OVE INTELLIGENT TOILET
Model 735H
Thank you for choosing OVE INTELLIGENT TOILET. Please read and understand this entire
manual before attempting to assemble, operate or install this product.
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 735H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for OVE 735H

  • Page 1 OVE INTELLIGENT TOILET Model 735H USER MANUAL Thank you for choosing OVE INTELLIGENT TOILET. Please read and understand this entire manual before attempting to assemble, operate or install this product.
  • Page 2: Table Of Contents

    CONTENTS SAFETY NOTICE ..........01-02 PART LIST .............03 INSTALLATION INSTRUCTIONS ......04 CONTROLS DESCRIPTION ........05 USAGE INSTRUCTIONS ........06-08 CAUTION NOTES ..........09 CLEANING THE FILTER NET .......10 DAILY MAINTENANCE ..........11 STORAGE GUIDELINES ........12 SPECIAL MAINTENANCE ........13 COMMON TROUBLESHOOTING ......14 TECHNICAL SPECIFICATIONS ......15 1 YEAR WARRANTY ..........16 CONTACT US ............17...
  • Page 3: Safety Notice

    SAFETY NOTICE ADMONITION Leading causes of electric shock and fire. ■ Inside the product there is an electronic apparatus installed, please do not use it in wet place. Please keep the electronics and electric plug away from water. Preventing sanitation issues ■...
  • Page 4 SAFETY NOTICE USAGE GUIDELINES PLEASE FOLLOW THE FOLLOWING GUIDELINES To prevent against Do not leave the toilet power surge damages, exposed to the sun. make sure the ground is Color fading and working in the power yellowing may result. socket. Radio or transmitting If you do not plan to use the toilet devices may interfere...
  • Page 5: Part List

    PART LIST Inlet Valve STOP SPRAY MOVE BIDET MOVE DRYING FLUSHING WATER PRESSURE WATER TEMPERATURE NOZZLE FORWARD AIR PUMP AIR TEMPERATURE NOZZLE BACKWARD WATER PRESSURE SEAT TEMPERATURE NOZZLE WASHING Deodorization Clockwise—turn down outlet Anti-clockwise—turn up Power socket Seat sensor Inlet Valve Silicone sealer PART#...
  • Page 6: Installation Instructions

    INSTALLATION INSTRUCTIONS INSTALLING THE SMART TOILET WATER AND ELECTRIC SUPPLY INSTALLATION Open inlet valve. Put the plug into the power socket If the blue light is flashing, this indicates that the washing water tank is filling-up. After 2 min, the tank should be full. *While the tank is filling, the user cannot ENERGY SAVER POWER...
  • Page 7: Controls Description

    CONTROLS DESCRIPTION Bidet cleaning display Drying display Spray cleaning display Self-flushing display Nozzle move forward Water temperature display ● 4 levels: ambiant, low, middle and high level. Nozzle move behind Wind temperature level display ● 4 levels: ambiant, low, middle and high level.
  • Page 8: Usage Instructions

    USAGE INSTRUCTIONS KEYPAD CONTROLS ON/OFF Press this button to turn the smart toilet ON and OFF. ENERGY SAVER POWER NOZZLE WASHING LIGHT ENERGY SAVER When ON, the energy saving mode will BIDET MOVE decrease the electrical usage of the smart toilet when in stand-by.
  • Page 9 USAGE INSTRUCTIONS ● All the settings from last usage are kept in memory for the next use. The remote control display will turn off automatically. To wake it up, press any button 1 time. Bidet cleaning display Drying display Spray cleaing display Self-flushing display Nozzle move forward Water temperature display...
  • Page 10 USAGE INSTRUCTIONS Automatic deodorization The carbon filter catalyzed automatic deodoriza- tion begins when the user sits on the seat. The Deodorizing deodorization stops after 20 second of standing In addition the toilet seat is covered with a layer of active anti-microbial material. Anti microbial Damp fitting...
  • Page 11: Caution Notes

    CAUTION NOTES ● If no one is sitting on the seat, the ● Once the nozzle cleaning session is water cleaning and drying function are over, the nozzles will self-clean every disabled. time. Sitting sensor in the toilet seat *Do not lean back on the seat cover once you are seated.
  • Page 12: Cleaning The Filter Net

    CLEANING THE FILTER NET Cleaning the filter net ● When you notice a decrease in water pressure in the washing nozzles, clean the filter net and/or change the filter. Always make sure the tap water pressure complies with this toilet’s requirements. How to clean the filter net 1.
  • Page 13: Daily Maintenance

    DAILY MAINTENANCE TOILET MAINTENANCE GUIDELINES The toilet's seat is made of plastic. Please following the below guidelines to prevent damages. Clean with warm water and a soft deter- gent. Never use abrasive materials of chemi- cals. Avoid spilling water on top of the electron- ic components behind the seat cover.
  • Page 14: Storage Guidelines

    STORAGE GUIDELINES Never use below freezing ● Always keep the toilet in an environment above 5 C to prevent water freezing and damaging the inner pluming. Extended periods of no usage ● If the toilet is not used for an extended period of time, the water should be drained from the toilet's bowl and the washing water tank.
  • Page 15: Special Maintenance

    SPECIAL MAINTENANCE Pulling out the nozzles for manual washing User may pull out the nozzle to wash it by hand 1. Nozzle manual cleaning ※ While no one is sitting on the ENERGY SAVER POWER seat: Open seat cover, press Nozzle Washin key.
  • Page 16: Common Troubleshooting

    COMMON TROUBLESHOOTING MALFUNCTION AND POTENTIAL ROOT CAUSES Problem Solution Cause Nozzle pulls out but no water Press nozzle or bidet cleaning Press nozzle clean key by mistake Inlet hose twisted leads to jam Get rid of the hose twisted Cleaning water don't spurt out Tap water no pressure Confirm tap water have pressure Wash the spout...
  • Page 17: Technical Specifications

    TECHNICAL SPECIFICATIONS Technical Specifications Item Content AC 120V. 1300W. 60HZ Specification 1.2m insulated power cord Nozzle cleaning Water amount adjustment 0.4-1.0 L/min (water pressure 0.19Mpa (27.6 psi)) Water amount Water amount adjustment 0.5-1.0 L/min (water pressure 0.19Mpa (27.6 psi)) Bidet cleaning Water temperature Temperature adjustment : from ambiant temperature to 40℃...
  • Page 18: Year Warranty

    1 YEAR WARRANTY LIMITED 1 YEAR WARRANTY The DISTRIBUTOR warranty is valid for a period of 1 year after purchased. Improper use of this product or any deviations to the general guidance given in the user manual will void the warranty. This non-transferable warranty applies only to the original purchaser and proof of purchase is required for all claims.
  • Page 19: Contact Us

    CONTACT US Save this manual for future reference Conservez ce manuel pour usage ultérieur Conserve este manual para futura referencia HEAD OFFICE / SIÈGE SOCIAL / OFICINA PRINCIPAL 2800 Etienne Lenoir, Laval Quebec H7R 0A3 Canada Customer service / Service à la clientèle / Service al cliente Tel.: 1-866-839-2888 Fax: 1-866-922-9990 customerservice@ovedecors.com...
