BendPak XPR-12CL Service Manual

Hide thumbs Also See for XPR-12CL:

Installation and operation manual (64 pages)

page of 46

/ 46
Bookmarks

Quick Links

Download this manual

Service Manual

SERVICE PARTS & DIAGRAMS

BENDPAK

XPR-12CL

PRODUCT SKU

5175405

DRAWING Nº

5260567

Need help?

Do you have a question about the XPR-12CL and is the answer not in the manual?

Questions and answers

Summary of Contents for BendPak XPR-12CL

Page 1 Bend Pak product. It provides comprehensive information on identifying serviceable parts and components and assists in troubleshooting problems and performing assembly /disassembly procedures. BendPak, Inc. Corporate Office Customer Service Desk / Warranty Parts Orders Domestic Sales & Service International Sales &...
Page 2 5260567 PROPRIETARY AND CONFIDENTIAL SEE COLORS & GRAPHICS FOR LABEL PLACEMENT THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF BENDPAK INC. ANY SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:40 THE WRITTEN PERMISSION OF BENDPAK INC.
Page 3 142.402in 3617.0mm [29.724-57.992in] 755-1473mm 104.843in 2663.0mm DRIVE THRU 155.157in 3941.0mm 119.409in 3033.0mm 168.701in 4285.0mm 1645 LEMONWOOD DR. SANTA PAULA, CA 93060 TITLE: XPR-12CL PRODUCTION LIFT VER E SIZE DWG. NO. 5260567 SCALE: 1:50 SHEET 2 OF 3...
Page 4 PROPRIETARY AND CONFIDENTIAL REFER TO MODEL FOR ADDITIONAL INFORMATION THE INFORMATION CONTAINED IN THIS DRAWING IS 5260563 THE SOLE PROPERTY OF BENDPAK INC. ANY SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:35 THE WRITTEN PERMISSION OF BENDPAK INC.
Page 5 PROPRIETARY AND CONFIDENTIAL THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY ASSEMBLE ITEMS AS SHOWN THE SOLE PROPERTY OF BENDPAK INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:25 THE WRITTEN PERMISSION OF BENDPAK INC. IS...
Page 6 5215293 PROPRIETARY AND CONFIDENTIAL SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT ASSEMBLE ITEMS AS SHOWN SCALE: 1:25 THE WRITTEN PERMISSION OF BENDPAK INC.
Page 7 5210031 PROPRIETARY AND CONFIDENTIAL SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING NEXT ASSEMBLY THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF BENDPAK INC. ANY 5245138 ASSEMBLE ITEMS AS SHOWN REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:18 THE WRITTEN PERMISSION OF BENDPAK INC.
Page 8 5215269 PROPRIETARY AND CONFIDENTIAL SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING THE INFORMATION CONTAINED IN THIS DRAWING IS 5215292 THE SOLE PROPERTY OF BENDPAK INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT ASSEMBLE ITEMS AS SHOWN SCALE: 1:12 THE WRITTEN PERMISSION OF BENDPAK INC. IS...
Page 9 PROPRIETARY AND CONFIDENTIAL SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING THE INFORMATION CONTAINED IN THIS DRAWING IS 5260567 THE SOLE PROPERTY OF BENDPAK INC. ANY ASSEMBLE ITEMS AS SHOWN REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
Page 10 PROPRIETARY AND CONFIDENTIAL FOR 5220116 SPECIFICATIONS REFER TO PART SPECIFICATION FORM THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY (*)5520116 QTY FOR REFERENCE ONLY REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:28 THE WRITTEN PERMISSION OF BENDPAK INC.
Page 11 1645 LEMONWOOD DR. SANTA PAULA, CA 93060 TITLE: XPR-12CL PARTS BOX SIZE DWG. NO. 5250254 SCALE: 1:22 SHEET 2 OF 2...
Page 12 5174518 NOTE: UNLESS OTHERWISE SPECIFIED. PROPRIETARY AND CONFIDENTIAL 5250268 THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF BENDPAK INC. ANY 5250314 REPRODUCTION IN PART OR AS A WHOLE WITHOUT SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING SCALE: 1:30 THE WRITTEN PERMISSION OF BENDPAK INC.
Page 13 5215701 PROPRIETARY AND CONFIDENTIAL 5250269 SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF BENDPAK INC. ANY 5250314 ASSEMBLE ITEMS AS SHOWN REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
Page 14 PROPRIETARY AND CONFIDENTIAL SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING THE INFORMATION CONTAINED IN THIS DRAWING IS 5250314 THE SOLE PROPERTY OF BENDPAK INC. ANY ASSEMBLE ITEMS AS SHOWN REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
Page 15 PROPRIETARY AND CONFIDENTIAL FOR ITEM 1 SPECIFICATIONS REFER TO PART SPECIFICATION FORM 5250297 THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF BENDPAK INC. ANY 5250298 ITEM 1 QTY FOR REFERENCE ONLY REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC.
Page 16: Additional Contact Information
Tel: +86 534-5421821 No. 7, Taishan Rd., Industrial Park, Ningjin County, Shandong, China 2. Vendor Information (Or for Reference) Approved Vendor Vendor Part # Contact # AUTHORIZED COMPONENT PROVIDER 1) Ningjin Hydraulic Hose 5570129 +86 534-5421821 OR BENDPAK ENGINEERING APPROVED EQUIVALENT...
Page 17 PROPRIETARY AND CONFIDENTIAL FOR ITEM 1 SPECIFICATIONS REFER TO PART SPECIFICATION FORM THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF BENDPAK INC. ANY 5250314 (*)ITEM 1 QTY FOR REFERENCE ONLY REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC.
Page 18 PROPRIETARY AND CONFIDENTIAL FOR ITEM 1 SPECIFICATIONS REFER TO PART SPECIFICATION FORM 5250297 THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF BENDPAK INC. ANY 5250298 REPRODUCTION IN PART OR AS A WHOLE WITHOUT ITEM 1 QTY FOR REFERENCE ONLY SCALE: THE WRITTEN PERMISSION OF BENDPAK INC.
Page 19 PROPRIETARY AND CONFIDENTIAL ASSEMBLE ITEMS AS SHOWN THE INFORMATION CONTAINED IN THIS DRAWING IS 5250314 THE SOLE PROPERTY OF BENDPAK INC. ANY ITEM 1 QTY FOR REFERENCE ONLY REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
Page 20 PROPRIETARY AND CONFIDENTIAL 5250268 ITEM 1 QTY FOR REFERENCE ONLY THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF BENDPAK INC. ANY 5250314 REPRODUCTION IN PART OR AS A WHOLE WITHOUT THREAD 5535011 WITH 5545345 ONTO CABLE FOR SHIPMENT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC.
Page 21 5600380 PROPRIETARY AND CONFIDENTIAL DIMENSIONS SHOWN ARE AFTER PAINTING THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY PAINT BENDPAK GREY (RAL-7024) REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:16 THE WRITTEN PERMISSION OF BENDPAK INC. IS...
Page 22 NEXT ASSEMBLY DIMENSIONS SHOWN ARE AFTER PAINTING PROPRIETARY AND CONFIDENTIAL THE INFORMATION CONTAINED IN THIS DRAWING IS 5215218 THE SOLE PROPERTY OF BENDPAK INC. ANY PAINT GRAY (RAL-7024) 20% GLOSS REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:10 THE WRITTEN PERMISSION OF BENDPAK INC.
Page 23 5600404 PROPRIETARY AND CONFIDENTIAL DIMENSIONS SHOWN ARE AFTER PAINTING THE INFORMATION CONTAINED IN THIS DRAWING IS 5215216 THE SOLE PROPERTY OF BENDPAK INC. ANY PAINT GRAY (RAL-7024) 20% GLOSS REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:10 THE WRITTEN PERMISSION OF BENDPAK INC. IS...
Page 24 5600993 PROPRIETARY AND CONFIDENTIAL LOCATION WITH THE FOLLOWING : NEXT ASSEMBLY THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF BENDPAK INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT MANUFACTURER CODE SCALE: 5215283 THE WRITTEN PERMISSION OF BENDPAK INC. IS SHEET 1 OF 3 PROHIBITED.
Page 25 PROPRIETARY AND CONFIDENTIAL BREAK AND DEBURR ALL SHARP EDGES 0.3mm THE INFORMATION CONTAINED IN THIS DRAWING IS 5600392 THE SOLE PROPERTY OF BENDPAK INC. ANY REMOVE ALL WELD SPLATTER REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
Page 26 PROPRIETARY AND CONFIDENTIAL BREAK AND DEBURR ALL SHARP EDGES 0.3mm THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF BENDPAK INC. ANY 5620372 MATERIAL: HR ASTM A36 OR Q235 GB/T 700 REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC.
Page 27 UPDATED DESCRIPTION AND SIZE OF LABEL 02/18/2020 01107 ITEM NO PART NUMBER DESCRIPTION QTY REV 5905311 BENDPAK LABEL; 4 x 38" WHITE INK 5905177 TO PROLONG LIFE OF TWO 5905555 2 POST SAFETY LABEL, ENGLISH-FRENCH DO NOT SCALE DRAWING NAME...
Page 28 Date: ECO : 1. Engineering Specification Application: INSTALLATION MANUAL Detailed Description: Print Settings for BendPak Manuals Unless otherwise specified, use these settings for printing BendPak manuals:  Color. Black and white.  Size. A4 (210 to 297 mm), 8.5 by 11 inches (216 to 279 mm), or between ...
Page 29 PART SPECIFICATION FORM BENDPAK Number: 5905109 MRP Description: WARNING ALI/WL 101C Date: 08/03/2017 ECO : 00850 1. Engineering Specification Application: ALI 2 POST SAFETY STICKER KIT Detailed Description: SIZE: ALI 2 POST CAUTION LABELS: 14” L x 8.5” W (356mm x 216mm) ALI NOTICE LABEL: 1.75”...
Page 30 3” L x 3” W (76.2mm x 76.2mm) 1 Color-Black Material 2 Mil. Gloss Polyester Thermal Transfer Label With A High Performance Permanent Acrylic Adhesive. 2. Vendor Information (Or for Reference) Approved Vendor Vendor Part # Reference # Preferred Vendor OR BENDPAK ENGINEERING APPROVED EQUIVALENT...
Page 31 Print Process: Offset Lithography - 200 line-screen or 300 p.p.i. for digital Lamination: Clear laminate Non-glare medium matte over-laminate for abrasion, chemical, and ultra violet protection 2. Vendor Information (Or for Reference) Approved Vendor Vendor Part # Contact # Preferred Vendor OR BENDPAK ENGINEERING APPROVED EQUIVALENT...
Page 32 PART SPECIFICATION FORM STANDARD 5905311 BENDPAK Number: BENDPAK LABEL; 4 x 38" WHITE INK MRP Description: 01/04/2021 Date: 01249 ECO : 1. Engineering Specification Application: BRANDING LABEL Detailed Description: Size: 4.25” W x 38” H (107.95mm x 965.2mm) Material: Clear Adhesive PET Thickness: 4 Mil Ink: U.V.
Page 33 Print Process: Offset Lithography - 200 line-screen or 300 p.p.i. for digital Lamination: Clear laminate non-glare medium matte over-laminate (No gloss) for abrasion, chemical, and ultra violet protection 2. Vendor Information (Or for Reference) Approved Vendor Vendor Part # Contact # Preferred Vendor OR BENDPAK ENGINEERING APPROVED EQUIVALENT...
Page 34: Instruction Label
Print Process: Offset Lithography - 200 line-screen or 300 p.p.i. for digital Lamination: Clear laminate Non-glare medium matte over-laminate for abrasion, chemical, and ultra violet protection 2. Vendor Information (Or for Reference) Approved Vendor Vendor Part # Contact # Preferred Vendor OR BENDPAK ENGINEERING APPROVED EQUIVALENT...
Page 35 Print Process: Offset Lithography - 200 line-screen or 300 p.p.i. for digital Lamination: Clear laminate Non-glare medium matte over-laminate for abrasion, chemical, and ultra violet protection 2. Vendor Information (Or for Reference) Approved Vendor Vendor Part # Contact # Preferred Vendor OR BENDPAK ENGINEERING APPROVED EQUIVALENT...
Page 36 Lamination: Clear laminate non-glare medium matte over- laminate (No gloss) for abrasion, chemical, and ultra violet protection 2. Vendor Information (Or for Reference) Approved Vendor Vendor Part # Contact # Preferred Vendor OR BENDPAK ENGINEERING APPROVED EQUIVALENT...
Page 37 Print Process: Offset Lithography - 200 line-screen or 300 p.p.i. for digital Lamination: Clear laminate non-glare medium matte over laminate for abrasion, chemical, and ultra violet protection 2. Vendor Information (Or for Reference) Approved Vendor Vendor Part # Contact # Preferred Vendor OR BENDPAK ENGINEERING APPROVED EQUIVALENT...
Page 38 3” W x 3” H (76.2mm x 76.2mm) 1 Color-Black Material 2 Mil. Gloss Polyester Thermal Transfer Label With A High Performance Permanent Acrylic Adhesive. 2. Vendor Information (Or for Reference) Approved Vendor Vendor Part # Reference # Preferred Vendor OR BENDPAK ENGINEERING APPROVED EQUIVALENT...
Page 39 Material: White Adhesive Paper Ink: 1 Color-Black Print Process: Offset Lithography - 200 line screen or 300 p.p.i. for digital 2. Vendor Information (Or for Reference) Approved Vendor Vendor Part # Contact # Preferred Vendor OR BENDPAK ENGINEERING APPROVED EQUIVALENT...
Page 40: Warning Label
Lamination: Clear laminate Non-glare medium matte over- laminate (No Gloss) for abrasion, chemical, and ultra violet protection. 2. Vendor Information (Or for Reference) Approved Vendor Vendor Part # Contact # Preferred Vendor OR BENDPAK ENGINEERING APPROVED EQUIVALENT...
Page 41: Product Data Label
300 p.p.i. for digital Lamination: Clear laminate Non-glare medium matte over-laminate (No gloss) for abrasion, chemical, and ultra violet protection 2. Vendor Information (Or for Reference) Approved Vendor Vendor Part # Contact # Preferred Vendor OR BENDPAK ENGINEERING APPROVED EQUIVALENT...
Page 42 Ink: U.V. protected CMYK 2/C Process BendPak lifts are supplied with concrete fasteners meeting the criteria as prescribed by ASTM E488/ Finish: Matte Overlaminate (No Gloss) E488M-18. Lift buyers are responsible for any special regional, structural, and/or seismic anchoring requirements specified by any other agencies and/or codes such as the Uniform Building Code (UBC) and/or International Building Code (IBC).
Page 43 2-Post Lifts (ALI approved) Product Decal Positioning *Max. Cap. Danger ENG- *NRTL Lifting Cap ENG- DANGER ATTENTION FRE.pdf: FRE.pdf: Size: 4"W x 8.5"H Size: 4.5"W x 3.25"H THE MAXIMUM LIFTING CAPACITY MAXIMUM LIFTING CAPACITY FOR THIS LIFT IS DESCRIBED BELOW Material: White Vinyl Pressure CAPACITÉ...
Page 44 Certification Label Serial Number Size: 3"W x 1.75"H (Order Labels from ALI) PN 5905653 A L X X S A M P L E X X N Santa Paula, CA USA www.bendpak.com MODEL NUMBER DESCRIPTION LIFT CAPACITY DATE CODE VOLTAGE...
Page 45 2-Post Lifts (ALI approved) Product Decal Positioning Santa Paula, CA USA TO RAISE LIFT: TO LOWER LIFT: www.bendpak.com 1. Press and hold UP button. 1. Press and hold UP button for MODEL NUMBER two to three seconds, moving 2. When lift is just PAST desired lift off safety locks.
Page 46 Tous BendPak lifts are supplied with concrete fasteners meeting the criteria as prescribed by ASTM E488/ CENTER OF GRAVITY midway les véhicules DOIVENT être E488M-18. Lift buyers are responsible for any special regional, structural, and/or seismic anchoring requirements specified by any other agencies and/or codes such as the Uniform Building Code (UBC) between adapters.
