This section tells you how to make the physical connections to your Netopia 3381-ENT Cable/DSL Router. This
section covers the following topics:
• "Find a Location" on page 2-1
• "What You Need" on page 2-1
•
"Identify the Connectors and Attach the Cables" on page 2-3
•
"Netopia 3381-ENT Cable/DSL Router Status Lights" on page 2-6

Find a Location

When choosing a location for the Netopia Cable/DSL Router, consider:
• Available space and ease of installation
•
Physical layout of the building and how to best use the physical space available for connecting your Netopia
Cable/DSL Router to the LAN
• Available wiring and jacks
•
Distance from the point of installation to the next device (length of cable or wall wiring)
•
Ease of access to the front of the unit for configuration and monitoring
•
Ease of access to the back of the unit for checking and changing cables
•
Cable length and network size limitations when expanding networks
For small networks, install the Netopia 3381-ENT near one of the LANs. For large networks, you can install the
Netopia 3381-ENT in a wiring closet or a central network administration site.

What You Need

Locate all items that you need for the installation.
Included in your router package are:
•
The Netopia 3381-ENT Cable/DSL Router
•
A power adapter and cord
•
One Category 5 Ethernet cable
•
One USB cable
•
One RJ-45 Modem cable
Making the Physical Connections 2-1
