Followed by value
Press key 3 to return to the 1
Press key B to scroll back up the display list.
No key press at the end of this display sequence will
cause the auto-cycle display to resume.
Key 4: Historical monthly consumption data
A short press of key '4' will initiate the associated display sequence. After each set of information comprising a
title followed by its data, either a four (4) seconds wait or short press of the key will advance the display to the
next set of information as described below.
The display will scroll forward through tweleve (12) months historical consumption data starting with the last
month which is the same as the 'LAST MONTH' in the above Key 3 sequence. For example, if the current
month is 'August' the last month will be 'July' so the data sequence will begin from 'July' and end with 'August'.
Title 1: Historical monthly consumption data
Press key 4 to advance to the next display
Title 2: Last month's consumption and its cost
Followed by value
Followed by value
Press key 4 to advance to the next display
Page 74 of 116 Liberty 100 Smart Electricity Meter Technical Reference Manual
(timeout 4 secs)
st
display.

Table 18: Key '3' display in Prepayment mode

The 1
the key is assigned to display historical monthly
consumption for the past twelve (12) months.
(timeout 2 secs)
The 2
The example shows that 15.6 kWh was used last
month and its associated cost was £11.78.
(timeout 2 secs)
(timeout 4 secs)
(timeout 4 secs)
st
display associated with key 4 indicating that
nd
set displays last month's consumption.
