HANBURY DOMED TOP ARCH
INSTRUCTIONS
We recommend using the following
tools (not supplied):
Tape Measure
Pozidrive
Screwdriver
PLEASE KEEP PLASTIC BAGS AND SMALL PARTS
AWAY FROM CHILDREN
We strongly advise that you anchor your arch down with either fixtures shown below to enhance stability. You will need to
purchase these separately. Apply each fixture to each leg before fully constructing your arch. 130mm of your post will be supported
FOR PATIO/DECKING (HARD SURFACES)
Easy-Fit Fencebase - 65mm
(FBEF65)
IMPORTANT
Assembly requires 2+
adults.
It's vital that you build your new arch on a level ground in your desired location.
Missing something or need more information?
Call our aftersales team on
0333 321 3142
Forest Garden, Oak Drive, Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB
EU Authorised Representative: Authorised Representative Service, 77 Camden Street Lower Dublin, D02 XE80, Ireland
Drill & 2-3mm
Ladder
Drill Bits
PREPARATION
within the fixture.
130mm
FIXING PACK CONTAINS:
FIXING PACK CODE: HANDTAFP
Rubber Mallet
CHECK AND TIGHTEN ALL THE FIXINGS APPLIED
TO THIS PRODUCT ON A REGULAR BASIS.
750mm
REMINDER
Always pre-drill before
screwing.
Visit our website for spare instructions and
more information
www.forestgarden.co.uk
ISSUE: 0122
4 x 80mm Screws
QTY: 5
4 x 60mm Screws
QTY: 4
FOR GRASS/SOIL
(SOFT SURFACES)
Easy-Fit Fencefast
(FEF6575)
Ensure that the spike can be
inserted into the ground by
750mm.
