Making British gardens great
SLATTED CORNER PERGOLA
INSTRUCTIONS
We recommend using the following tools (NOT SUPPLIED):
Tape
Screwdriver
Measure
It's vital that you build your new pergola on a level ground in your desired location.
FIXING PACK CONTAINS:
6 x 120mm Screws
QTY: 12
PLEASE KEEP PLASTIC BAGS AND SMALL PARTS AWAY FROM CHILDREN
IMPORTANT
Assembly requires 5+
adults.
THE ROOF OF THIS PERGOLA IS NOT A LOAD BEARING STRUCTURE
Missing Something?
Call our aftersales team on
0333 777 7089
Forest Garden, Oak Drive, Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB
Pozidrive
Drill & 2mm
Drill Bit
Need more information?
Call our technical team on
0333 321 3142
Hammer
5 x 80mm Screws
QTY: 20
REMINDER
Always pre-drill before
screwing.
Visit our website for spare
instructions and more
information
www.forestgarden.co.uk
ISSUE: 0120
FIXING PACK CODE: SCP90FP
Ladder
Spirit Level
4 x 50mm Screws
QTY: 24
Advertisement
Related Manuals for Forest SCP90
Summary of Contents for Forest SCP90
- Page 1 Visit our website for spare Missing Something? Need more information? instructions and more Call our aftersales team on Call our technical team on information 0333 777 7089 0333 321 3142 www.forestgarden.co.uk Forest Garden, Oak Drive, Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB...
- Page 2 PREPARATION We strongly advise that you anchor your pergola down with either fixtures shown below to enhance stability. You will need to purchase these separately. Apply each fixture to each leg before fully constructing your pergola. 130mm of your post will be supported within the fixture. FOR GRASS/SOIL (SOFT SURFACES) Easy-Fit Fencefast...
- Page 3 BACK CORNER FRONT CORNERS SCREWS SCREWS Assemble this stage with 3 adults holding onto a post each. If your 3 posts are anchored, use the measurements provided as a guide for spacing. Lift up the assembled roof and place onto the designated grooves provided on the posts as shown above.
- Page 4 CHECK YOU HAVE ALL YOUR PARTS. (The parts do not have codes on them. They are listed below should you need to order one.) Slatted Corner Pergola (SCP90) Description Part Code SCP90BP Back Post SCP90LRRAF Side Fascias Front Fascia SCP90FRAF...
