- Page 1 Instruction Manual Propane (LP) Small Gas Fryer Model No. 5094 Series 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 USA © 2023 Gold Medal Products Co. Part No. 110317...
-
Page 2: Safety Precautions
Propane (LP) Small Gas Fryer Model No. 5094 Series SAFETY PRECAUTIONS This unit is designed for use with Propane (LP) Gas only. DANGER Gas is safe when used properly, but can be very dangerous when used improperly. We suggest that installation be carefully made by qualified personnel only. - Page 3 Note: Improvements are always being made to Gold Medal’s equipment. This information may not be the latest available for your purposes. It is critical that you call Gold Medal’s Technical Service Department at 1-800-543-0862 for any questions about your machine operations, replacement parts, or any service questions.
-
Page 4: Table Of Contents
Propane (LP) Small Gas Fryer Model No. 5094 Series Table of Contents SAFETY PRECAUTIONS ........................... 2 INSTALLATION INSTRUCTIONS ........................5 Inspection of Shipment ............................5 Manual ..................................5 Model Description ..............................5 Items Included with this Unit ........................... 5 Setup ................................... 5 Gas Installation Instructions ........................ -
Page 5: Installation Instructions
Propane (LP) Small Gas Fryer Model No. 5094 Series INSTALLATION INSTRUCTIONS Inspection of Shipment After unpacking, check thoroughly for any damage which may have occurred in transit. Claims should be filed immediately with the transportation company. The warranty does not cover damage that occurs in transit, or damage caused by abuse, or consequential damage due to the operation of this machine, since it is beyond our control (reference warranty in back of manual). - Page 6 Propane (LP) Small Gas Fryer Model No. 5094 Series 4. Observe the following clearances to ensure proper air supply and maintenance: • Minimum of 10 inches clearance on each side of unit. • Minimum of 10 inches clearance on front and back of unit.
-
Page 7: Gas Installation Instructions
Model No. 5094 Series Gas Installation Instructions Gas Requirements The 5094 Series Fryer is designed for Propane only. Converting this unit to an alternate fuel source will void the warranty and may cause a dangerous condition. 5094-00-100, 5094-00-200: Propane Gas, 45,000 BTU/HR NOTE: This fryer must be attached to a minimum of 40 pound LPG cylinder. -
Page 8: Important Fire Safety Notice
Propane (LP) Small Gas Fryer Model No. 5094 Series Important Fire Safety Notice Consult your local fire protection agency for your area’s requirements. Check local fire protection requirements regularly to ensure compliance with local codes and proper operation. Have a fire extinguisher near the fryer. -
Page 9: Checking For Gas Leaks
Stop using the appliance immediately if damage is found, and contact a qualified professional to inspect and correct any issue. 3. Securely route all gas lines away from flames and high temperature areas. 4. Contact Gold Medal Technical Support, or a qualified Gas Service Technician with any questions. Gas Pressure We have determined that optimum frying occurs when the gas pressure is adequate. -
Page 10: Operating Instructions
Propane (LP) Small Gas Fryer Model No. 5094 Series OPERATING INSTRUCTIONS Controls and Their Functions COMBINATION VALVE (Safety Valve) The Combination Valve has three settings to control gas flow, PILOT, ON, and OFF. (Reference the Lighting and Shutdown Instructions in the Operating Instruction section.) PILOT: When valve is in PILOT position, depress valve to provide gas to light the pilot. -
Page 11: Tank Preparation
Propane (LP) Small Gas Fryer Model No. 5094 Series DRAIN VALVE (with Drain Plug) Drain Valve allows cooking oil to be drained from the tank—the valve handle has a safety collar, and the drain line has a drain plug to help prevent unintentional tank draining. -
Page 12: Lighting And Shutdown Instructions
Propane (LP) Small Gas Fryer Model No. 5094 Series Lighting and Shutdown Instructions CAUTION If pilot is turned off or goes out, shut off the gas supply and turn all unit controls off—a minimum 5-minute shutdown period is required before attempting to re-light. -
Page 13: Operating The Fryer
Propane (LP) Small Gas Fryer Model No. 5094 Series Operating the Fryer Important Operating Information and Quality Control Tips • Don't overheat. Don't fry if the oil temperature exceeds 400°F. • Don't waste money, use only high quality heavy duty frying shortening. -
Page 14: Care And Cleaning
4. Add appropriate amount of dish soap. To deep clean a tank which has a build-up of cooking oil: Instead of soap, add appropriate amount of Gold Medal’s Heat’n Kleen (Item No. 2095) per amount of water used (see Heat’n Kleen product instructions). -
Page 15: Troubleshooting
Propane (LP) Small Gas Fryer Model No. 5094 Series Troubleshooting Issue Possible Cause Solution Gas Issues A. For gas issues refer to the initial Gas Installation Instructions. Cooking Issues A. Product cooking issues A. Reference the Important Operating Information and Quality Control Tips located in the Operating the Fryer section of this manual. -
Page 16: The Following Sections Are For Qualified Service Personnel Only
Propane (LP) Small Gas Fryer Model No. 5094 Series THE FOLLOWING SECTIONS ARE FOR QUALIFIED SERVICE PERSONNEL ONLY MAINTENANCE INSTRUCTIONS DANGER Improper installation, adjustment, alteration, service, or maintenance can cause property damage, injury, or death. Any alterations to this equipment will void the warranty and may cause a dangerous condition. -
Page 17: Ordering Spare Parts
4. Please include your model number, serial number, and date of manufacture (located on the machine nameplate/data plate) with your order. 5. Address all parts orders to Parts Department, Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 or place orders by phone or online:... -
Page 18: Cabinet And Tank View
Propane (LP) Small Gas Fryer Model No. 5094 Series Cabinet and Tank View General image shown for reference only. Part Number Part Number Item Part Description Item Part Description All Models All Models OIL TANK WELD ASSY 89950 FRYER TANK SAFETY LABEL... -
Page 19: 5094-00-100 Gas Line, Controls, Accessories
Propane (LP) Small Gas Fryer Model No. 5094 Series 5094-00-100 Gas Line, Controls, Accessories *Pilot Installation Note: Use the pilot fitting for (LP) propane marked 4211. Accessories Aluminum Tubing (not shown) Reference wire diagram when wiring unit. Part Number Part Number... -
Page 20: 5094-00-200 Gas Line, Controls, Accessories
Propane (LP) Small Gas Fryer Model No. 5094 Series 5094-00-200 Gas Line, Controls, Accessories *Pilot Installation Note: Use the pilot fitting for (LP) propane marked 4211. Accessories Aluminum Tubing Reference wire diagram when wiring unit. (not shown) Part Number Part Number... -
Page 21: Wiring Diagram
Propane (LP) Small Gas Fryer Model No. 5094 Series Wiring Diagram gmpopcorn.com Page 21... -
Page 22: Warranty
© 2023 – The text, descriptions, graphics, layout, and other material in this publication are the exclusive property of Gold Medal Products Co. and shall not be used, copied, reproduced, or published in any fashion, including website display, without its express written consent.
