Table 25: Key '0' Display In Prepayment Mode - Secure Liberty 100 Technical Reference Manual

Press key 0 to advance to the next display.
Title 10: Last month's CO
Followed by value
Press key 0 to advance to the next display.
Title 11: Refund code
Followed by value
Press key 0 to return to the 1
Press key B to scroll back up the display list.
No key press at the end of this display sequence will
cause the auto-cycle display to resume.
BGX501-767-R02
(timeout 4 secs)
emission data
2
(timeout 2 secs)
(timeout 4 secs)
(timeout 2 secs)
(timeout 4 secs)
st
display.

Table 25: Key '0' display in Prepayment mode

Liberty 100 Smart Electricity Meter Technical Reference Manual
th
The 10 set displays last month's CO
The example shows that 0.5 kg was last month's
CO emission.
2
th
The 11 set displays the refund code if present.
20-digit UTRN
The UTRN is displayed in blocks of five digits. The
first character indicates the block of the code (A, B,
C, and D). The start of a code is indicated by a '<'
and the end by a '>'. A '-' is inserted after each block
as a separator. Each subsequent press of button '0'
will display the next block of code till all have been
displayed.
emission data.
2
Page 87 of 116
