7.7 Auto Scroll Display in Default Mode

The meter's operating mode can be changed to default mode remotely (or locally if the rule permits). This mode
operates in credit mode with only total cumulative active import and export kWh registers.
The default display will show pertinent information relating to the meter's default mode of operation. For each
display the timeout is two (2) seconds. The following display cycle is configured by default when the meter is
operating in 'Default' mode. These can be configured as per energy retailer's requirement.
Operating Mode:
Title: Cumulative import active rate register
Followed by value
Title: Cumulative export active rate register
BGX501-767-R02
Or
(timeout 4 secs) Or
(timeout 20 secs)

Table 26: UTRN entry from Prepayment mode

Figure 20: Auto scroll display cycle in Default mode

This is the 1
operating in 'Default' mode.
Followed by
nd
The 2
import active rate register since manufacture.
In the example display the title 'Import kWh' is followed by
15.6 kWh which is the cumulative consumption value in
import active rate register.
Followed by
rd
The 3
export active rate register since manufacture. This display set
will not be displayed for import only meters.
Liberty 100 Smart Electricity Meter Technical Reference Manual
'Incorrect' indicates UTRN is rejected because it is a
wrong UTRN.
'Incomplete' indicates UTRN is rejected because it is
not in multiples of 20-digit.
The display 'Key Locked' indicates that the user has
entered five (5) consecutive invalid UTRN and this
locks key 'A' for the configured timeout period.
st
display indicating the meter is currently
set displays the cumulative energy value recorded in
set displays the cumulative energy value recorded in
