Combi Baby Carrier User Manual

For questions concerning installation please see our
instructional video at the following link:
www.combi-intl.com/retrofit_kit.html
Wrench Tool
Spring
*Phillips-head screwdriver
not included.
*Make sure you have all the parts pictured above before using your child
restraint. If any parts are missing, call Consumer Affairs at 1-800-992-6624.

Step 1: Remove Fabric and Plastic Covers

1a.
Detach foot-end of fabric cover from shell by unsnapping
and removing adjuster strap and buckle from cover.
Fold cover back as shown in figure 1b to expose the
plastic covers on the left and right.
1b.
Left
2.
Slide wrench tool under-
neath lower end of plastic
cover to pop open.
Spring
Inspection
Sticker
*Color of spring may vary.
Right
Retrofit Kit Instruction Manual

Step 2: Remove Screw and Washer

3a.
While holding back plastic cover,
use phillips-head screwdriver
to remove screw and washer as
shown in figure 3b.
3b.

Step 3: Assemble Spring

4.
Place screw and washer
into spring loop.

Models Affected

Combi Centre, Centre ARB, Shuttle
and associated Travel Systems con-
taining the Centre and Shuttle.
Model numbers affected are:
8065, 8074, 8086, 8087 and 8520
and associated Travel Systems
containing the Centre and Shuttle
(Model #4400, 4515, 4520)
Child restraints manufactured prior
to 12/15/2007 are affected by this
recall.
