ONWARD LIFTED 4-PASSENGER LITHIUM-
ION
Operators Manual
APPLICABLE TO VEHICLES WITH SERIAL PREFIX OF DM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Club Car ONWARD LIFTED and is the answer not in the manual?

Questions and answers

Mariann McKallen
June 6, 2025

Fault Error

Mariann McKallen
June 6, 2025

Reset Lithium Battery. Possible Fuse

Summary of Contents for Ingersoll-Rand Club Car ONWARD LIFTED

  • Page 1 ONWARD LIFTED 4-PASSENGER LITHIUM- Operators Manual APPLICABLE TO VEHICLES WITH SERIAL PREFIX OF DM...
  • Page 2 Copyright © 2020 Club Car, LLC This manual effective December 1, 2020...
  • Page 3: Introduction

    INTRODUCTION VEHICLE OWNERSHIP Congratulations! The Club Car brand is widely recognized as the industry leader in vehicle efficiency and long-lasting value. Read, understand, and obey the technical content in this manual to protect your investment and provide years of reliable vehicle operation. Read, understand, and obey all instructions and safety precautions in this manual to prevent the risk of personal injury or property damage.
  • Page 4 APPROVED DEALERS AND DISTRIBUTORS Club Car’s customer support system offers fast and courteous service. Speak with your dealer or distributor for: • Accessories • Technical Advice • Publications • Warranty Work • Replacement Parts To find your nearest dealer or distributor: •...
  • Page 5 NOTICES VEHICLE MODEL AND SERIAL NUMBER The vehicle serial number is located on a bar code decal installed below the passenger-side cup holder. 1. A two-letter code that identifies the vehicle model. 2. A four-digit code that identifies the model year and production week the vehicle was assembled.
  • Page 6 VEHICLE WARRANTY Warranty information is located in the warranty section of this manual. No other expressed or implied warranties are contained herein. Your dealer or distributor examined the vehicle before it was delivered to you. The dealer or distributor will also supply you a copy of the completed vehicle warranty registration form. GOVERNMENTAL AND INDUSTRY STANDARDS AMERICAN NATIONAL STANDARDS INSTITUTES ANSI Z135 The configuration of this vehicle complies with American National Standards Institutes (ANSI) Z135...
  • Page 7 PUBLICATION COPYRIGHT This manual contains proprietary information that is protected by copyright. All rights are reserved. Express written consent of Club Car, LLC is necessary to photocopy, replicate, or translate this manual. The information contained in this publication is subject to change without notice. ONWARD LIFTED 4-PASSENGER LITHIUM-ION Page v Operators Manual...
  • Page 8 (Page intentionally left blank.)
  • Page 9: Table Of Contents

    CONTENTS INTRODUCTION ............................I NOTICES ..............................III SECTION 1 – SAFETY INFORMATION ....................11 General Safety Information ........................ 12 Note To The Owner ......................... 12 Practice Safety..........................12 Safety Signal Words ........................12 Safety Committee .......................... 13 Vehicle Safety Information........................13 Vehicle Safety And Compliance Decals..................14 Vehicle Safety Features ........................
  • Page 10 DC Output ............................39 IC900 Specifications..........................40 Manufacturer Information ......................40 Dimension And Weight ........................40 Operational Temperature....................... 40 AC Input............................40 DC Output ............................40 Governmental And Industry Certifications ..................40 European Conformity ........................40 Federal Communications Commission ..................41 International Protection Marking....................
  • Page 11 SECTION 8 – VEHICLE MAINTENANCE .....................63 Disable The Vehicle ..........................64 Vehicle Cleaning........................... 65 Windshield ............................65 Vehicle Exterior ..........................65 Vehicle Interior ..........................65 Maintenance Schedule ........................65 Overview............................65 Service Schedule ..........................66 Maintenance Tasks..........................67 Clean The Dynamic Braking Resistor..................... 67 Lift The Vehicle ..........................
  • Page 12 (Page intentionally left blank.)
  • Page 13: Notices

    Safety Information Notices SAFETY INFORMATION ONWARD LIFTED 4-PASSENGER LITHIUM-ION Page 11 Operators Manual TPCC01DM00EN019 (Edition D)
  • Page 14: General Safety Information

    Safety Information General Safety Information GENERAL SAFETY INFORMATION This vehicle is designed and intended to transport people on improved or semi-improved surfaces for applications including commercial, industrial, agriculture and personal use, where permitted by law or by regulatory authority rules. Always adhere to local laws and regulations pertaining to the use of the vehicle.
  • Page 15: Safety Committee

    Safety Information Vehicle Safety Information SAFETY SIGNAL WORD SIGNIFICANCE A DANGER identifies a hazardous situation which will result in DANGER death or serious injury. A WARNING identifies a hazardous situation which could result WARNING in death or serious injury. A CAUTION identifies a hazardous situation which could result CAUTION in minor or moderate injury.
  • Page 16: Vehicle Safety And Compliance Decals

    Safety Information Vehicle Safety Information THE VEHICLE DOES NOT GIVE PROTECTION FROM LIGHTNING, FLYING OBJECTS, OR OTHER STORM RELATED HAZARDS. DO NOT OPERATE THE VEHICLE IN STORMS. STOP THE VEHICLE. GET OUT OF THE VEHICLE IMMEDIATELY AND FIND A SHELTER IN ACCORDANCE WITH APPLICABLE SAFETY GUIDELINES FOR YOUR LOCATION IF IN A STORM.
  • Page 17 Safety Information Vehicle Safety Information OPERATING INSTRUCTIONS Before using vehicle, read owner’s manual and vehicle safety warnings. Study and understand controls. TO OPERATE • Ensure wheels are turned in desired direction of travel and path is clear. • Turn key to ON. •...
  • Page 18 Safety Information Vehicle Safety Information WARNING WARNING COLLISION, UNINTENDED MOVEMENT, ROLLOVERS, OR FALLING OUT CAN CAUSE RISK OF EYE INJURY SERIOUS INJURY OR DEATH. Maximum Grade: 20% Maximum Load: 800 lb (360 kg) Windshield does not • Vehicle to be operated by licensed or authorized persons only. •...
  • Page 19 Safety Information Vehicle Safety Information WARNING SET THE RUN/TOW-STOW SWITCH TO TOW BEFORE: • Towing this vehicle • Extended storage • Servicing the vehicle BATTERY EXPLOSION MAXIMUM TONGUE WEIGHT CAN CAUSE SERIOUS INJURY 150 lb (68 kg) STOW • Read the vehicle service manual before servicing. 101155301 •...
  • Page 20: Vehicle Safety Features

    Safety Information Vehicle Safety Features FALLING OFF CAN CAUSE SERIOUS INJURY OR DEATH WARNING • Two (2) persons per bench seat maximum. 105267301 15. Falling Off Warning Decal VEHICLE SAFETY FEATURES BATTERY CHARGING INTERLOCK External Battery Charger: The battery charging interlock is a safety feature that prevents possible damage to the battery charger and vehicle.
