Loreme BGCL96 Configuration Handbook

Led bargraph with circular strip light 96 x 96 mm
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
LED BARGRAPH WITH CIRCULAR STRIP LIGHT
96 x 96 mm
CONFIGURATION HANDBOOK
BGCL96
LOREME 12, rue des Potiers d'Etain Actipole BORNY - B.P. 35014 - 57071 METZ CEDEX 3
Phone 03.87.76.32.51 - Telefax 03.87.76.32.52
Contact : Commercial@Loreme.fr - Technique@Loreme.fr
Download manual at : www.loreme.fr
REV 0.0 - 03/08/11
E 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BGCL96 and is the answer not in the manual?

Questions and answers

Related Manuals for Loreme BGCL96

Summary of Contents for Loreme BGCL96

  • Page 1 LED BARGRAPH WITH CIRCULAR STRIP LIGHT 96 x 96 mm CONFIGURATION HANDBOOK BGCL96 LOREME 12, rue des Potiers d'Etain Actipole BORNY - B.P. 35014 - 57071 METZ CEDEX 3 Phone 03.87.76.32.51 - Telefax 03.87.76.32.52 Contact : Commercial@Loreme.fr - Technique@Loreme.fr Download manual at : www.loreme.fr...
  • Page 2 DIAGRAM OF CONNECTION ........................p13 RS485 MODBUS COMMUNICATION ........................p14 MODBUS TCP COMMUNICATION ........................... p16 PROFIBUS COMMUNICATION ..........................p17 CONNECTION TO COMMUNICATION NETWORK ....................p19 LOREME 12, rue des Potiers d'Etain - 57071 Metz  03.87.76.32.51 - Fax 03.87.76.32.52 - Email: Commercial@Loreme.fr - Technique@Loreme.fr...

  • Page 3: Device Presentation

    The purpose of this configuration handbook is to allow to become familiar with the functions supplied by the device. The programmable bargraph BGCL96 allows with his circular ramp and the display, to evaluate easily the state of his process inputs.
  • Page 4 If no button is pushed during a delay of 30 seconds, the device returns in measure mode without saving the configured parameters. LOREME 12, rue des Potiers d'Etain - 57071 Metz  03.87.76.32.51 - Fax 03.87.76.32.52 - Email: Commercial@Loreme.fr - Technique@Loreme.fr...

  • Page 5: Rs232 Link Setting

    Step 2: Setting of terminal emulation software (PC with Windows). The terminal emulation software for PC « HyperTerminal » is resident in windows up to XP version. For later ver- sions, it is downloadable on : www.loreme.fr in download part ( http://www.loreme.fr/HyperTerm/htpe63.exe =>...
  • Page 6 - In configuration mode, if you want to go back to measure mode without taking notice of the modifications made before, you just have to press "ESC". 2.2) Language Languages possibilities are: - French, - English. LOREME 12, rue des Potiers d'Etain - 57071 Metz  03.87.76.32.51 - Fax 03.87.76.32.52 - Email: Commercial@Loreme.fr - Technique@Loreme.fr...
  • Page 7  SOMMAIRE 2.3) Input The input possibilities are: - Voltage (mV, mV differential, V) - Current (mA) - Resistance () - Frequency (Hz), duty cyle (%), - Thermocouple (°C) internal or external compensation, linearized or not. - Pt 100 (°C) 3 wires, linearized or not. - Pt 100 (°C) 4 wires, linearized or not with for each input type, the choice of low scale, high scale and display range.
  • Page 8 Note: The hysteresis value is relative to the display range scale and can be configured between 0 % and 99 %. LOREME 12, rue des Potiers d'Etain - 57071 Metz  03.87.76.32.51 - Fax 03.87.76.32.52 - Email: Commercial@Loreme.fr - Technique@Loreme.fr...
  • Page 9  SOMMAIRE - Relay parameter: - adjustable, - security, - delay. When alarm is used in threshold detection, it is possible to access the threshold adjustment in front face with the push- buttons. This possibility can be deactivated if the adjustment must be inaccessible in front face, only the visualization is then possible.
  • Page 10 Attention, the offset has no effect on the measure when the converter is in frequency or duty cycle mode !!! E 10 LOREME 12, rue des Potiers d'Etain - 57071 Metz  03.87.76.32.51 - Fax 03.87.76.32.52 - Email: Commercial@Loreme.fr - Techni-...

  • Page 11: Firmware Update

    READY TO TRANSFER... The device is now in file waiting mode, This file is provided by LOREME. This file contain the firmware code in intel HEX format. Selected the « Transfer », « Send a text file... » in the HyperTerminal menu Select the directory and the file, click on «...

  • Page 12: Emc Consideration

    - It is advisable to separate the input / output lines from the power supply lines in order to avoid the coupling phenomena. - It is also advisable to limit the lengths of data cables as much as possible. E 12 LOREME 12, rue des Potiers d'Etain - 57071 Metz  03.87.76.32.51 - Fax 03.87.76.32.52 - Email: Commercial@Loreme.fr - Techni-...
  • Page 13  SOMMAIRE Wirings PC - DEVICE LINK 3.5 stereo 9 female pins to PC jack DIAGRAMS OF CONNECTIONS mV, Tc input: terminal D (+), terminal F (-) V/Frequency input: terminal B (+), terminal F (-) mA input: terminal C (+), terminal F (-) Potentiometer input: terminal G (supply), terminal B (+), terminal F (-) Strain gauge input :...

  • Page 14: Rs485 Modbus Communication

    Data are transmitted Most Significant Byte first, 4 bytes or 2 words long. $FFFFFFFF = sensor braking. Sign Exponent Mantissa E 14 LOREME 12, rue des Potiers d'Etain - 57071 Metz  03.87.76.32.51 - Fax 03.87.76.32.52 - Email: Commercial@Loreme.fr - Techni-...
  • Page 15  SOMMAIRE - Data in 16 bits integer format. Data are transmitted most significant byte first, 2 bytes or 1 word long. The 16 bits unsigned integer values correspond to the percentage of the input measure scale. $0000 ou $FFFF = sensor breaking. $0001 = Low overstepping of input scale, $FFFE = High overstepping of input scale.

  • Page 16: Modbus Tcp Communication

    The available data are the same as for the MODBUS communication (see pages 14/15). 3) Response time It is the delay between a read request send by the master and the response frame send by the BGCL96/CMTCP. The BGCL96 device answer in less of 30 ms to a read of 4 registers.
  • Page 17 There are 6 byte of standard diagnostic data and 2 byte for device specific data. 2.3) Data exchange information: Remark: Only the channel 1 is use by the BGCL96 and the alarms 1 and 2 are always 0. Total word...
  • Page 18 - Date in IEEE 32 bits floating point number. Data are transmitted Most significant byte first, 4 bytes long. $FFFFFFFF = sensor breaking. Sign Exponent Mantisse E 18 LOREME 12, rue des Potiers d'Etain - 57071 Metz  03.87.76.32.51 - Fax 03.87.76.32.52 - Email: Commercial@Loreme.fr - Techni-...
  • Page 19  SOMMAIRE Connection to the communication network 1) Connection to a MODBUS network RS 485 1 2 3 The terminal (3) is not connected INL35 INL35 2) Connection to a PROFIBUS network The terminal (3) is not connected 1 2 3 INL35 Profibus cable wire color...
