- Page 1 · RG-MTFi-M520 Mobile LTE WiFi Router Web Configuration Guide...
- Page 2 This document is provided “as is”. The contents of this document are subject to change without any notice. Please obtain the latest information through the Ruijie Networks website. Ruijie Networks endeavors to ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.
- Page 3 Preface Thank you for using our products. Audience This manual is intended for: Ruijie Networks Website: https://www.ruijienetworks.com/ Technical Support Website: https://ruijienetworks.com/support http://caseportal.ruijienetworks.com Case Portal: Community: http://community.ruijienetworks.com Technical Support Email: service_rj@ruijienetworks.com Skype: service_rj@ruijienetworks.com Obtaining Technical Assistance ...
- Page 4 Web Configuration Guide RG-MTFi-M520 Mobile LTE WiFi Router Elements in square brackets are optional. { x | y | z } Alternative keywords are grouped in braces and separated by vertical bars. [ x | y | z ] Optional alternative keywords are grouped in brackets and separated by vertical bars.
-
Page 5: Table Of Contents
Contents Web-based Configuration ........................6 Overview ..........................6 Configuration Environment Requirements ................6 Default Configuration ......................6 Before Start ............................7 Logging In ............................. 7 Homepage ............................. 7 Network Settings ........................... 8 Interface ..........................8 WiFi ............................9 SIM Card Configuration ......................10 Authentication ........................ -
Page 6: Web-Based Configuration
Web Configuration Guide RG-MTFi-M520 Mobile LTE WiFi Router 1 Web-based Configuration 1.1 Overview A user accesses the Web-based management system by using a browser (for example, IE browser) to manage the AP device. Web-based management involves two parts: Web server and Web client. A Web server is integrated onto a device to receive and process requests sent from a client (for example, read a Web file or execute a command request) and returns the processing result to the client. -
Page 7: Before Start
Please make sure the device case and accessories are complete based on packing list. Please insert the SIM cards with the adapters properly then connect necessary antennas. For device installation and power connection, please refer to RG-MTFi-M520 Mobile LTE WiFi Router Installation and Basic Configuration Guide, which is available at the our website. 3 Logging In Open a browser (Chrome is recommended) and type in the Web-based configuration IP address, then the login page will appear as following. -
Page 8: Network Settings
Web Configuration Guide RG-MTFi-M520 Mobile LTE WiFi Router GPS information SIM card information and 3G/4G status Associated STA information To make MTFi SIM cards dial up 3G/4G network successfully, please refer to section 5.3. 5 Network Settings Changing or saving the network setting will cause the restart of the related network interface or service. -
Page 9: Wifi
Web Configuration Guide RG-MTFi-M520 Mobile LTE WiFi Router You can configure the interface protocol (static IP/DHCP), as shown below. You can configure the associated users IP segment, as shown below. 5.2 WiFi You can add, edit or delete a wireless network, and you can also configure SSID, encryption type and associated network... -
Page 10: Sim Card Configuration
Web Configuration Guide RG-MTFi-M520 Mobile LTE WiFi Router 5.3 SIM Card Configuration 5.3.1 APN Configuration MTFi maintains an APN list in this section in where you are able to add, edit and delete a carrier’s APN information. The APN information including APN, username, password, MCC and MNC is usually required for SIM card 3G/4G dialing up. - Page 11 Web Configuration Guide RG-MTFi-M520 Mobile LTE WiFi Router Network Type: 3G4G Switch-over Time: 0 IP: 8.8.8.8, 8.8.4.4 and/or some others the carriers provide 5.3.2 SIM Work Mode You can decide which work mode you want the dual SIM cards to work in. Currently MTFi supports active-standby mode.
-
Page 12: Authentication
Web Configuration Guide RG-MTFi-M520 Mobile LTE WiFi Router 5.4 Authentication You can enable or disable authentication for MTFi, and select the authentication type as Local Auth, WiFiDog Auth, or MAC Auth1. 5.5 Static Address Leases You can bind an IP address with a MAC address and review the bound ones’ lease time in this section. -
Page 13: Advanced
Web Configuration Guide RG-MTFi-M520 Mobile LTE WiFi Router 5.6 Advanced In this section, you can set the uplink/downlink speed limit, which controls the max throughput per associated STA. You can also manage the access white/black list. You are able to add ACS URL which links the device with MACC or your private cloud management center. - Page 14 Web Configuration Guide RG-MTFi-M520 Mobile LTE WiFi Router You can modify the static routing. There is a troubleshooting section which is used for collecting error information and share for further diagnosis. To enable MTFi to be online in MACC, please input ACS URL in Advanced > CWMP > ACS URL. The URL is in the format of ‘http://[MACC IP and Port]/ service/tr069servlet’...
-
Page 15: System
Web Configuration Guide RG-MTFi-M520 Mobile LTE WiFi Router 5.7 System The system time and password can be set here. Backup, upgrade, reset, and restart functions are located in this section. For system upgrade, it is recommended to process the upgrade every time without keeping the old settings.
