- Page 1 ZH 用户手册 / 组装说明 EN Instructions for use / Assembly instructions Ecos 14084007 Ecos 14086007 Logis E MySport 71602007 71262007 Logis E MySport 71403007 71242XX7...
- Page 2 中文 安全技巧 符号说明 装配时为避免挤压和切割受伤, 必须戴上手套. 请勿使用含有乙酸的硅胶! 冷热水管间过大的压力差必须予以平衡. 调节 (参见第页 6) 淋浴系统只允许作为洗浴, 卫生和洁身之用. 安装提示 热水温度调节. 如果使用即热式喷头, 则不建议安 装热水阀门. • 安装前必须检查产品是否受到运输损害. 安装后 将不认可运输损害或表面损伤. 大小 (参见第页 8) • 管道和阀门必须根据通用标准进行安装, 冲洗和 检查. 流量示意图 (参见第页 8) • 请遵守当地国家现行的安装规定. 备用零件 (参见第页 11) 技术参数 XX = 颜色代码 1 MPa 工作压强: 最大 00 = 镀铬 0,1 - 0,5 MPa 推荐工作压强: 67 = Matt Black 1,6 MPa 测试压强: 70 = Matt White (1 MPa = 10 bar = 147 PSI) 60°C 热水温度:...
-
Page 3: Installation Instructions
English The product is exclusively designed for drinking water! Safety Notes Symbol description Gloves should be worn during installation to prevent crushing and cutting injuries. Do not use silicone containing acetic acid! The hot and cold supplies must be of equal pressures. Adjustment (see page 6) The shower system may only be used for bathing, hygienic and body cleaning purposes. To adjust the hot water limiter. Using a hot water limiter in Installation Instructions combination with a continuous flow water heater is not recommended. • Prior to installation, inspect the product for transport damages. After it has been installed, no transport or Dimensions (see page 8) surface damage will be honoured. Flow diagram (see page 8) • The pipes and the fixture must be installed, flushed and tested as per the applicable standards. Spare parts (see page 11) • The plumbing codes applicable in the respective countries must be observed. XX = Colors Technical Data 00 = Chrome Plated 67 = Matt Black Operating pressure: max. 1 MPa... - Page 4 X + 36 mm 36 mm max. 39 mm max. 5 mm SW 24 mm...
- Page 5 SW 30 mm SW 22 mm (17 Nm) SW 22 mm (2 Nm) > 2 min...
- Page 6 60 °C 10 °C 0,3 MPa 36°C 38°C 50°C 60°C 43°C 55°C 17 x...
- Page 7 开 / open 关 / close 冷 / cold 热 / hot...
- Page 8 MySport 71242XX7 15 0 ± 12 15 - 2 3 G 1 / 2 2 21 2 0 5 MySport 71262007 15 - 2 3 15 0 ± 12 G 1 / 2 18 4 2 21 13 5 16 4 MySport 71242XX7 MySport 71262007 0,60...
- Page 9 Ecos 14084007 Ecos 14086007 Ecos 14084007 Ecos 14086007 0,60 0,55 0,50 0,45 0,40 0,35 0,30 0,25 0,20 0,15 0,10 0,05 0,00 Q = l/min 9 12 15 18 21 24 27 30 Q = l/sec...
- Page 10 Logis E 71403007 15 - 23 G 1 / 2 Logis E 71602007 15 - 23 G1/2 Logis E 71403007 Logis E 71602007 0,60 0,55 0,50 0,45 0,40 0,35 0,30 0,25 0,20 0,15 0,10 0,05 0,00 9 12 15 18 21 24 27 30 Q = l/min Q = l/sec...
- Page 11 MySport 71242XX7 92374XX0 96338000 (71242007 97406XX0 71242707) 96338610 98193000 (71242677) (32x2) 97977XX0 98464000 94140000 (40x1,5) 92730000 95140000 97981XX0 96157XX0 97979XX0 95008000 94135XX0 97220000 98163000 MySport (15x2) 71262007 92360XX0 94140000 97978000 96157000 92730000 94135000 97220000 98464000 98163000 (40x1,5) 98129000 (15x2) 98193000 (14x2) 95008000 (32x2)
- Page 12 Ecos 95518000 14084007 97406000 96338000 98193000 97977000 (32x2) 98164000 (33x1,5) 92730000 94140000 95140000 95008000 97981000 97979000 98163000 (15x2) 94135000 97220000 96157000 97978000 92360000 Ecos 14086007 94140000 98163000 (15x2) 92730000 94135000 97220000 98193000 96157000 96044000 (32x2) 97406000 95140000 97209000 95518000 96338000...
- Page 13 Logis E 93024000 71403007 96338000 97406000 98193000 97977000 (32x2) SW 30 mm 98164000 (33x1,5) 94140000 SW 24 mm 95140000 92730000 (M4x20) SW 4 mm 95008000 98163000 97981000 (15x2) 97979000 96157000 SW 30 mm 94135000 Logis E 97220000 96512000 71602007 (M24x1 - 97978000 30 l/min) 94140000 SW 19 mm SW 22 mm SW 24 mm 98163000 (15x2) 96157000 SW 30 mm 92730000...
