Z3-DM8168-APP-41
Multi-Channel H.264 HD Multimedia System
Acceptance Testing
Version 1.00
January 24, 2012
Model Name: Z3-DM8168-APP-41
___________________________________________________________________________________________
1
V1.00
Z3 Technology, LLC ♦ 4701 Innovation Drive CB103 ♦ Lincoln, NE 68521 USA ♦ +1.402.323.0702
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Z3 Technology Z3-DM8168-APP-41
Summary of Contents for Z3 Technology Z3-DM8168-APP-41
- Page 1 CONFIDENTIAL Z3-DM8168-APP-41 Multi-Channel H.264 HD Multimedia System Acceptance Testing Version 1.00 January 24, 2012 Model Name: Z3-DM8168-APP-41 ___________________________________________________________________________________________ V1.00 Z3 Technology, LLC ♦ 4701 Innovation Drive CB103 ♦ Lincoln, NE 68521 USA ♦ +1.402.323.0702...
- Page 2 CONFIDENTIAL Z3-DM8168-APP-41 Revision History Version Date Change Note Author 0.01 1/23/12 Initial version 0.02 1/23/12 Revision 1.00 1/24/12 Release ___________________________________________________________________________________________ V1.00 Z3 Technology, LLC ♦ 4701 Innovation Drive CB103 ♦ Lincoln, NE 68521 USA ♦ +1.402.323.0702...
-
Page 3: Table Of Contents
HDMI video output ..........................9 HDMI input 1 ............................9 HDMI input 2 ............................10 H.264 video encoder ..........................10 Test result matrix ............................11 Approvals..............................12 ___________________________________________________________________________________________ V1.00 Z3 Technology, LLC ♦ 4701 Innovation Drive CB103 ♦ Lincoln, NE 68521 USA ♦ +1.402.323.0702... -
Page 4: Purpose Of This Document
Purpose of this document The purpose of this document is to define the testing methods and acceptance criteria for the Z3-DM8168- APP-41 board and the basic system operation when the Z3-DM8168-APP-41 board is paired with a Z3- DM8168-MOD-34 processor module. - Page 5 The PC computer must be fast enough so that VLC can decode H.264 video at 1080p60 and keep up with real time. The tests require a video player to source video to the HDMI inputs. Since the Z3-DM8168-APP-41 board does not accept HDCP encrypted content, the user must ensure that the video player does not use HDCP encryption.
-
Page 6: Basic Setup
Configure the Teraterm serial port parameters to 115200 baud, 8 bits, 1 stop bit, no parity. Connect the serial port cable from the 2.5mm console jack on the Z3-DM8168-APP-41 board to the serial port of the PC, using the null modem adapter if necessary. Connect the power supply to the Z3-DM8168-APP-41 board and verify that the computer displays the boot sequence. -
Page 7: Physical Embodiment
CPU is executing code, memory is not corrupt and the console port is functional. Ensure that the serial cable is connected between the console jack of the Z3-DM8168-APP-41 and the computer. Ensure that Teraterm is configured for the appropriate serial port, and set to 115200,N81. -
Page 8: Sata Interface
PC. Connect the Ethernet patch cable from the RJ-45 jack of the Z3-DM8168-APP-41 to the Windows PC. Follow the procedure specified by section 4.2 above to turn on the system and obtain a shell prompt. -
Page 9: Hdmi Video Output
Ensure that the file “dectest.h264” is present in the USB mass storage device. Plug the USB mass storage device to the USB jack of the Z3-DM8168-APP-41. Connect the HDMI output of the Z3-DM1868-APP-41 to the HDMI input of the monitor. -
Page 10: Hdmi Input 2
CONFIDENTIAL Z3-DM8168-APP-41 Connect the HDMI output of the media player to the HDMI 1 input on the Z3-DM8168-APP-41. Connect the HDMI output of the Z3-DM1868-APP-41 to the HDMI input of the monitor. Connect the Ethernet patch cable from the RJ-45 jack of the Z3-DM8168-APP-41 to the Windows PC. -
Page 11: Test Result Matrix
Pass/Fail Notes Physical embodiment Basic USB interface SATA interface Ethernet interface HDMI video out HDMI input 1 HDMI input 2 H.264 video encoder ___________________________________________________________________________________________ V1.00 Z3 Technology, LLC ♦ 4701 Innovation Drive CB103 ♦ Lincoln, NE 68521 USA ♦ +1.402.323.0702... -
Page 12: Approvals
CONFIDENTIAL Z3-DM8168-APP-41 Approvals Z3 Technology ______________________________________________ Date: Tester Z3 Technology ______________________________________________ Date: Eng. Management Customer ______________________________________________ Date: Approval Manager ___________________________________________________________________________________________ V1.00 Z3 Technology, LLC ♦ 4701 Innovation Drive CB103 ♦ Lincoln, NE 68521 USA ♦ +1.402.323.0702...
