- Page 1 Instruction Manual Propane (LP) Gas Funnel Cake Fryer Model No. 5099-00-100 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 USA © 2023 Gold Medal Products Co. Part No. 110316...
-
Page 2: Safety Precautions
Propane (LP) Gas Funnel Cake Fryer Model No. 5099-00-100 SAFETY PRECAUTIONS This unit is designed for use with Propane (LP) Gas only. DANGER Gas is safe when used properly, but can be very dangerous when used improperly. We suggest that installation be carefully made by qualified personnel only. - Page 3 Note: Improvements are always being made to Gold Medal’s equipment. This information may not be the latest available for your purposes. It is critical that you call Gold Medal’s Technical Service Department at 1-800-543-0862 for any questions about your machine operations, replacement parts, or any service questions.
-
Page 4: Table Of Contents
Propane (LP) Gas Funnel Cake Fryer Model No. 5099-00-100 Table of Contents SAFETY PRECAUTIONS ........................... 2 INSTALLATION INSTRUCTIONS ........................5 Inspection of Shipment ............................5 Manual ..................................5 Model Description ..............................5 Items Included with this Unit ........................... 5 Setup ................................... 5 Using the Door Panel Catch .......................... -
Page 5: Installation Instructions
To order copies of the operator’s manual go to gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, OH 45241 USA 1-(800)-543-0862. Model Description 5099-00-100: Propane (LP) Gas Funnel Cake Fryer Items Included with this Unit Tank Regulator... -
Page 6: Using The Door Panel Catch
Propane (LP) Gas Funnel Cake Fryer Model No. 5099-00-100 5. Bolt the unit to the counter to secure it from tipping. To restrain the fryer, use 3/8-16 bolts through the counter into tapped holes in the bottom of the fryer. -
Page 7: Gas Installation Instructions
Model No. 5099-00-100 Gas Installation Instructions Gas Requirements The 5099-00-100 is designed for Propane only. Converting this unit to an alternate fuel source will void the warranty and may cause a dangerous condition. 5099-00-100: Propane Gas, 95,000 BTU/HR NOTE: This fryer must be attached to a minimum of 80-100 pound LPG cylinder. The unit will not operate properly on small (20-40 lb.) cylinders. -
Page 8: Important Fire Safety Notice
Propane (LP) Gas Funnel Cake Fryer Model No. 5099-00-100 Important Fire Safety Notice Consult your local fire protection agency for your area’s requirements. Check local fire protection requirements regularly to ensure compliance with local codes and proper operation. Have a fire extinguisher near the fryer. -
Page 9: Checking For Gas Leaks
Stop using the appliance immediately if damage is found, and contact a qualified professional to inspect and correct any issue. 3. Securely route all gas lines away from flames and high temperature areas. 4. Contact Gold Medal Technical Support, or a qualified Gas Service Technician with any questions. Gas Pressure We have determined that optimum frying occurs when the gas pressure is adequate. -
Page 10: Operating Instructions
Propane (LP) Gas Funnel Cake Fryer Model No. 5099-00-100 OPERATING INSTRUCTIONS Controls and Their Functions COMBINATION VALVE (Safety Valve) The Combination Valve has three settings to control gas flow, PILOT, ON, and OFF. (Reference the Lighting and Shutdown Instructions in the Operating Instruction section.) PILOT: When valve is in PILOT position, depress valve to provide gas to light the pilot. -
Page 11: Tank Preparation
Propane (LP) Gas Funnel Cake Fryer Model No. 5099-00-100 DRAIN VALVE (with Pin Lock and Drainpipe Extension) Drain Valve allows cooking oil to be drained from the tank—the valve handle has a safety collar and pin lock to prevent unintentional opening. Always allow hot cooking oil to cool below 140°F before putting on the drainpipe extension and draining unit, see image. -
Page 12: Lighting And Shutdown Instructions
Propane (LP) Gas Funnel Cake Fryer Model No. 5099-00-100 Lighting and Shutdown Instructions CAUTION If pilot is turned off or goes out, shut off the gas supply and turn all unit controls off—a minimum 5-minute shutdown period is required before attempting to re-light. -
Page 13: Operating The Fryer
Propane (LP) Gas Funnel Cake Fryer Model No. 5099-00-100 Operating the Fryer Important Operating Information and Quality Control Tips • Don't overheat. Don't fry if the oil temperature exceeds 400°F. • Don't waste money, use only high quality heavy duty frying shortening. -
Page 14: Care And Cleaning
4. Add appropriate amount of dish soap. To deep clean a tank which has a build-up of cooking oil: Instead of soap, add appropriate amount of Gold Medal’s Heat’n Kleen (Item No. 2095) per amount of water used (see Heat’n Kleen product instructions). -
Page 15: Troubleshooting
Propane (LP) Gas Funnel Cake Fryer Model No. 5099-00-100 Troubleshooting Issue Possible Cause Solution Gas Issues A. For gas issues refer to the initial Gas Installation Instructions. Cooking Issues A. Product cooking issues A. Reference the Important Operating Information and Quality Control Tips located in the Operating the Fryer section of this manual. -
Page 16: The Following Sections Are For Qualified Service Personnel Only
Propane (LP) Gas Funnel Cake Fryer Model No. 5099-00-100 THE FOLLOWING SECTIONS ARE FOR QUALIFIED SERVICE PERSONNEL ONLY MAINTENANCE INSTRUCTIONS DANGER Improper installation, adjustment, alteration, service, or maintenance can cause property damage, injury, or death. Any alterations to this equipment will void the warranty and may cause a dangerous condition. -
Page 17: Ordering Spare Parts
4. Please include your model number, serial number, and date of manufacture (located on the machine nameplate/data plate) with your order. 5. Address all parts orders to Parts Department, Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 or place orders by phone or online:... -
Page 18: Cabinet And Tank View
Propane (LP) Gas Funnel Cake Fryer Model No. 5099-00-100 Cabinet and Tank View Keep lower half of Union threaded on drainpipe for easy install. Union Drainpipe Extension 10, 11 13, 14 16, 17 Part Number Part Number Item Part Description... -
Page 19: Gas Line, Controls, Accessories
Propane (LP) Gas Funnel Cake Fryer Model No. 5099-00-100 Gas Line, Controls, Accessories *Pilot Installation Note: Use the pilot fitting for (LP) propane marked 4211. Accessories Aluminum Tubing (not shown) Reference wire diagram when wiring unit. Part Number Part Number... -
Page 20: Wiring Diagram
Propane (LP) Gas Funnel Cake Fryer Model No. 5099-00-100 Wiring Diagram gmpopcorn.com Page 20... -
Page 21: Warranty
