Scanning Basics

1. Place film holder and
mammography film
Follow the section of the "Position
mammography Film" in this guide to place the
film holder and film properly on the scan bed.
2. Launch ScanWizard Medi
To launch ScanWizard Medi as a stand-alone
program, double-click the ScanWizard Medi
icon on your desktop.
All four windows (Preview, Settings, Scan Job
Queue and Information) appear automatically
after the ScanWizard Medi is started up at
the first time. You may hide the Scan Job
Queue and Information windows from the
View menu.
3. Specify scanning
requirements
a) In the Preview window, choose "X-Ray"
from the Scan Material menu.
b) In Settings window, select the appropriate
image output type (e.g., Gray Scale) in
the Type drop-down menu.
c) In Settings window, select a
desired image output
resolution (e.g., 600) in the
Resolution drop-down menu.
4. Scan mammography film
a) Click the Smart-Scan button on the
Preview window in the ScanWizard Medi
or the Scan button on the Medi-5000 unit.
b) When the "Scan To: Save As" dialog box
appears, specify the folder location, a file
name, and the format for the output
image, then click Save. The image is
scanned and saved to the specified
location.
5
