AC & DC TRMS current and voltage transducer
Wattmeter, Voltmeter, Ammeter,...
CONFIGURATION HANDBOOK
CPL35
CPL35L
LOREME 12, rue des Potiers d'Etain Actipole BORNY - B.P. 35014 - 57071 METZ CEDEX 3
Phone 03.87.76.32.51
Contact : Commercial@Loreme.fr - Technique@Loreme.fr
Download manual at : www.loreme.fr
REV 2.2 - 01/10/18
E 1
Advertisement
Table of Contents
Related Manuals for Loreme CPL35
Summary of Contents for Loreme CPL35
- Page 1 AC & DC TRMS current and voltage transducer Wattmeter, Voltmeter, Ammeter,... CONFIGURATION HANDBOOK CPL35 CPL35L LOREME 12, rue des Potiers d'Etain Actipole BORNY - B.P. 35014 - 57071 METZ CEDEX 3 Phone 03.87.76.32.51 Contact : Commercial@Loreme.fr - Technique@Loreme.fr Download manual at : www.loreme.fr REV 2.2 - 01/10/18...
-
Page 2: Table Of Contents
Balanced three phases network with neutral ..................... p16 Balanced three phases network without neutral ..................p17 Hall sensor current input ..........................p17 BIPOLAR OUTPUT WIRING ............................ p18 LOREME 12, rue des Potiers d'Etain - 57071 Metz 03.87.76.32.51 - Email: Commercial@Loreme.fr - Technique@Loreme.fr... -
Page 3: Device Presentation
TABLE OF CONTENTS Device Presentation The CPL35 and CPL35L are TRMS (AC+DC) converters for measuring, monitoring and retransmission of electrical pa- rameters. Implementation is fast by simple front face configuration. The various output options allow a wide range of ap- plication: measurement, protection, control. -
Page 4: Reset Of Memorized Alarms
The network configurable parameters are: - Alternative or Continuous (only on CPL35(L) or CPL35(L)-Hall), - Single-phase or balanced three phases with or without neutral for a alternative network (only visible on a CPL35). It is also necessary to configure: LOREME 12, rue des Potiers d'Etain - 57071 Metz 03.87.76.32.51 - Email: Commercial@Loreme.fr - Technique@Loreme.fr... -
Page 5: Relays Configuration
Signal with an average value > 0. +100 -100 V These 2 rubrics are only accessible on a CPL35 and if the ALTERNATIVE mode was previously selected SINGLE PHASE? Push the YES button to choose the single phase mode or the NO button to select the next choice. -
Page 6: Outputs Configuration
Push the YES button to access the output response time setting (0 to 60 s). LIMITATION? Push the YES button to activate the output limitation, Push the NO button to deactivate the output limitation. LOREME 12, rue des Potiers d'Etain - 57071 Metz 03.87.76.32.51 - Email: Commercial@Loreme.fr - Technique@Loreme.fr... -
Page 7: Display Configuration
TABLE OF CONTENTS MEASURE: Choice of monitored measure. VOLTAGE? Push the YES button to choose the displayed type. Push the NO button to display the next measurement type. MEASURE 0%? Push the YES button to access the measure low scale setting. MEASURE 100%? Push the YES button to access the measure high scale setting. -
Page 8: Rs232 Link Setting
Note: to modify the parameters of terminal mode whereas this one is already started, it is necessary, after having car- ried out the modifications, to close the terminal and to open it again so that the modifications are effective. LOREME 12, rue des Potiers d'Etain - 57071 Metz 03.87.76.32.51 - Email: Commercial@Loreme.fr - Technique@Loreme.fr... -
Page 9: Terminal Mode
1) Visualization The CPL35 or CPL35L can be connected to a terminal with the RS232 link on the front of the device. This requires a USB/Jack adapter cable, and have a ASCII emulation program like ‘HyperTerminal ' or else installed on the PC. -
Page 10: Language
The activation and deactivation delays, configurable from 0 to 600 s set the time above which alarm changes its state after event appearance and disappearance (see chronograms on next page). E 10 LOREME 12, rue des Potiers d'Etain - 57071 Metz 03.87.76.32.51 - Email: Commercial@Loreme.fr - Technique@Loreme.fr... -
Page 11: Analogical Outputs
- Limitation. - Monitored value: voltage, peak voltage (only for output 1 on a CPL35L), current, frequency, plus active power, reactive power, apparent power, power factor, on a CPL35. - Low and high input measure scales. The limitation allows to bound the output signal swing to the configured output scales for all input signal values. -
Page 12: Special Functions
If no action is performed during the configuration process, the device returns automatically to measurement mode after a wait of two minutes, without taking into account of the modifications made before. E 12 LOREME 12, rue des Potiers d'Etain - 57071 Metz 03.87.76.32.51 - Email: Commercial@Loreme.fr - Technique@Loreme.fr... -
Page 13: Firmware Update
FIRMWARE LOADER Rev3 READY TO TRANSFER... The device is now in the firmware load mode and is waiting for the firmware file. This file is provide by LOREME and contain the firmware code in Intel HEX format. Select the « Transfer », « Send a text file ... » in the HyperTerminal menu. -
Page 14: Emc Consideration
1) Introduction To meet its policy concerning EMC, based on the Community directives 2014/30/EU & 2014/35/EU, the LOREME company takes into account the standards relative to this directives from the very start of the con- ception of each product. The set of tests performed on the devices, designed to work in an industrial environment, are made in accor- dance with IEC 61000-6-4 and IEC 61000-6-2 standards in order to establish the EU declaration of confor- mity. -
Page 15: Wiring
TABLE OF CONTENTS Wirings Removable connectors strap for voltage output Removable connectors Power supply: terminals G, H. Relay 1: terminals common (C1), rest (R1), work (T1). Relay 2: terminals common (C2), rest (R2), work (T2). Relay 3: terminals common (C3), rest (R3), work (T3). Analogical output 1: terminals S1+, S1-, Shunt (Internal 500 Ohms shunt for voltage output). -
Page 16: Wiring Examples
For CPL35 with measurements on a balanced three phases network with neutral User device Wiring can also be done on phase L2 or L3. E 16 LOREME 12, rue des Potiers d'Etain - 57071 Metz 03.87.76.32.51 - Email: Commercial@Loreme.fr - Technique@Loreme.fr... -
Page 17: Balanced Three Phases Network Without Neutral
TABLE OF CONTENTS For CPL35(L) with measurements on a balanced three phases network without neutral User device Phase 2 & 3 are not measured, but serves only to reconstitute an artificial neutral. For a CPL35(L)-Hall with Hall sensor current input... -
Page 18: Bipolar Output Wiring
TABLE OF CONTENTS Bipolar output Wirings +/- 10 V output E 18 LOREME 12, rue des Potiers d'Etain - 57071 Metz 03.87.76.32.51 - Email: Commercial@Loreme.fr - Technique@Loreme.fr...
