Summary of Contents for PowerPoint P65555MSFW
- Page 1 Smart Frost Fridge Freezer P65555MSFW INSTRUCTIONS: Please read and keep safe for future use. Serial No. You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)
-
Page 2: Table Of Contents
INSTALLATION AND USER INSTRUCTIONS Features………………………………………………………………………………………………….. 3 Transportation instructions................. 4 Introduction & safety warnings..............5 Electrical Requirements/Installation ………………… ........6 Food Storage …………………………………………………………………….…………………….. 7 Defrosting/Arrangement of Food ..............9 Temperature Control ………………………………………………………………………………..10 Cleaning and Care………………................ 11 Top Tips ……………..................12 Problem solving ................... 14 Technical data/Health &... -
Page 3: Features
Features Description Thermostat Refrigerator Glass Shelf Crisper Cover Crisper Frozen Upper Drawer Frozen drawer Adjusting foot Upper bottle frame Middle bottle frame Lower bottle frame You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com) - Page 4 Transportation of your Appliance When transporting, never tilt to more than 45 degrees The appliance should be transported only in a vertical upright position The packaging as supplied must be intact during transportation If during the course of transport the appliance has to be transported ...
- Page 5 Hold the base and lift the refrigerator carefully Never hold the door handle as support Never place the refrigerator upside down or lie it down Move refrigerator by using its two hind roller feet as an axis and then ...
-
Page 6: Electrical Requirements/Installation
Take care not to damage the cooling circuit, if damaged immediately ventilate the room where the appliance is situated This appliance should not be used in an unheated, cold room i.e. Garage, conservatory, annex, shed, out-house etc. Ensure that the plug remains readily accessible ... - Page 7 The frequency shown in the rating plate inside the appliance corresponds to Your electricity supply. We recommend that this appliance is connected to the mains supply via a suitable switched and fused socket in a readily accessible position. Should the mains lead of the appliance become damaged or should it need Replacing at any time, it must be replaced by a special purpose made mains Lead which can only be obtained from Shomar Ltd.
-
Page 8: Food Storage
10. To ensure that your appliance is level adjust the levelling feet at the front by turning them Before you start using the refrigerator check that: 1. The interior is dry and air can circulate freely at the rear of the cabinet. - Page 9 Pre-packed commercially frozen food should be stored in accordance with the frozen food manufacturer's instructions for a frozen food storage compartment To ensure that the high quality achieved by the frozen food manufacturer and the food retailer is maintained, the following should be observed: - Put packets in the freezer as quickly as possible after purchase.
- Page 10 After a period of time frost will build up in certain areas in the Freezer compartment. As a temporary measure, this frost should be scraped away using the plastic scraper included with the appliance. NEVER use a metal or sharp instrument. Complete defrosting will however become necessary approximately once per year, or if the frost layer exceeds 5mm to maintain the efficiency of the Fridge/Freezer.
-
Page 11: Temperature Control
3. Cooked dishes must be stored in airtight covered containers. 4. Fresh wrapped produce can be placed on the shelf. Fresh fruit and vegetables should be cleaned and stored in the crisper bins. 5. Bottles can be placed in the door section. 6. -
Page 12: Cleaning And Care
The temperature inside the refrigerator is controlled by a temperature gauge installed in the fridge freezer. The temperature inside the refrigerator varies depending on the opening and closing of the appliance doors, the ambient temperature of the room, and the location of the appliance. Under normal working conditions (spring and autumn), it is suggested that the gear should be set at 5 degrees in the middle gear. -
Page 13: Top Tips
If you are going away on holiday or for any other reason, wish to leave the refrigerator idle for any period of time, proceed as follows: Disconnect the refrigerator from the electric power supply by removing the plug from the wall socket Remove all food ... -
Page 14: Problem Solving
Don't consume food which has been stored for an excessive time in the fridge Don't leave the door open for long periods as this will make the appliance more costly to run and cause excessive ice formation Don't put hot food into the appliance ... - Page 15 Check the following: That the plug is inserted properly in the socket and that the power supply is on That the fuse has blown/circuit breaker has tripped/main distribution switch has been turned off That the temperature control has been set correctly ...
-
Page 16: Technical Data/Health & Safety
There may be too much food in the refrigerator, possible incorrect temperature selection Symptom: Smell inside the appliance. Cause: Some of the food is not properly wrapped or covered. The inside of the refrigerator needs cleaning; Liquids such as milk may have been spilled in the fridge. - Page 17 Health & Safety The use of any electrical appliance requires the following common sense safety rules. There is danger of injury or death and damage to the appliance. Location This appliance is intended to be used in household and residential ...
- Page 18 This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities Children Children should be supervised to ensure that they do not play with this appliance Teach children to be aware of dangers in the kitchen ...
-
Page 19: Disposal/Warranty Information
minimise damage to the environment. Before disposing of the appliance, cut off the power cable plug and remove the door to avoid accidents. Warranty Information. Registering Your 2 Year Guarantee Your standard one year guarantee is extended for an additional 1 year when you register the product within 28 days of purchase with the supplier Shomar Ltd. - Page 20 Contact Details The After Sales Division for PowerPoint Appliances is located at the offices of the Brand owner and Distributor – Shomar Ltd, Unit 9 Western Industrial Estate, Dublin 12, Republic Of Ireland.
- Page 21 To validate your 2 year guarantee register with us by visiting www.powerpointappliances.ie You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)
