  • Page 1 Citrix ADC MPX Citrix Product Documentation | docs.citrix.com February 8, 2023...

  • Page 2: Table Of Contents

    Citrix ADC MPX 5550 and MPX 5650 Citrix ADC MPX 5900 Citrix ADC MPX 7500 and MPX 9500 Citrix ADC MPX 8005, MPX 8015, MPX 8200, MPX 8400, MPX 8600, and MPX 8800 Citrix ADC MPX 8900 Citrix ADC MPX 8900 FIPS certified appliance...
  • Page 3 Citrix ADC MPX Citrix ADC MPX 16000 Citrix ADC MPX 17500, MPX 19500, and MPX 21500 Citrix ADC MPX 17550, MPX 19550, MPX 20550, and MPX 21550 Citrix ADC MPX 22000 Citrix ADC MPX 24100 Citrix ADC MPX 25000A Citrix ADC MPX 25100T Citrix ADC MPX 25000TA Citrix ADC MPX 25000‑40G...
  • Page 4 Fortville NICs firmware upgrade on Citrix ADC MPX appliances Wiping your data before sending the ADC appliance to Citrix How to verify the file system integrity of your Citrix ADC MPX appliance Migrate the configuration of an existing Citrix ADC appliance to another Citrix ADC appliance212...

  • Page 5: Common Hardware Components

    On the MPX 22000 and MPX 24000 appliance back panel, system status LEDs indicate the overall status of the appliance. The following table describes the indicators of the system status LED. Note: System status LEDs are available on only some Citrix ADC appliances. LED Color LED Indicates No power.
  • Page 6 Citrix ADC MPX The port LEDs show whether a link is established and traffic is flowing through the port. The following table describes the LED indicators for each port. There are two LED indicators for each port type. Note: This section applies to all the appliances.
  • Page 7 Citrix ADC MPX Port Type LED Color LED Indicates Solid green Link is established but no traffic is passing through the port. Blinking green Traffic is passing through the port. Right Speed No connection. Yellow Traffic rate of 1 gigabit per second.
  • Page 8 Citrix ADC MPX Port Type LED Color LED Indicates Amber Traffic rate of 1 gigabit per second. Right Link/Activity No link. Solid yellow Link is established but no traffic is passing through the port. On each power supply, a bicolor LED indicator shows the condition of the power supply.
  • Page 9 Citrix ADC MPX Power Supply 450 W AC 450 W DC 1000 W AC 1000 W DC 1200 W AC LED behavior YM‑2451CAR YM‑2451DBR YM‑ YM‑ YM‑ when 2102NA01R 2102JA01R 2122CA01R No Power to any power supply No power to...
  • Page 10 Citrix ADC MPX Power Supply 450 W AC 450 W DC LED behavior when R1BA2451B‑GE9A R1B02451A No Power to any power supply No power to this power Flashing RED Flashing RED supply Power supply is in standby Flashing GREEN Flashing BLUE...
  • Page 11 Citrix ADC MPX Power Supply 960 W AC 960 W DC Power supply is functional GREEN GREEN (Power ON) Power supply failure ‑ ‑ Warning ‑ ‑ (OVP/UVP/OCP/OTP/Fan) Note Power Supply Unit ON‑Green Power Supply Unit OFF‑ No Color There is no other function other than ON or OFF for the module LEDs. A continuous beep sound occurs if a cable or module is unplugged.
  • Page 12 • 50 GB QSFP28 • 100 GB QSFP28 All Citrix ADC appliances have a combination of some or all of these ports. Cards might be vertical or horizontal depending on the platform. The number of ports per card varies across platforms. For better fault tolerance, create link aggregated groups (LAGs) on independent cards.
  • Page 13 Note Citrix ADC appliances use the Receive Side Scaling (RSS) feature to optimally distribute and pro‑ cess traffic. The RSS implementation is based on hashing which distributes the packet Toeplitz among its queues based on the 5‑tuple: TCP/IP protocol, source IP address, destination IP ad‑...
  • Page 14 Citrix ADC MPX 1G SFP and 10G SFP+ ports A 1G SFP port can operate at a speed of 1 Gbps. It accepts either a copper 1G SFP transceiver for operation as a copper Ethernet port, or a fiber 1G SFP transceiver for operation as a fiber optic port.
  • Page 15 Citrix ADC MPX © 1999 2023 Cloud Software Group, Inc. All rights reserved. –...
  • Page 16 Citrix ADC MPX © 1999 2023 Cloud Software Group, Inc. All rights reserved. –...
  • Page 17 Copper 1G SFP distance specifications Description: Citrix ADC 1G SFP Ethernet copper (100 m) ‑ 4 pack Transmitter wavelength (nm): Not applicable Cable type: Category 5 (Cat‑5) copper cable...
  • Page 18 Citrix ADC MPX Short reach fiber 1G SFP distance specifications Description: Citrix ADC 1G SFP Ethernet SX (300 m) ‑ 4 pack Transmitter wavelength (nm): 850 nm (nominal) Fiber type: 50/125um MMF, 2000MHz‑km (OM3) Typical Reach (m): 550 m Fiber type: 50/125um MMF, 500MHz‑km (OM2) Typical Reach (m): 550 m Fiber type: 50/125um MMF, 400MHz‑km...
  • Page 19 • MPX 22000 • MPX 24000 Long reach fiber 1G SFP distance specifications Description: Citrix ADC 1G SFP Ethernet long range (10 km) ‑ Single Transmitter wavelength (nm): 1310 nm (nominal) Fiber type: 9/125um SMF Typical reach (m): 10 km Applicable platforms: •...
  • Page 20 62.5/125um MMF, 26 m 160MHz‑km Long reach fiber 10G SFP+ distance specifications Description: Citrix ADC 10G SFP+ Ethernet long range (10 km) ‑ Single Transmitter wavelength (nm): 1310 nm (nominal) © 1999 2023 Cloud Software Group, Inc. All rights reserved.
  • Page 21 • MPX 26000‑100G (adapter required to connect 100G ports to 10G transceiver) Citrix direct‑attached (DAC) copper TwinAx 10G SFP+ passive cables specifications Description: Citrix ADC 1 m DAC SFP+ cable for up to 1 m distance Applicable platforms: • MPX 5901/5905/5910 •...
  • Page 22 Citrix ADC MPX • MPX 25000‑40G Description: Citrix ADC 3 m DAC SFP+ cable for up to 3 m distance Applicable platforms: • MPX 5901/5905/5910 • MPX 8005/8015/8200/8400/8600/8800 • MPX 8905/8910/8920/8930 • MPX 9100 • MPX 16000 • MPX 22000 •...

  • Page 23: Data Sheets

    Notes: • The peer switch must be 40G. You connect 4x10G ports on the Citrix ADC appliance. The reverse is not supported. That is, 40G on the Citrix ADC appliance and 4x10G on the peer switch is not supported. • To obtain these cables, contact Cisco partner representatives.
  • Page 24 Citrix ADC MPX IMPORTANT: The first supported build for each hardware platform and software release are listed in the following table. All subsequent builds are supported unless the word “only” follows the build number. When it does, only the specified build is supported on that platform.
  • Page 25 Citrix ADC MPX Hardware plat‑ forms/Software releases 11.1 12.1 13.0 13.1 MPX 14020‑ 11.1–47.14 12.1–48.13 13.0–36.27 13.1–4.x 40G/14040‑ 40G/14060‑ 40G/14080‑ 40G/14100‑40G MPX 14040‑ 11.1–47.14 12.1–48.13 13.0–36.27 13.1–4.x 40S/14060‑ 40S/14080‑ 40S/14100‑40S MPX 14030 11.1–51.21 12.1–48.13 13.0–36.27 13.1–4.x FIPS/14060 FIPS/14080 FIPS 11.1–60.13 12.1–50.31...

  • Page 26: Hardware Platforms

    The various Citrix ADC hardware platforms offer a wide range of features, communication ports, and processing capacities. All the MPX platforms have multicore processors. The Citrix ADC hardware platforms range from the single processor MPX 5500 platform to the high‑ capacity MPX 25100‑40G platforms and T1010/1100/1120/1200/1300 telco platforms. The various Cit‑...
  • Page 27 Citrix ADC MPX Note: This platform has reached its end of life. The Citrix ADC MPX 5500 is a 1U appliance, with 1 dual‑core processor, and 4 GB of memory. The following figure shows the front panel of the MPX 5500.

  • Page 28: Citrix Adc Mpx 5550 And Mpx 5650

    Citrix ADC MPX 5550 and MPX 5650 September 19, 2022 The the Citrix ADC models MPX 5550 and MPX 5650 are 1U appliances. Each model has 1 quad‑core processor and 8 GB of memory. The following figure shows the front panel of the MPX 5550/5650 appliance.

  • Page 29: Citrix Adc Mpx 5900

    • Non‑maskable interrupt (NMI) button, which is used at the request of Technical Support to pro‑ duce a Citrix ADC core dump. Use a pen, pencil, or other pointed object to press this red button, which is recessed to prevent unintentional activation.
  • Page 30 Citrix ADC MPX • Six 10/100/1000Base‑T RJ45 copper Ethernet Ports. • Two 10G/1G SFP+ Ethernet Ports. For information on the software releases supported on the Citrix ADC hardware platforms, see Hardware Software Release Matrix. The following figure shows the front panel of the MPX 5900 appliance.

  • Page 31: Citrix Adc Mpx 7500 And Mpx 9500

    September 19, 2022 Note: This platform has reached its end of life. The Citrix ADC MPX 7500/9500 are 1U appliances, each with 1 quad‑core processor, and 8 GB of mem‑ ory. The MPX 7500/9500 appliances are available in two port configurations: 8x10/100/1000Base‑T copper Ethernet ports and 4x1G SFP + 4x10/100/1000Base‑T copper Ethernet ports.
  • Page 32 The following figure shows the front panel of the MPX 7500/9500 (4x1G SFP + 4x10/100/1000Base‑T copper Ethernet ports) appliances. Figure 2. Citrix ADC MPX 7500/9500 (4x1G SFP + 4x10/100/1000Base‑T copper Ethernet ports), front panel Depending on the model, the appliance has the following ports: •...
  • Page 33 The following components are visible on the back panel of the MPX 7500 /9500: • 4 GB removable CompactFlash card that is used to store the Citrix ADC software. • Power switch, which turns off power to the MPX 7500/9500, as if you were to unplug the power supply.

  • Page 34: Citrix Adc Mpx 8005, Mpx 8015, Mpx 8200, Mpx 8400, Mpx 8600, And Mpx 8800

    Citrix ADC MPX Citrix ADC MPX 8005, MPX 8015, MPX 8200, MPX 8400, MPX 8600, and MPX 8800 September 19, 2022 The Citrix ADC models MPX 8005, MPX 8015, MPX 8200, MPX 8400, MPX 8600, and MPX 8800 are 1U appliances. Each model has one quad‑core processor and 32 GB of memory.
  • Page 35 • One 10/100Base‑T copper Ethernet Port (RJ45), also called LOM port. You can use this port to remotely monitor and manage the appliance independently of the Citrix ADC software. • One 10/100/1000Base‑T copper Ethernet management port (RJ45), numbered 0/1. The man‑...

  • Page 36: Citrix Adc Mpx 8900

    • Non‑maskable interrupt (NMI) button, which is used at the request of Technical Support to pro‑ duce a Citrix ADC core dump. Use a pen, pencil, or other pointed object to press this red button, which is recessed to prevent unintentional activation.
  • Page 37 Citrix ADC MPX For information on the software releases supported on the Citrix ADC hardware platforms, see Hardware‑Software Release Matrix. The following figure shows the front panel of the MPX 8900 series appliances. Figure 1. Citrix ADC MPX 8900, front panel The Citrix ADC MPX 8900 series appliances have the following ports: •...
  • Page 38 Citrix ADC MPX The following components are visible on the back panel of the MPX 8900 appliance: • One 240 GB or larger removable solid‑state drive (SSD). Note: Drive densities might increase as components become EOL but its size is never smaller than the original.

  • Page 39: Citrix Adc Mpx 8900 Fips Certified Appliance

    Citrix ADC MPX 8900 FIPS certified appliance September 19, 2022 The Citrix ADC MPX 8900 FIPS certified appliance is a 1U appliance. This platform has a single 8‑core processor and 32 GB of memory. Note: On all sides of the appliance, you see FIPS tamper seals. Tampering with the seals breaks the FIPS requirement.
  • Page 40 The following figure shows the back panel of the MPX 8900 FIPS certified appliance. Figure 2. Citrix ADC MPX 8900 FIPS certified appliance, back panel The following components are visible on the back panel of the MPX 8900 FIPS certified appliance: •...

  • Page 41: Citrix Adc Mpx 9100

    Citrix ADC MPX 9100 December 5, 2022 The Citrix ADC MPX 9100 appliance is a 1U appliance. This platform has a single 10‑core processor and 64 GB of memory. The appliance provides a total of eight 25G SFP28 ports. For information on the software releases supported on the ADC hardware platforms, see Hardware‑...
  • Page 42 The following figure shows the back panel of the MPX 9100 appliance. Figure 2. Citrix ADC MPX 9100, back panel The following components are visible on the back panel of the MPX 9100 appliance: • One 480 GB removable solid‑state drive (SSD).

  • Page 43: Citrix Adc Mpx 9700, Mpx 10500, Mpx 12500, And Mpx 15500

    Note: The non‑FIPS platform has reached its end of life. The Citrix ADC MPX 9700/10500/12500/15500 are 2U appliances, each with 2 quad‑core processors, and 16 GB of memory. All these appliances are also available in a 10G model and a FIPS model.
  • Page 44 Citrix ADC MPX The following figure shows the front panel of the MPX 9700/10500/12500/15500 10G. Figure 2. Citrix ADC MPX 9700/10500/12500/15500 10G, front panel The following figure shows the front panel of the MPX 9700/10500/12500/15500 FIPS. Figure 3. Citrix ADC MPX 9700/10500/12500/15500 FIPS, front panel *The FIPS Management Port (Level 3 Mode) is reserved for a future release.
  • Page 45 10G model and FIPS model: • Four GB removable CompactFlash Card that is used to store the Citrix ADC software. • Power Switch, which turns off power to the appliance, as if you were to unplug the power supply.

  • Page 46: Citrix Adc Mpx 11500, Mpx 13500, Mpx 14500, Mpx 16500, Mpx 18500, And Mpx 20500

    For information about performing the initial configuration of your appliance, see “Initial Configura‑ tion.” Citrix ADC MPX 11500, MPX 13500, MPX 14500, MPX 16500, MPX 18500, and MPX 20500 September 19, 2022 Note: This platform has reached its end of life.
  • Page 47 • 10/100Base‑T copper Ethernet Port (RJ45), also called LOM port. You can use this port to re‑ motely monitor and manage the appliance independently of the Citrix ADC software. Note: The LEDs on the LOM port are not operational by design.

  • Page 48: Citrix Adc Mpx 11500

    Hardware. For information about performing the initial configuration of your appliance, see Initial Configuration. Citrix ADC MPX 11500 September 19, 2022 The Citrix ADC models MPX 11515/11520/11530/11540/11542 are 2U appliances. Each model has two 6‑core processors for a total of 12 physical cores (24 cores with hyper‑threading), and 48 GB of memory. The following figure shows the front panel of the MPX 11515/11520/11530/11540/11542 appliance.
  • Page 49 • 10/100Base‑T copper Ethernet Port (RJ45), also called LOM port. You can use this port to re‑ motely monitor and manage the appliance independently of the Citrix ADC software. Note: The LEDs on the LOM port are not operational by design.

  • Page 50: Citrix Adc Mpx 14000

    The Citrix ADC MPX 14020/14030/14040/14060/14080/14100 are 2U appliances. Each model has two 6‑core processors and 64 GB of memory and sixteen 10G SFP+ ports (16x10G SFP+). For information about the software releases supported on the Citrix ADC hardware platforms, see Cit‑...
  • Page 51 • 10/100Base‑T copper Ethernet Port (RJ45), also called the LOM port. You can use this port to remotely monitor and manage the appliance independently of the Citrix ADC software. • Two 10/100/1000Base‑T copper Ethernet Management Ports (RJ45), numbered 0/1and 0/2 from left to right.
  • Page 52 Citrix ADC MPX The following components are visible on the back panel of the MPX 14020/14030/14040/14060/14080/14100 appliance: • Two 240 GB or larger removable solid‑state drives in a redundant array of independent disks (RAID) configuration. In a RAID configuration, the same data is stored on multiple drives to im‑...

  • Page 53: Citrix Adc Mpx 14000-40C

    Citrix ADC MPX 14000‑40C September 19, 2022 The Citrix ADC MPX 14000‑40C are 2U appliances. Each model has 2 six‑core processors, 64 GB of memory, and sixteen 10G SFP+ ports. The following figure shows the front panel of the 14000‑40C appliance.
  • Page 54 Citrix ADC MPX The following components are visible on the back panel of the MPX 14000‑40C appliances: • Two 300 GB or larger removable solid‑state drives in a redundant array of independent disks (RAID) devices. In a RAID configuration, the same data is stored on multiple drives to improve performance, increase storage capacity, lower the risk of data loss, and provide fault tolerance.

  • Page 55: Citrix Adc Mpx 14000-40G

    Citrix ADC MPX 14000‑40G September 19, 2022 The Citrix ADC MPX 14020‑40G, MPX 14040‑40G, MPX 14060‑40G, MPX 14080‑40G, MPX 14100‑40G are 2U appliances. Each model has two 6‑core processors, 64 GB of memory, four 40G QSFP+ ports, and sixteen 10G SFP+ ports (4x40G QSFP+ + 16x10G SFP+).
  • Page 56 • 40G ports do not support 10G and 1G transceivers. The following figure shows the back panel of the 14000‑40G appliance. Figure 2. Citrix ADC MPX 14020/14040/14060/14080/14100‑40G (4x40G QSFP+, 16x10G SFP+), back panel The following components are visible on the back panel of the MPX 14000‑40G appliance: •...

  • Page 57: Citrix Adc Mpx 14000-40S

    Citrix ADC MPX 14000‑40S September 22, 2022 The Citrix ADC MPX 14040‑40S, MPX 14060‑40S, MPX 14080‑40S, MPX 14100‑40S are 2U appliances. Each model has two 6‑core processors, 64 GB of memory, four 40G QSFP+ ports, and eight 10G SFP+ ports.
  • Page 58 Citrix ADC MPX The following figure shows the back panel of the 14000‑40S appliance. Figure 2. Citrix ADC MPX 14020/14040/14060/14080/14100‑40S (4x40G QSFP+, 8x10G SFP+), back panel The following components are visible on the back panel of the MPX 14000‑40S appliance: •...

  • Page 59: Citrix Adc Mpx 14000 Fips

    MPX 14000 FIPS appliance topic. The Citrix ADC models MPX 14030 FIPS, MPX 14060 FIPS, and MPX 14080 FIPS are 2U appliances. Each model has two 6‑core processors, 64 GB of memory, sixteen 10G SFP+ ports (16x10G SFP+).
  • Page 60 • 40G ports do not support 10G and 1G transceivers. The following figure shows the back panel of the MPX 14030/14060/14080 FIPS appliances. Figure 2. Citrix ADC MPX 14030/14060/14080 FIPS appliance, back panel The following components are visible on the back panel of the MPX 14000 FIPS appliance: •...

  • Page 61: Citrix Adc Mpx 15000

    Citrix ADC MPX 15000 September 19, 2022 The Citrix ADC MPX 15000 appliance is a 2U appliance. This platform has two 8‑core processors and 128 GB of memory. The appliance provides a total of 16 Ethernet 25G ports. For information on the software releases supported on the Citrix ADC hardware platforms, see Hardware‑Software Release...
  • Page 62 Citrix ADC MPX The following figure shows the back panel of the MPX 15000 appliance. Figure 2. Citrix ADC MPX 15000, back panel The following components are visible on the back panel of the MPX 15000 appliance: • Two 480 GB or larger removable solid‑state drives in a redundant array of independent disks (RAID) configuration.

  • Page 63: Citrix Adc Mpx 15000-50G

    Citrix ADC MPX 15000‑50G September 19, 2022 The Citrix ADC MPX 15000‑50G appliance is a 2U appliance. This platform has two 8‑core processors and 128 GB of memory. The MPX 15000‑50G appliance provides a total of 12 network ports: • Eight 10G SFP+ Ethernet Ports •...
  • Page 64 • Four 50G ports, numbered 50/1 to 50/4. For information about supported transceivers per port, 25G, 40G, 50G, and 100G ports. The following figure shows the back panel of the Citrix ADC MPX 15000‑50G appliance. Figure 2. Citrix ADC MPX 15000‑50G, back panel © 1999 2023 Cloud Software Group, Inc.
  • Page 65 Citrix ADC MPX The following components are visible on the back panel of the MPX 15000‑50G appliances: • Two 480 GB or larger removable solid‑state drives in a redundant array of independent disks (RAID) configuration. In a RAID configuration, the same data is stored on multiple drives to im‑...

  • Page 66: Citrix Adc Mpx 15000-50G Fips Certified Appliance

    Citrix ADC MPX 15000‑50G FIPS certified appliance September 19, 2022 The Citrix ADC MPX 15000‑50G FIPS certified appliance is a 2U appliance. This platform has two 8‑core processors and 128 GB of memory. Note: There are FIPS tamper seals on all sides of the appliance. Tampering with the seals breaks the FIPS requirement.
  • Page 67 • Four 50G ports, numbered 50/1 to 50/4. For information about supported transceivers per port, 25G, 40G, 50G, and 100G ports. The following figure shows the back panel of the Citrix ADC MPX 15000‑50G FIPS certified appliance. Figure 2. Citrix ADC MPX 15000‑50G FIPS certified appliance, back panel © 1999 2023 Cloud Software Group, Inc.
  • Page 68 Citrix ADC MPX The following components are visible on the back panel of the MPX 15000‑50G FIPS certified appliance: • Two 480 GB or larger removable solid‑state drives in a redundant array of independent disks (RAID) configuration. In a RAID configuration, the same data is stored on multiple drives to im‑...

  • Page 69: Citrix Adc Mpx 16000

    December 5, 2022 The Citrix ADC MPX 16000 appliance is a 2U appliance. This platform has two 16‑core processors and 128 GB (16 x 8 GB DIMM) of memory. The appliance provides a total of eight 25G SFP28 ports and four 100G QSFP28 Ethernet ports.
  • Page 70 Citrix ADC MPX The Citrix ADC MPX 16000 series appliances have the following ports: • RS232 serial Console port. • One 10/100/1000Base‑T RJ45 copper Ethernet LOM port. Use this port to remotely monitor and manage the appliance independently of the ADC software.
  • Page 71 Citrix ADC MPX The following components are visible on the back panel of the MPX 16000 appliance: • Two 960 GB removable solid‑state drives (SSD). Note: Drive densities might increase as components become EOL but its size is never smaller than the original.

  • Page 72: Citrix Adc Mpx 17500, Mpx 19500, And Mpx 21500

    September 19, 2022 Note: This platform has reached its end of life. The Citrix ADC models MPX 17500/19500/21500 are 2U appliances. Each model has two 6‑core proces‑ sors and 48 GB of memory. The following figure shows the front panel of the MPX 17500/19500/21500 appliance.
  • Page 73 Citrix ADC MPX The following components are visible on the back panel of the MPX 17500/19500/21500 appliance: • 160 GB or larger removable solid‑state drive. Note: Drive densities might increase as components become EOL but its size is never smaller than the original.

  • Page 74: Citrix Adc Mpx 17550, Mpx 19550, Mpx 20550, And Mpx 21550

    Note: This platform has reached its end of life. The Citrix ADC models MPX 17550, MPX 19550, MPX 20550, and MPX 21550 are 2U appliances. Each model has two 6‑core processors for a total of 12 physical cores (24 cores with hyper‑threading), and 96 GB of memory.
  • Page 75 The following components are visible on the back panel of the MPX 17550/19550/20550/21550 appli‑ ance: • 160 GB or larger removable solid‑state drive that is used to store the Citrix ADC software. Note: Drive densities might increase as components become EOL but its size is never smaller than the original.

  • Page 76: Citrix Adc Mpx 22000

    The following figure shows the front panel of the MPX 22040/22060/22080/22100/22120 (12x1G SFP + 24x10G SFP+) appliance. Figure 1. Citrix ADC MPX 22040/22060/22080/22100/22120 (12x1G SFP + 24x10G SFP+), front panel The following figure shows the front panel of the MPX 22040/22060/22080/22100/22120 (24x10G SFP+) appliance.
  • Page 77 • 10/100Base‑T copper Ethernet Port (RJ45), also called the LOM port. You can use this port to remotely monitor and manage the appliance independently of the Citrix ADC software. • Two 10/100/1000Base‑T copper Ethernet Management Ports (RJ45), numbered 0/1 and 0/2 from left to right.
  • Page 78 Citrix ADC MPX The following components are visible on the back panel of the MPX 22040/22060/22080/22100/22120 appliance: • Non‑maskable interrupt (NMI) Button, used at the request of Technical Support to initiate a core dump. To press this red button, which is recessed to prevent unintentional activation, use a pen, pencil, or other pointed object.

  • Page 79: Citrix Adc Mpx 24100

    Citrix ADC MPX 24100 September 19, 2022 The Citrix ADC MPX 24100/24150 are 2U appliances. Each model has two 8‑core processors and 256 GB of memory. The MPX 24100/24150 appliances are available in the twelve 1G SFP ports and twenty‑four 10G SFP+ ports (12x1G SFP + 24x10G SFP+) configuration.
  • Page 80 Citrix ADC MPX The following components are visible on the back panel of the MPX 24xxx appliances: • Non‑maskable interrupt (NMI) Button, used at the request of Technical Support to initiate a core dump. To press this red button, which is recessed to prevent unintentional activation, use a pen, pencil, or other pointed object.

  • Page 81: Citrix Adc Mpx 25000A

    Citrix ADC MPX 25000A September 22, 2022 The Citrix ADC MPX 25100A, MPX 25160A, and MPX 25200A are 2U appliances. Each model has two eight‑core processors, 256 GB of memory, eight 40G QSFP+ ports (8x40G QSFP+). The front panel of the MPX 25100A, MPX 25160A, and MPX 25200A appliances has a (8x40G QSFP+) port configuration.
  • Page 82 The NMI Button is also available remotely over the network in the LOM GUI, in the Remote Control menu. For more information about the lights out management port of the appliance, see Lights out management port of the Citrix ADC appliance. © 1999 2023 Cloud Software Group, Inc.

  • Page 83: Citrix Adc Mpx 25100T

    Citrix ADC MPX 25100T September 19, 2022 The Citrix ADC MPX 25100T and 25160T are 2U appliances. Each model has two 10‑core processors and 128 GB of memory. The MPX 25100T/25160T appliances are available in the thirty‑two 10G SFP+ ports (32x10G SFP+) configuration.
  • Page 84 LOM GUI, in the Remote Control menu. For more information about the lights out manage‑ ment port of the appliance, see Lights out management port of the Citrix ADC MPX appliance. For information about installing the rails, rack mounting the hardware, and connecting the cables, Installing the Hardware.

  • Page 85: Citrix Adc Mpx 25000Ta

    Citrix ADC MPX 25000TA September 19, 2022 The Citrix ADC MPX 25100TA, MPX 25160TA, and MPX 25200TA are 2U appliances. Each model has two 8‑core processors, 128 GB of memory, 8X40GE (QSFP+) ports. The front panel of the MPX 25100TA, MPX 25160TA, and MPX 25200TA have (8X40GE QSFP+) ports.
  • Page 86 Citrix ADC MPX The following components are visible on the back panel of the MPX 25100TA, MPX 25160TA, and MPX 25200TA appliance: • One 300 GB or larger removable solid‑state drives in a redundant array of independent disks (RAID) devices. In a RAID configuration, the same data is stored on multiple drives to improve performance, increase storage capacity, lower the risk of data loss, and provide fault tolerance.

  • Page 87: Citrix Adc Mpx 25000-40G

    Citrix ADC MPX 25000‑40G September 22, 2022 The Citrix ADC MPX 25000‑40G are 2U appliances. Each model has two 10‑core processors, 256 GB of memory, four 40G QSFP+ ports, and sixteen 10G SFP+ ports (4x40G QSFP+ 16x10G SFP+). The following figure shows the front panel of the MPX 25100/MPX 25160/25200 40G appliances.
  • Page 88 – One power supply is malfunctioning and you want to continue operating the appliance until it is repaired. For more information, see Lights out management port of the Citrix ADC MPX appliance topic. © 1999 2023 Cloud Software Group, Inc. All rights reserved.

  • Page 89: Citrix Adc Mpx 26000

    Citrix ADC MPX 26000 September 19, 2022 The Citrix ADC MPX 26100/26160/26200 appliances are 2U appliances. These appliances have two 14‑ core processors and 256 GB of memory. The appliance has eight 50G and sixteen 25G network ports. For information about the software releases supported on the Citrix ADC hardware platforms, see Cit‑...
  • Page 90 Figure 2. Citrix ADC MPX 26000, back panel The following components are visible on the back panel of the Citrix ADC MPX 26000 appliances: • Two 480 GB or larger removable solid‑state drives in a redundant array of independent disks (RAID) configuration.

  • Page 91: Citrix Adc Mpx 26000-50S

    Citrix ADC MPX 26000‑50S September 19, 2022 The Citrix ADC MPX 26000‑50S appliances are 2U appliances. These appliances have two 14‑core pro‑ cessors and 256 GB of memory. The appliances have four 50G and 16 25G network ports. For information about the software releases supported on the Citrix ADC hardware platforms, see Cit‑...
  • Page 92 The following figure shows the back panel of the MPX 26000‑50S appliances. Figure 2. Citrix ADC MPX 26000‑50S, back panel The following components are visible on the back panel of the Citrix ADC MPX 26000‑50S appliances: © 1999 2023 Cloud Software Group, Inc. All rights reserved.
  • Page 93 The NMI Button is also available remotely over the network in the LOM GUI, in the Remote Control menu. For more information about the lights out manage‑ ment port of the appliance, see Lights out management port of the Citrix ADC MPX appliance. © 1999 2023 Cloud Software Group, Inc.

  • Page 94: Citrix Adc Mpx 26000-100G

    Cit‑ rix ADC MPX hardware software compatibility matrix. The following figure shows the front panel of the Citrix ADC MPX 26000‑100G and Citrix ADC MPX 26000T‑100G appliances. Figure 1. Citrix ADC MPX 26000‑100G and Citrix ADC MPX 26000T‑100G, front panel The Citrix ADC MPX 26000‑100G and Citrix ADC MPX 26000T‑100G appliances have the following ports:...
  • Page 95 DAC and AoCs. To support native 10G and 25G transceivers, DAC and AoCs, use an SFP+ to QSFP+ adapter. The following figure shows the back panel of the Citrix ADC MPX 26000‑100G and Citrix ADC MPX 26000T‑100G appliances. Figure 2. Citrix ADC MPX 26000‑100G and Citrix ADC MPX 26000T‑100G, back panel The following components are visible on the back panel of the Citrix ADC MPX 26000‑100G and Citrix...

  • Page 96: Citrix Adc T1010

    Citrix ADC T1010 August 18, 2020 The Citrix ADC T1010 is a 1U appliance, with a single‑core processor, and 32 GB of memory. The following figure shows the front panel of the T1010 appliance. Figure 1. Citrix ADC T1010 front panel ©...
  • Page 97 • Non‑maskable interrupt (NMI) button, which is used at the request of Technical Support to pro‑ duce a Citrix ADC core dump. Use a pen, pencil, or other pointed object to press this red button, which is recessed to prevent unintentional activation.

  • Page 98: Citrix Adc T1100

    Citrix ADC T1100 August 18, 2020 The Citrix ADC T1100 is a 2U appliance, with 1 dual‑core processor, and 42 GB memory. The following figure shows the front panels of the two models T1100 appliance, T1100 (Gen1) and T1100 (16).
  • Page 99 • One 10/100BASE‑T, RJ‑45 LOM ports The following figure shows the back panel of the T1100. Figure 2. Citrix ADC T1100 back panel The following components are visible on the back panel of the T1100: • USB port (reserved for a future release).

  • Page 100: Citrix Adc T1120

    Citrix ADC T1120 August 19, 2020 The Citrix ADC T1120 appliance is a 2U appliance, with a dual‑core processor and 128 GB memory. The following figure shows the front panel of the T1120 appliance. Figure 1. Citrix ADC T1120 appliance front panel The T1120 appliance has the following ports: •...

  • Page 101: Citrix Adc T1200

    • One 10/100BASE‑T RJ‑45 LOM port The following figure shows the back panel of the T1120 appliance. Figure 2. Citrix ADC T1120 back panel The following components are visible on the back panel of the T1120 appliance: • 240 GB removable solid‑state drive.
  • Page 102 Citrix ADC MPX The Citrix ADC T1200 is a 2U appliance, with a dual‑core processor and 256 GB memory. The following figure shows the front panel of the T1200 appliance. Figure 1. Citrix ADC T1200 front panel The T1200 appliance has the following ports: •...

  • Page 103: Citrix Adc T1300

    Citrix ADC T1300 August 19, 2020 The Citrix ADC T1300 is a 2U appliance, with a dual‑core processor and 128 GB memory. The following figure shows the front panels of the T1300‑10GE and T1300‑40GE appliances. Figure 1. Citrix ADC T1300‑10GE and T1300‑40GE front panels ©...
  • Page 104 • 16 10GBASE‑X SFP+ data plane ports (T1300‑40GE) The following figure shows the back panel of the T1300 appliance. Figure 2. Citrix ADC T1300 back panel The following components are visible on the back panel of the T1300 appliance: © 1999 2023 Cloud Software Group, Inc.

  • Page 105: Citrix Adc T1310

    Citrix ADC T1310 August 19, 2020 The Citrix ADC T1310 is a 2U appliance. It has two 10‑core processors and 256 GB memory. The T1310 appliance is available in the eight 40G QSFP+ ports (8x40G QSFP+) configuration. Note: The T1310 appliance is not a RAID device.
  • Page 106 • 10/100Base‑T copper Ethernet Port (RJ45), also called the LOM port. You can use this port to remotely monitor and manage the appliance independently of the Citrix ADC software. • Two 10/100/1000Base‑T copper Ethernet Management Ports (RJ45), numbered 0/1 and 0/2 from left to right.

  • Page 107: Citrix Web App Firewall Platforms

    For information about performing the initial configuration of your appliance, see Initial Configuration. Citrix Web App Firewall platforms August 18, 2020 For information about the Citrix Web App Firewall platforms, see the Data sheet. Field replaceable units September 19, 2022 ©...
  • Page 108 Citrix ADC MPX Citrix ADC field replaceable units (FRU) are ADC components that a user or a technician can replace at the user’s site. The FRUs for a Citrix ADC appliance include DC or AC power supplies, solid‑state (SSD) or hard‑disk drives (HDD), direct attach cable (DAC), and the bezel of the appliance.
  • Page 109 Note The illustration in the following figures might not represent the actual Citrix ADC appliance. Figure 1. Remove the existing AC power supply 2. Carefully remove the new power supply from its box.
  • Page 110 Replace a DC power supply Most Citrix ADC MPX platforms can accommodate two power supplies. Some platforms can accom‑ modate four power supplies. All Citrix ADC appliances function properly with a single power supply, except the appliances that can accommodate four power supplies.
  • Page 111 (ns.conf), licenses, and for some models, the Citrix ADC software and the user data. All MPX platforms store the Citrix ADC software on the SSD. The SSD is mounted as /flash. Note On the MPX 5550/5650 and MPX 8005/8015/8200/8400/8600/8800 appliances, both /flash and /var are mounted from different partitions of the same SSD drive.
  • Page 112 Citrix ADC MPX sh raid <!--NeedCopy--> Output: RAID1 status: READY Drive: ONLINE ONLINE Done <!--NeedCopy--> If both the SSDs’ show ONLINE and the RAID status shows READY, no action is required. In the following table, the values in the first column show the drive number on the back panel of the appliance.
  • Page 113 From the shell, confirm that drive 1/SSD 2 has failed, RAID status reports DEGRADED and drive 1/SSD 2 reports MISSING, or not present in the output. 1. At the Citrix ADC command prompt, switch to the shell prompt. Type: shell 2.
  • Page 114 5. Start the rebuild process. 6. Monitor the rebuild process. 7. Verify that the rebuild is successful. 8. Exit the bash shell and verify from the Citrix ADC CLI. Example when SSD 2 fails In the following example, SSD 2/drive 1/ata3 has failed.
  • Page 115 ONLINE <!--NeedCopy--> Note: After the rebuild operation completes, the subdisks status shows ONLINE, and the RAID status shows READY. 9. Exit the shell and verify the status of the RAID array from the Citrix ADC CLI. root@ns# exit >sh raid <!--NeedCopy-->...
  • Page 116 Citrix ADC MPX ONLINE Done <!--NeedCopy--> Example when SSD 1 fails In the following example, SSD 1/drive 0/ata2 has failed. 1. Detach a failed drive. root@ns# atacontrol detach ata2 <!--NeedCopy--> 2. Physically, remove SSD 1/drive 0 and replace it with a new FRU drive in slot 1.
  • Page 117 ONLINE <!--NeedCopy--> Note: After the rebuild operation completes, the subdisks status shows ONLINE, and the RAID status shows READY. 9. Exit the shell and verify the status of the RAID array from the Citrix ADC CLI. root@ns# exit >sh raid <!--NeedCopy-->...
  • Page 118 Important: When you insert the drive, make sure that the Citrix product label is at the top if the drive is inserted horizontally. The label must be at the right if the drive is inserted vertically.
  • Page 119 Citrix ADC MPX Figure 5. Insert the replacement solid‑state drive 6. Turn on the Citrix ADC appliance. When the appliance starts, it no longer has the previous work‑ ing configuration. Therefore, the appliance is reachable only through the default IP address of 192.168.100.1/16, or through the console port.
  • Page 120 3. Locate the hard disk drive on the back panel of the appliance. 4. Verify that the replacement hard disk drive is the correct type for the Citrix ADC platform. 5. Disengage the hard disk drive by pushing the safety latch of the drive cover to the right or down, depending on the platform, while pulling out on the drive handle.
  • Page 121 (SFP+ transceivers and fiber optic cables.) The transceiver with DAC is hot‑swappable. You can insert and remove the transceiver with the at‑ tached cable without shutting down the appliance. The Citrix ADC appliance supports only a passive DAC. Important: •...
  • Page 122 Citrix ADC MPX Bezel The bezel of a Citrix ADC appliance is now available as a FRU and can be replaced in the field. Note The bezel FRU is supported only on the MPX/SDX 9100 platform. To replace the bezel 1.
  • Page 123 Citrix ADC MPX Figure 2: Replacing the 1U bezel © 1999 2023 Cloud Software Group, Inc. All rights reserved. –...

  • Page 124: Safety, Cautions, Warnings, And Other Information

    Note: For the list of safety certifications, standards, and ROHS compliance for each model, see the data sheet. The data sheet is available on www.citrix.com. Click Products, and in the Workspace and App Delivery list, select Citrix ADC. In Platforms, select Physical Appliances, and then click Citrix ADC MPX/SDX data sheet.
  • Page 125 Citrix ADC MPX To avoid a shock hazard: • Do not connect or disconnect any cables or perform installation, maintenance, or reconfigura‑ tion of this product during an electrical storm. • Connect all power cords to a properly wired and grounded electrical outlet.
  • Page 126 See the information that is provided with your device for electrical specifications. Statement 5 (applies to Citrix appliances with ‑48 VDC input): Caution: This equipment is designed to permit the connection between the earthed conductor of the DC supply circuit and the earthing conductor at the equipment.
  • Page 127 Citrix ADC MPX • Switching or disconnecting devices must not be in the earthed circuit conductor between the DC source and the point of connection of the earthing electrode conductor. Statement 6: Caution: To reduce the risk of electric shock or energy hazards: •...
  • Page 128 Citrix ADC MPX Fiber optic safety information Danger: Hazardous Radiation Fiber optic products use laser radiation with the potential to cause injury. Uncovered ports might release this radiation. Avoid direct exposure to laser radiation. Do not stare into the beam, and do not view directly with optical instruments.
  • Page 129 Citrix ADC MPX • Always disconnect the appliance from power before removing or installing any component, un‑ less the component is hot‑swappable. When disconnecting power, first shut down the appli‑ ance, and then unplug the power cords of all the power supply units connected to the appli‑...

  • Page 130: Taiwan Bsmi Rohs Statement

    Use the rack‑rail hardware, described later, instead. Taiwan BSMI RoHS statement September 19, 2022 The following tables are a declaration of the presence condition of restricted substances in Citrix ADC MPX and SDX hardware appliances. © 1999 2023 Cloud Software Group, Inc. All rights reserved.
  • Page 131 Citrix ADC MPX © 1999 2023 Cloud Software Group, Inc. All rights reserved. –...

  • Page 132: Fcc Compliance Statement

    Citrix ADC MPX FCC compliance statement September 19, 2022 Supplier’s declaration of conformity The FCC Compliance Statements listed on this page apply to all Citrix ADC MPX and SDX hardware models. Responsible Party – U.S. Contact Information: © 1999 2023 Cloud Software Group, Inc. All rights reserved.

  • Page 133: Prepare For Installation

    Citrix ADC MPX Citrix Systems, Inc. 4988 Great America Parkway Santa Clara, CA 95054 USA compliance.prime@citrix.com This device complies with part 15 of the FCC Rules. Operation is subject to the following two con‑ ditions: (1) This device might not cause harmful interference, and (2) this device must accept any interference received, including interference that might cause undesired operation.
  • Page 134 Note Make sure that a power outlet is available for each cable. If the kit that you received does not fit your rack, contact your Citrix sales representative to order the appropriate kit. Transceiver modules are sold separately. Contact your Citrix sales representative to order transceiver modules for your appliance.

  • Page 135: Install The Hardware

    Citrix ADC MPX Rack requirements The rack on which you install your appliance must meet the following criteria: • Rack characteristics: Racks must be either integrated into a purpose‑designed server cabinet or be the floor‑to‑ ceiling type, bolted down at both top and bottom to ensure stability. If you have a cabinet, it must be installed perpendicular to a load‑bearing wall for stability and sufficient airflow.
  • Page 136 Citrix ADC MPX Watch this quick video about How to rack mount a Citrix ADC hardware appliance. Mount the appliance on a rack Most appliances can be installed in standard server racks that conform to the EIA‑310‑D specification. The appliances ship with a set of rails, which you must install before you mount the appliance. The only tools that you need for installing an appliance are a Phillips screwdriver and a flathead screw‑...
  • Page 137 Citrix ADC MPX Install the rack rails on the rack 1. If you have a round‑hole, threaded rack, skip to step 3. 2. Install square nut retainers into the front post and back post of the rack as shown in the following figures.
  • Page 138 Citrix ADC MPX Figure 4. Install the rail assembly to the rack (1)‑For round‑hole threaded racks, remove the stud, and discard. Secure the rail to the rack by using the flat head screws that were holding the studs in place. For square‑hole and round‑hole non‑threaded racks, insert studs into the hole in the rear of the rack.
  • Page 139 (AOC). Native 10G and 25G transceivers are supported on appliances that do not have 10G and 25G ports, but require the use of an SFP+ to QSFP+ adapter. Contact your Citrix representative to purchase this adapter.
  • Page 140 Citrix ADC MPX Citrix ADC appliances do not support transceivers from vendors other than Citrix Systems. At‑ tempting to install third‑party transceivers on your Citrix ADC appliance voids the warranty. Do not install the transceivers with the cables attached. Doing so can damage the cable, the connector, or the optical interface of the transceiver.
  • Page 141 Citrix ADC MPX 5. Verify that the LED is green and blinks twice, which indicates that the transceiver is functioning correctly. 6. If you are using a fiber transceiver, do not remove the dust caps attached to the transceiver and the cable until you are ready to insert the cable.
  • Page 142 Citrix ADC MPX 1. Insert the RJ‑45 connector on the Ethernet cable into an appropriate port on the front panel of the appliance, as shown in the following figure. Figure 8. Insert an Ethernet cable 2. Insert the RJ‑45 connector on the other end into the target device, such as a router or switch.
  • Page 143 2. If your appliance has more than one power supply, repeat this process. The additional power supply is a redundant, hot‑swappable power supply. 3. The Citrix logo and the LCD on the front of the appliance illuminate after the appliance starts, and the LCD indicates the operational status of the appliance.

  • Page 144: Initial Configuration

    Once the initial configuration is complete, refer to the specific configuration guides for the features you are using. Initial configuration is the same for the multifunction Citrix ADC, Citrix Gateway, and the dedicated © 1999 2023 Cloud Software Group, Inc. All rights reserved.
  • Page 145 Using the first‑time setup wizard To configure a Citrix ADC appliance (or Citrix ADC virtual appliance) for the first time, you need an administrative computer configured on the same network as the appliance. Assign a Citrix ADC IP (NSIP) address as the management IP address of your Citrix ADC appliance. You access the appliance for configuration, monitoring, and other management tasks at this address.
  • Page 146 The serial number bar code is available at the back of the appliance. Citrix recommends that you change the password after the first logon. For information about changing the password, see Change the administrative password.
  • Page 147 The subnet mask is associated with both the NSIP and default gateway IP address. The NSIP is the IPv4 address of the Citrix ADC appliance. The default gateway is the IPv4 address for the router, which handles the external IP traffic that the appliance cannot otherwise route. The NSIP ad‑...
  • Page 148 Note: To prevent an attacker from breaching your ability to send packets to the appliance, choose a non‑routable IP address on your organization’s LAN as your appliance IP address. You can replace steps 5 and 6 with the following commands. At the Citrix ADC command prompt, type: set ns config -ipaddress<IPAddress>...
  • Page 149 To use DHCP, you must first specify the appliance vendor class identifier on a DHCP server. Optionally, you can also specify the pool of IP addresses from which your Citrix ADC appliance can acquire an IP address. If a pool is not specified, the address is acquired from the general pool.
  • Page 150 DHCP server. dhcpd manpage 1. If you do not want Citrix ADC appliances to use IP addresses from the general pool, specify a pool of addresses for the appliance. Include this pool declaration inside the subnet declaration. For example, adding the following configuration to the dhcpd.conf file specifies a pool of IP addresses ranging from 192.168.2.120 to 192.168.2.127.
  • Page 151 IPv4 and select Define Vendor ..citrix-Ns Classes. Add a new class by specifying a display name, description, and “.citrix‑NS” as the ASCII value. Click OK. 4. Create a scope to configure IP range, subnetwork, DNS server, WIN server, default Gateway, and excluded IP address range.
  • Page 152 Alternatively, restarting the appliance automatically releases the DHCP IP address back to the server pool. You can find out the SNIP address assigned to the appliance from the Citrix ADC console or from the DHCP server.
  • Page 153 The following table describes DHCP‑related CLI commands that you might want to use when config‑ uring a new Citrix ADC appliance. Table 2. Citrix ADC CLI commands for using DHCP with a new Citrix ADC appliance Task At the command prompt, type: To verify the DHCP fetched details, such as IP >...
  • Page 154 Using DHCP when a configuration file is present If you need to move a Citrix ADC appliance to a different subnet, you can use DHCP to access an ap‑ pliance that already has a configuration file. Before moving the appliance, enable its DHCP client and save the configuration.
  • Page 155 4. Press ENTER two times when prompted for a passphrase. Note: If the client is a Citrix ADC appliance, move the private key file to a persistent location such as the subdirectories of the /flash and /var directories.
  • Page 156 Optionally, remove the public key. root@ns## rm id_rsa.pub 7. On the client, verify that you can connect to the remote Citrix ADC appliance by using SSH, with‑ out entering the password. If using the default file name for the public‑private key pair.

  • Page 157: Lights Out Management Port Of The Citrix Adc Mpx Appliance

    Lights out management port of the Citrix ADC MPX appliance October 18, 2022 Some Citrix ADC appliances have an Intelligent Platform Management Interface (IPMI), also known as the lights out management (LOM) port, on the front panel of the appliance. You can use the LOM port to remotely monitor and manage the appliance, independently of the Citrix ADC software.
  • Page 158 • Power control operations • Factory reset • Enable or disable RAKP Different Citrix appliances support different shells: • For FreeBSD based Citrix ADC MPX appliances, use the shell (also known as NS bash nsroot Shell). • For Linux based appliances, use the Linux bash root shell.

  • Page 159: Configure The Network Settings On The Lom Port

    Citrix ADC MPX and CloudBridge/SDX (dom0) appliances for initial LOM port network con‑ figuration. When using the shell, you can choose to use DHCP or static IP settings for initial network configuration. After configuring the network settings, you can use the...
  • Page 160 1. In a web browser, type http://192.168.1.3 and enter the default user credentials. Note: The Citrix ADC LOM port is preconfigured with IP address 192.168.1.3 and subnet mask 255.255.255.0. 2. On the Configuration tab, click Network and type new values for the following parameters: •...
  • Page 161 – Obtain health monitoring information There are two ADC MIBs: the Citrix ADC software management MIB and the ADC IPMI LOM hardware management MIB. The software management MIB is primarily used for monitoring the application software and the application software’s utilization of hardware resources, such as CPU % and mem‑...
  • Page 162 The ADC MIB has a small subset of hardware sensors. It does not cover any BIOS level failures, because the BIOS checks the hardware primarily during boot time, before the Citrix ADC software starts. If the BIOS detects a failure, it does not load the boot loader. If the boot loader does not load, the operating system does not load, and therefore the ADC SNMP software service responsible for sending the traps does not load.
  • Page 163 You can configure SNMP alerts on the LOM. Optionally, you can configure an alert to send emails. To configure the alerts, you can use the LOM GUI or the Citrix ADC shell. Configure SNMP alerts on the LOM by using the GUI 1.

  • Page 164: Install A Certificate And Key On The Lom Gui

    Install a certificate and key on the LOM GUI September 19, 2022 Citrix recommends using HTTPS to access the LOM GUI. To use HTTPS, you must replace the default SSL certificate with one from a trusted certificate authority and upload a private key to the LOM GUI.
  • Page 165 Citrix ADC MPX Upload a trusted certificate and private key by using the LOM GUI 1. Navigate to Configuration > SSL Certification. 2. In the right pane, click the Choose File buttons to select a new SSL certificate and a new private key.
  • Page 166 Citrix ADC MPX 4. Click Upload. A message informs you that uploading a new SSL certificate replaces the existing (default) certificate. 5. Click OK. 6. When a message informs you that the certificate and key have been uploaded successfully, click OK to reset the device.
  • Page 167 Citrix ADC MPX The reset takes approximately 60 seconds. You are then redirected to the logon page. 7. Log on to the LOM GUI by using your default credentials. Note: If the certificate or key is invalid, the BMC reboots, tries the new settings, and reverts to using the previous settings.
  • Page 168 Citrix ADC MPX 9. Click Certificate information to display details about the certificate that you uploaded. © 1999 2023 Cloud Software Group, Inc. All rights reserved. –...
  • Page 169 Citrix ADC MPX Note: Best practices for LOM and ADC security are covered in Citrix ADC Secure Deployment Guide. © 1999 2023 Cloud Software Group, Inc. All rights reserved. –...

  • Page 170: Obtain The Mac Address, Serial Number, And Host Properties Of The Appliance

    Citrix ADC MPX Obtain the MAC address, serial number, and host properties of the appliance September 19, 2022 A Media Access Control address (MAC address) is a unique identifier assigned to network interfaces for communication on the physical network segment. The serial number is on the back panel of the ap‑...

  • Page 171: Perform Power Control Operations By Using The Lom Port

    Citrix ADC MPX IP Header TTL=0x00 Flags=0x00 Precedence=0x00 TOS=0x00 BMC ARP Control ARP Responses Enabled, Gratuitous ARP Disabled Gratituous ARP Intrvl : 0.0 seconds Default Gateway IP : 0.0.0.0 Default Gateway MAC : 00:00:00:00:00:00 Backup Gateway IP : 0.0.0.0 Backup Gateway MAC : 00:00:00:00:00:00 802.1q VLAN ID...
  • Page 172 Citrix ADC MPX as pushing the power button until the unit powers off. • Power Off System – Orderly Shutdown—Gracefully shut down the appliance, and then disconnect power to the appliance. This option has the same effect as pressing the power button on the back panel of the appliance for less than four seconds.

  • Page 173: Restore The Bmc Configuration To Factory Defaults

    Citrix ADC MPX Perform a warm restart remotely from another computer on the network ipmitool <bmc_gui_username> <bmc_gui_password> H <bmc IP address> – – – reset cold Perform a core dump If the appliance fails or becomes unresponsive, you can remotely perform a core dump. This proce‑...

  • Page 174: Use The Bios Post Code To Detect Errors

    Upgrade the LOM firmware on a Citrix ADC MPX appliance October 18, 2022 Citrix has automated the upgrade of LOM firmware within Citrix ADC MPX software. It is no longer necessary to know your hardware platform or download any LOM firmware.
  • Page 175 Citrix ADC MPX • MPX 26000 For information about upgrading the Citrix ADC appliance, see Upgrade and downgrade a Citrix ADC appliance Note If you cannot log into the LOM GUI on the MPX 5900, MPX 8900, MPX 15000, or MPX 26000, reset...

  • Page 176: Enable Radius Authentication In The Lom Gui

    Citrix ADC MPX Enable RADIUS authentication in the LOM GUI September 19, 2022 RADIUS (Remote Authentication Dial‑In User Service) is a network protocol that allows you to manage remote user authentication, authorization, and auditing. Configure RADIUS authentication in the LOM GUI 1.

  • Page 177: Rakp Topology On Citrix Adc Appliances

    Configure an external computer running Windows or Ubuntu OS to access the LOM using RADIUS’ network protocol RADIUS is an application that runs on an external computer to access the Citrix LOM. Before you run RADIUS, you need to configure the user account and client information.

  • Page 178: Configure Active Directory In Lom

    Citrix ADC MPX 3. Select Enable or Disable. 4. Click Save. Enable or disable RAKP using the ADC bash shell • To enable RAKP, type: ipmitool raw 0x30 0x72 0x01 0x01 • To disable RAKP, type: ipmitool raw 0x30 0x72 0x01 0x00...
  • Page 179 Citrix ADC MPX 3. Click the link to configure or edit active directory settings. 4. Type values for the different parameters and click Save. © 1999 2023 Cloud Software Group, Inc. All rights reserved. –...
  • Page 180 Citrix ADC MPX The following message appears after a successful save. 5. Click Active Directory and add a role group. A role group is required to give an Active Directory user a specific type of privilege on LOM. 6. Select Administrator to give admin privileges to the role group and click Save.

  • Page 181: Change The Bmc Host Name

    Citrix ADC MPX You have completed the steps to add an Active Directory. Change the BMC host name April 26, 2022 When changing the host name for BMC version 2.12, you must enter an IP address in the DNS Server IP field.
  • Page 182 Citrix ADC MPX Entering a dummy IP address, such as 0.0.0.0 is supported. Perform the following steps to change the host name for BMC version 2.12 using the LOM GUI. 1. Log on to the LOM GUI. 2. Navigate to Configuration > Network.

  • Page 183: Hardware Health Attributes For The Mpx 16000 Platform

    Citrix ADC MPX Hardware health attributes for the MPX 16000 platform December 6, 2022 The following table lists the recommended ranges for the health attributes on the MPX 16000 platform. Run the command from the shell. This command lists the sensory parameters ipmitool sdr list data in detail.
  • Page 184 Citrix ADC MPX Health Attribute (shell) Health Attribute (CLI) Recommended Range Vcpu2VDDQEFGH Voltage 3 (Volts) 1.096–1.344 5VSB 5V Standby Voltage (Volts) 4.745–5.249 3.3VSB Standby 3.3 V Supply Voltage 3.117–3.447 1.8V PCH Voltage 4 (Volts) 1.698–1.883 PS1 Status Power supply 1 status ‑...
  • Page 185 Citrix ADC MPX Battery Voltage (Volts) 3.11 Intel CPU Vtt Power(Volts) 0.00 5V Standby Voltage(Volts) 5.04 Voltage Sensor2(Volts) 0.00 CPU Fan Speed (RPM) 3360 CPU Fan Speed (RPM) 3360 System Fan Speed (RPM) 3360 System Fan Speed (RPM) 3360 System Fan...
  • Page 186 Citrix ADC MPX > <!--NeedCopy--> Shell At the command line, type: shell > shell root@ns# ipmitool sdr list CPU1 Temp | 54 degrees C CPU2 Temp | 53 degrees C PCH Temp | 34 degrees C System Temp | 33...
  • Page 187 Citrix ADC MPX Vcpu2VDDQEFGH | 1.20 Volts 5VSB | 5.04 Volts 3.3VSB | 3.45 Volts 2.5V BMC | 2.56 Volts 1.8V BMC | 1.83 Volts 1.2V BMC | 1.20 Volts 1.0V BMC | 1.02 Volts 1.8V PCH | 1.88 Volts PVNN PCH | 1.06...

  • Page 188: Hardware Health Attributes For The Mpx 9100 Platform

    Citrix ADC MPX Hardware health attributes for the MPX 9100 platform December 6, 2022 The following table lists the recommended ranges for the health attributes on the MPX 9100 platform. Run the command from the shell. This command lists the sensory parameters ipmitool sdr list data in detail.
  • Page 189 Citrix ADC MPX Health Attribute (shell) Health Attribute (CLI) Recommended Range Fan 5 System Fan 2 Speed (RPM) 1260–18060 Fan 6 Fan 0 Speed (RPM) 1260–18060 +12.0 V Supply Voltage 10.704–13.812 5VCC +5.0 V Supply Voltage 4.466–5.737 3.3VCC Main 3.3 V Supply Voltage 2.885–3.690...
  • Page 190 Citrix ADC MPX ranges, see the previous table. • From the CLI • From the shell • From the LOM GUI At the command line, type: stat system -detail >stat system -detail Citrix ADC Executive View System Information: Up since...
  • Page 191 Citrix ADC MPX System Disk Statistics: /flash Size (MB) 23801 /flash Used (MB) 3392 /flash Available (MB) 18504 /flash Used /var Size (MB) 341189 /var Used (MB) 12637 /var Available (MB) 301257 /var Used System Health Statistics(Auxiliary): Voltage 0 (Volts) 1.22...
  • Page 192 Citrix ADC MPX VRMEFGH Temp | 40 degrees C DIMMABCD Temp | 27 degrees C DIMMEFGH Temp | 30 degrees C FAN1 | 9380 FAN2 | 9380 FAN3 | 9380 FAN4 | 9240 FAN5 | 9240 FAN6 | 9240 | 12.38...

  • Page 193: Hardware Health Attributes

    Citrix ADC MPX Hardware health attributes December 8, 2022 Operating ranges for Citrix ADC hardware platforms vary for different attributes. Note Use the command to display the current values of the attributes. stat system -detail © 1999 2023 Cloud Software Group, Inc. All rights reserved.
  • Page 194 Citrix ADC MPX Health attributes for the MPX 5900 platform The following table lists the health attributes for the MPX 5900 platform. Health Attribute Recommended Range CPU 0 core (Volts) 1.77–1.81 Main 3.3 V Supply (Volts) 3.25–3.32 Standby 3.3 V Supply (Volts) 3.27–3.32...
  • Page 195 Citrix ADC MPX Health Attribute Recommended Range +12.0 V Supply (Volts) 11.75–12.00 Battery (Volts) 3.02–3.13 5 V Standby (Volts) 5.05–5.16 CPU Fan 0 Speed (RPM) 6600–12600 CPU Fan 1 Speed (RPM) 6300–12200 System Fan Speed (RPM) 6700–8600 System Fan 1 Speed (RPM) 6600–8500...
  • Page 196 Citrix ADC MPX Health Attribute Unit Minimum value Nominal value Maximum value CPU Fan 0 Speed 1500 ‑NA‑ 7500 CPU Fan 1 Speed 1500 ‑NA‑ 7500 System Fan 1500 ‑NA‑ 7500 Speed System Fan 1 1500 ‑NA‑ 7500 Speed System Fan 2 1500 ‑NA‑...
  • Page 197 Citrix ADC MPX Health Attribute Recommended Range CPU 0 Temperature (Celsius) 33–43 CPU 1 Temperature (Celsius) 35–45 Internal Temperature (Celsius) 28–38 Power Supply 1 Status NORMAL Power Supply 2 Status NORMAL Health attributes for the MPX 22040 platform The following table lists the health attributes for the MPX 22040 platform.
  • Page 198 Citrix ADC MPX Lower Lower Upper Upper Health Non‑ Lower Non‑ Non‑ Upper Non‑ attribute Unit Recoverable Critical Critical Critical Critical Recoverable FAN 1 ‑ NA ‑ 1980.000 ‑ NA ‑ ‑ NA ‑ ‑ NA ‑ ‑ NA ‑...
  • Page 199 Citrix ADC MPX Lower Lower Upper Upper Health Non‑ Lower Non‑ Non‑ Upper Non‑ attribute Unit Recoverable Critical Critical Critical Critical Recoverable Volts 0.816 0.864 0.912 1.344 1.392 1.440 CPU1 Volts 0.480 0.512 0.544 1.488 1.520 1.552 Vcore CPU2 Volts 0.480...
  • Page 200 Citrix ADC MPX Lower Lower Upper Upper Health Non‑ Lower Non‑ Non‑ Upper Non‑ attribute Unit Recoverable Critical Critical Critical Critical Recoverable Peripheral degrees C ‑9.000 ‑7.000 ‑5.000 80.000 85.000 90.000 Temp degrees C ‑11.000 ‑8.000 ‑5.000 90.000 95.000 100.000...
  • Page 201 Citrix ADC MPX Lower Lower Upper Upper Health Non‑ Lower Non‑ Non‑ Upper Non‑ attribute Unit Recoverable Critical Critical Critical Critical Recoverable PS_2 degrees C ‑ NA ‑ ‑ NA ‑ ‑ NA ‑ ‑ NA ‑ ‑ NA ‑...
  • Page 202 Citrix ADC MPX Lower Lower Upper Upper Health Non‑ Lower Non‑ Non‑ Upper Non‑ attribute Unit Recoverable Critical Critical Critical Critical Recoverable VBAT Volts 2.400 2.544 2.688 3.312 3.456 3.600 Health attributes for MPX 5500/7500/9700/9700 10G platforms The following tables list the health attributes and their recommended value ranges.
  • Page 203 Citrix ADC MPX Health 9700/10500/ attributes/‑ SNMP Alarm 12500/15500 Platform Support 5500/5600 7500/9500 9700/10500/12500/15500 CPU Fan 0 3000–16000 3000–16000 3000–10000 3000–16000 Speed (RPM) CPU Fan 1 3000–16000 3000–16000 3000–16000 3000–16000 Speed (RPM) System Fan 900–15000 900–13000 900–10000 900–9000 Speed (RPM) System Fan 1 900–15000...
  • Page 204 Citrix ADC MPX Health SNMP attributes/‑ Alarm Platform Support 17500/19500/21500 MPX 115xx 17550/19550/20550/21550 MPX8005/8015/8200/8400/8600/8800 5550/5650/5750 CPU 0 core 0.99–1.5 0.95–1.5 0.95–1.5 ‑ NA ‑ ‑ NA ‑ (Volts) CPU 1 core 0.99–1.5 0.95–1.56 0.95–1.5 ‑ NA ‑ ‑ NA ‑...
  • Page 205 Citrix ADC MPX Health SNMP attributes/‑ Alarm Platform Support 17500/19500/21500 MPX 115xx 17550/19550/20550/21550 MPX8005/8015/8200/8400/8600/8800 5550/5650/5750 CPU Fan 1 3000–16000 3000–16000 3000–16000 > 5500 > 5500 Speed (RPM) System Fan 900–15000 900–15000 900–15000 > 5500 > 5500 Speed (RPM) System Fan 900–15000...

  • Page 206: Fortville Nics Firmware Upgrade On Citrix Adc Mpx Appliances

    Prerequisites 1. Before upgrading the NIC firmware to version 7.00, you must upgrade the Citrix ADC MPX ap‑ pliance to a software version that supports the new firmware. The following versions support firmware version 7.00. • 11.1 build 64.x and later •...
  • Page 207 The files are included with all ADC software that supports this firmware upgrade. Supported Platforms The firmware upgrade scripts are supported on all Citrix ADC MPX platforms containing Fortville NICs. The scripts verify if the appliance contains Fortville NICs and exit if none is found.
  • Page 208 /nsconfig/.developer • By deleting the file the /nsconfig/rc.local fortville_fw_update_state_machine script is not invoked on reboot. After reboot, Citrix ADC software is up and the firmware upgrade process is complete. After firmware upgrade, the log file in the directory, upgrade_fortville_nic_fw.log /var/log contains a detailed record of the firmware upgrade activities.

  • Page 209: Wiping Your Data Before Sending The Adc Appliance To Citrix

    Supported Platforms The script is supported on all Citrix ADC MPX appliances. The script is not supported on Citrix ADC SDX appliances. Delete the VPX instances before returning the SDX appliance. Required script files The following script files must be present in the /flash/.recovery directory.
  • Page 210 Citrix ADC MPX • rc.system_wipe_and_reset Commands to wipe the config At the command line, type: > shell cd /flash/.recovery sh rc.system_wipe_and_reset <!--NeedCopy--> Two optional parameters are available to zero the flash and the disk one or more times. sh rc.system_wipe_and_reset [num_flash_loops [num_disk_loops]] <!--NeedCopy-->...

  • Page 211: How To Verify The File System Integrity Of Your Citrix Adc Mpx Appliance

    How to verify the file system integrity of your Citrix ADC MPX appliance September 19, 2022 Complete the following procedure to verify the file system integrity of the Citrix ADC MPX appliance. 1. Connect a console cable to the serial console of the ADC appliance, which is 9600 baud, 8 bits, 1 stop bit, and No parity.
  • Page 212 Citrix ADC MPX 3. Press keys simultaneously when you see the message Ctrl+C Booting [/ns-12.1-60.19] . At the OK prompt, type to show available com‑ counting down from second mands. 4. Type to start the kernel in single user mode.
  • Page 213 Citrix ADC MPX 6. Type to verify the disk consistency of the partition: fsck_ufs -y /dev/ad0s1a /flash 7. Type to display the currently mounted partitions. 8. If the device name is not mounted, type to mount /sbin/mount /dev/ad0s1a /flash the disk name on the partition.
  • Page 214 Citrix ADC MPX the procedure again. If the error is displayed again, contact Citrix Support for further investigation. Migrate the configuration of an existing Citrix ADC appliance to another Citrix ADC appliance August 12, 2022 Before migrating to a new appliance, you must make some changes to the configuration of the old appliance before you copy the configuration to the new appliance.
  • Page 215 Citrix ADC MPX 9. Restart the new appliance. 10. Add the interface‑related configuration specific to your new appliance, switch, and router, and save the configuration. If you have a high‑availability setup, you must perform the preceding procedure on both the nodes.
  • Page 216 Citrix ADC MPX 4. Initialize appliance A as the source appliance. At the command prompt, type: init ssl fipsSIMsource <certFile> <!--NeedCopy--> Example: init fipsSIMsource /nsconfig/ssl/nodeA.cert 5. Copy this file to appliance B, in the /nconfig/ssl folder. <certFile> Example: scp /nsconfig/ssl/nodeA.cert nsroot@198.51.100.10:/nsconfig/ssl 6.

  • Page 217: Troubleshooting

    17. Copy the rest of the configuration from appliance A to appliance B. Troubleshooting September 19, 2022 I cannot access the Citrix ADC appliance after it is restarted. The Citrix ADC IP address (NSIP) is not accessible and does not respond to a ping request Citrix ADC MPX 8005/8015/8200/8400/8600/8800, MPX 11500/13500/14500/16500/18500/20500, MPX...
  • Page 218 LOM IP address, connect to the COM1 console port through a serial cable. You can also try pinging the Citrix ADC IP address (NSIP). The serial cable can be connected to a network serial terminal/console server for remote access. On the appliance, do the following: a) Verify that the appliance is receiving power.

  • Page 219: Hardware Faqs

    Citrix ADC command line. Complete the Check Network Interfaces steps to find a working interface on which to transfer the support bundle file. Check network interfaces 1.
  • Page 220 ADC appliance on one end and to a QSFP+ 40G port of a Cisco switch on the other end. Support for 40G connectivity: Citrix ADC models that have at least four 10G SFP+ ports con‑ nect to Cisco 40G interfaces by aggregating four of the 10G SFP+ ports to form a 40G link aggrega‑...
  • Page 221 Power supplies • Is the power supply on the Citrix ADC MPX 5500 and MPX 5550/5650 appliances field replaceable? No. The power supply on the Citrix ADC MPX 5500 and MPX 5550/5650 appliances is fixed. • Do the MPX 8005, 8015, 8200, 8400, 8600, 8800 and T1010 appliances ship with two power sup‑...
  • Page 222 23 inches to 33 inches. • How far can an appliance extend from the front post of the rack? The chassis can extend up to 1.25 inches from the front post for all Citrix ADC MPX and SDX appliances.
  • Page 223 • What is the recommended terminal emulator? PuTTY. • Which platforms support Pay‑As‑You‑Grow licenses? Check the Citrix ADC data sheet for the updated list of platforms that support Pay‑As‑You‑Grow licenses. Some of the platforms that support Pay‑As‑You‑Grow licenses are listed here: –...
  • Page 224 Citrix ADC MPX • Can I mix SFP+ fiber and DAC in ports that are part of the same link aggregation channel? No. There must be symmetry between all elements in the same link aggregation channel. • Which transceivers use the MPO type connector? Only 40G QSFP+ SR4 transceiver and 100G QSFP28 SR4 transceivers use the MPO type connector.
  • Page 225 Citrix ADC MPX – MPX/SDX 14000 40S – MPX/SDX 14000 40G – MPX/SDX 15000 50G – MPX 15041T 50G – MPX 15081T 50G – MPX 25000TA – MPX/SDX 25000 40G – MPX/SDX 26000 – MPX/SDX 26000 50S – MPX/SDX 26000 100G ©...
  • Page 226 Cloud Software Group, Inc. and/or one or more of its subsidiaries, and may be registered with the U.S. Patent and Trademark Office and in other countries. All other marks are the property of their respective owner(s). Citrix Product Documentation | docs.citrix.com February 8, 2023...
