- Page 1 Operating manual CarboVis 700/5 IQ Set UV/VIS sensor set for the spectral determination of carbon sum parameters Set contents: CarboVis 700/5 IQ UV/VIS sensor MIQ/VIS Connection module for UV/VIS sensors MIQ/CHV Valve module ba75405e01 12/2003...
- Page 2 The latest version of the present operating manual can be found in the Internet under www.WTW.com. © Copyright Weilheim 2003, WTW GmbH & Co. KG Reprinting - even as excerpts - is only allowed with the explicit written authorization of WTW GmbH & Co. KG, Weilheim. Printed in Germany.
-
Page 3: Table Of Contents
CarboVis 700/5 IQ Contents Overview ........1-1 How to use this component operating manual . - Page 4 Contents CarboVis 700/5 IQ Spare parts, maintenance means, accessories ..6-1 What to do if........7-1 Troubleshooting .
-
Page 5: Overview
CarboVis 700/5 IQ Set Overview Overview How to use this component operating manual Structure of the operating IQ S ENSOR manual Fig. 1-1 Structure of the IQ S operating manual ENSOR operating manual has a modular structure like the IQ S ENSOR itself. -
Page 6: Field Of Application
The CarboVis 700/5 IQ Set is an online measuring system for in-situ determination of carbon sum parameters in waste water treatment plants. The range of application comprises control, feedback control and monitoring. The CarboVis 700/5 IQ Set can be used in the inlet or outlet. Compressed-air... -
Page 7: Structure Of The Uv/Vis Sensor
CarboVis 700/5 IQ Set Overview Structure of the UV/VIS sensor A UV/VIS sensor contains a light source (1), a measuring gap (3) to enable the contact of light with the measuring solution, and a detector (5) to measure the alleviated light beam. -
Page 8: Overview Of The Set
The following overview shows the integration of the CarboVis 700/5 IQ Set in the IQ S ENSOR Fig. 1-3 The CarboVis 700/5 IQ Set in the IQ S ENSOR Instrument identification A name plate with the exact designation and series number of the UV/ VIS sensor is fixed on the sensor cable. -
Page 9: Safety
Safety This component operating manual contains special instructions that must be followed in the operation of the CarboVis 700/5 IQ Set. Thus, it is essential to read this component operating manual before carrying out any work using this sensor or the set. In addition to this manual, the... -
Page 10: Authorized Use
Safety CarboVis 700/5 IQ Set Authorized use The authorized use of the CarboVis 700/5 IQ Set consists of its use as a sensor in the IQ S ENSOR The technical specifications according to chapter 8 T ECHNICAL DATA must be observed. Only operation according to the instructions given in this operating manual is considered to be authorized. - Page 11 CarboVis 700/5 IQ Set Safety Safe operation If safe operation is no longer possible, the sensor must be taken out of operation and secured against inadvertent operation. Safe operation is no longer possible if the sensor: l has been damaged in transport...
- Page 12 Safety CarboVis 700/5 IQ Set 2 - 4...
-
Page 13: Commissioning
CarboVis 700/5 IQ Set Commissioning Commissioning System requirements of the IQ S ENSOR Software versions of the The operation of the CarboVis 700/5 IQ requires the following software controller and terminal versions in the IQ S ENSOR components l MIC/C184 Controller software: Version 2.66 or higher... -
Page 14: Installation
The sensor may only be electrically connected to the MIQ/VIS module while the module is not supplied with voltage (dead). The following steps are required to install the CarboVis 700/5 IQ Set: l Make sure that there is enough system power available in the... -
Page 15: Mounting The Sensor
CarboVis 700/5 IQ Set Commissioning 3.3.2 Mounting the sensor Caution The sensor is an optical precision instrument that is to be protected against shocks. Make sure the distances to the wall, bottom and other installation surroundings are sufficient. If necessary, protect the sensor from hitting using the protective ring provided. -
Page 16: Connecting The Module Stack (Miq/Vis + Miq/Chv) To The Iq Sensor Net
Commissioning CarboVis 700/5 IQ Set Vertical installation When mounting the sensor vertically, make sure that interfering elements in the measuring gap (e.g. air bubbles from the compressed- air cleaning) can escape with the flow. In the case of vertical installation, the minimum flow rate is 0.2 m/s in order to keep the measuring gap optimally clean. -
Page 17: Connecting The Compressed-Air Hose
CarboVis 700/5 IQ Set Commissioning 3.3.4 Connecting the compressed-air hose General instructions Observe the following instructions when connecting the compressed air hoses: l Follow the specification of the compressed air according to chapter ECHNICAL DATA l Only use the mounting material provided to connect the compressed air. - Page 18 Commissioning CarboVis 700/5 IQ Set Connecting the compressed-air hose to the MIQ/CHV MIQ/CHV UV/VIS-Sensor Fig. 3-5 Connecting the compressed-air hose to the MIQ/CHV Connect the other end of the compressed-air hose (4) to the compressed-air outlet of the MIQ/CHV. Secure the connection with a hose clip (5).
-
Page 19: Connecting The Sensor
CarboVis 700/5 IQ Set Commissioning 3.3.5 Connecting the sensor Caution The sensor may only be electrically connected to the MIQ/VIS module while the module is not supplied with voltage (dead). Caution A UV/VIS sensor CarboVis 700/5 IQ may only be connected to the IQ S via an MIQ/VIS module. -
Page 20: Initial Commissioning
Commissioning CarboVis 700/5 IQ Set Initial commissioning 3.4.6 General information Warning Never look into the measurement window or put objects into the measurement window during operation! The emitted UV radiation can damage the eyes! In the case of authorized use, inadvertent eye contact with the light beam is not possible.
