Reyee EW PoC Guide Contents Preface ....................... 3 1.Reyee EW Testing List .................. 3 2.Testing Lists ....................4 2.1 Management ....................... 4 2.1.1 eWEB ........................... 4 2.2 Basic Feature ..................... 5 2.2.1 Wizard ..........................5 2.2.2 PPPoE ..........................7 2.2.3 Wireless repeater ...................... -
Page 7: Preface
1.Reyee EW Testing List Category Test Item Description Pass Fail Enable WEB and log into EW 1. Management successfully Complete the initial configuration Wizard by setting IP address, SSID, Country/Region/Time Zone Obtaining an address via PPPoE PPPoE Access to another devices' Wi-Fi... -
Page 8: Testing Lists
PoC Guide Reyee EW PoC Guide 2.Testing Lists 2.1 Management 2.1.1 eWEB eWeb Testing project Enable WEB and log into router successfully Testing purpose Testing procedure and expected results 1. Connect PC with EW through UTP cable as shown above. (in this example, port Lan1 is connected) 2. -
Page 9: Basic Feature
PoC Guide Reyee EW PoC Guide browser must be IE and other major browsers and open compatible mode Login eWeb successfully Measured record eWeb can be easily opened by simply enter 192.168.120.1 via Testing browser conclusion 2.2 Basic Feature 2.2.1 Wizard... - Page 10 PoC Guide Reyee EW PoC Guide 2. Select the method of obtaining an IP address 3. Configure SSID, Wi-Fi password, Management Password 4. Configure Coutry/Region/TimeZone 5. Applying configuration...
-
Page 11: Pppoe
PoC Guide Reyee EW PoC Guide Configure the IP address acquisition method as DHCP, SSID and password, the administrative password is the same as the wifi Measured record password Testing conclusi Initial configuration can be done via Wizard 2.2.2 PPPoE... - Page 12 PoC Guide Reyee EW PoC Guide 3. Next, EW will try to connect to the PPPoE server and create a dial- up port When the PPPoE server is found, EW will use the configured username and password for authentication. 4. Successful authentication will result in an IP address being obtained from the PPPoE server 5.
-
Page 13: Wireless Repeater
PoC Guide Reyee EW PoC Guide 2.2.3 Wireless repeater Wireless repeater Testing project Access to another devices' Wi-Fi to obtain the network Testing purpose On “EW1200G PRO”, select wireless repeater mode Testing procedur e and expected r esults Select primary SSID... - Page 14 PoC Guide Reyee EW PoC Guide Fill in the password for the Primary SSID, set the local SSID to be the same as the primary SSID or create a new SSID When the establishment is successful, the SSID of the EW will be...
-
Page 15: Reyee Mesh
PoC Guide Reyee EW PoC Guide Testing Slave device extend the coverage of the Master WiFi conclusion 2.2.4 Reyee mesh Reyee mesh Testing project Enables Zero-Configuration Networking for Pairing Multiple EW1200G Testing purpose PRO to Complete Wi-Fi Coverage Wireless mesh: Complete the “Wizard”... - Page 16 PoC Guide Reyee EW PoC Guide Tips: Mesh slave ap is managed by the master AP and can not be edited locally. Ping 8.8.8.8 on “Secondary” Wired mesh The two devices are powered on and the Secondary EW wan port...
-
Page 17: Time Schedule
PoC Guide Reyee EW PoC Guide In the Basic → Repeater of Secondary EW, the wired relay established by wired automatic MESH is a status of success Ping 8.8.8.8 on Secondary EW Mesh successfully and main router sync the configuration to Measured record secondary one. - Page 18 PoC Guide Reyee EW PoC Guide 1. Client connect the EW device’s WIFI, on EW Client page can see client list, click “+Add Blocked Time” to set block time Testing procedure and expected results...
- Page 19 PoC Guide Reyee EW PoC Guide 2. Add Rule 3. When the blocking time is not reached, customers access the Internet normally...
- Page 20 PoC Guide Reyee EW PoC Guide 4. When the time reaches the specified block time, it will block completely within 40sec or so, client can access wifi but cannot access the internet. 5. When the non-blocking time is reached, customer access to the...
-
Page 21: Roaming
PoC Guide Reyee EW PoC Guide Block client 14:39-14:42, the client can access WiFi but cannot access Measured record Internet Testing Blocking customer access to the Internet for a period of time conclusion 2.2.6 Roaming Roaming between mesh devices Testing project... - Page 22 PoC Guide Reyee EW PoC Guide 2. The roaming is enabled for the mesh network by default 3. Connect to the main router, then walk to secondary router, open the Wi-Fi MoHo to confirm which device the user is connected to 4.
- Page 23 PoC Guide Reyee EW PoC Guide Roaming back. 5. Repeat step 4 for three times and record the result Roaming Roaming Packet Loss Out Time In Time Measured record 437ms 782ms Testing Roaming success conclusion...
