Hytek ALPHA/50WPFC Technical Data Manual page 15

DRG.
REF
EXTERNAL COMPONENTS
1 LOCK (x 2)
2 NOZZLE HOLSTER WITH SWITCH
3 DOOR KEY
4 OUTLET ELBOW
5 SIDE ACCESS PANEL
6 MOUNTING BASE
7 TOP CAP
8 DOOR
9 SIDE PANEL
10 SIDE PANEL WITH HOSE OUTLET
INTERNAL COMPONENTS
11 DISPLAY COVER
12 PULSER
13 SOLENOID VALVE
14 MOTOR
15 4 PISTON METER (2 REV PER LITRE)
16 PUMP UNIT (COMPLETE)
17 PULLEY BELT (50 LPM)
17 PULLEY BELT (70 LPM)
17 PULLEY BELT (90 LPM)
18 PULLEY (50 LPM)
18 PULLEY (70 LPM)
18 PULLEY (90 LPM)
19 METER OUTLET PIPE
20 INLET FLANGE*
21 INLET GASKET*
22 FLEXIBLE SUCTION CONNECTOR
23 MOTOR RELAY (INSIDE JUNCTION BOX)*
SOLENOID RELAY (INSIDE JUNCTION BOX)*
24 230 AC MAINS JUNCTION BOX
25 LOW VOLTAGE JUNCTION BOX
26 PUMP MOUNTING FRAME (x 2)
27 MOTOR MOUNTING PLATE
28 JUNCTION BOX
29 POWER FAIL BACKUP BATTERY*
* Not shown
ALPHA PARTS LIST
PART DESCRIPTION PART NO.
ALP.LOCK.FC
ALP.NOZBOOT.P
ALP.KEY.FC
ELB.4FFCR
ALP.ACCPAN3
ALP.BASE3
ALP.CAP4
ALP.DOOR.H4
ALP.SPAN.BL4
ALP.SPAN.H4
ALP.AFC.COVER
PULS.W
ALP.SOL.A
MOT.E75.ATEX
209A.METER.REP
209A.PASSY.W
VBLT.275
VBLT.28
VBLT.285
PULL.2C
PULL.25C
PULL.25C
ALP.OUTPIPE.W
FLNG
GSK.TRI
TTLB
ALP.FC10.RELAY
ALP.FC10.RELAY
ALP.JBOX.P
ALP.JBOX.P
ALP.PFRAME3
ALP.PPLATE3C
ALP.DBOX.FC103
ALP.W.BATT
S887/2
