Table 17: Key '2' Display In Prepayment Mode - Secure Liberty 100 Technical Reference Manual

Press key 2 to advance to the next display
Title 2: Previous week's cost
Followed by value
Press key 2 to return to the 1
Press key B to scroll back up the display list.
No key press at the end of this display sequence will
cause the auto-cycle display to resume.
Key 3: Current month and previous month's cost of consumption
A short press of key '3' will initiate the associated display sequence. After each set of information comprising a
title followed by its data, either a four (4) seconds wait or short press of the key will advance the display to the
next set of information as described below.
Title 1: Current month's cost
Followed by value
Press key 3 to advance to the next display
Title 2: Previous month's cost
BGX501-767-R02
(timeout 4 secs)
(timeout 2 secs)
(timeout 4 secs)
st
display.

Table 17: Key '2' display in Prepayment mode

(timeout 2 secs)
(timeout 4 secs)
(timeout 2 secs)
Liberty 100 Smart Electricity Meter Technical Reference Manual
nd
The 2 set displays the cost of electricity used in the
previous week.
The example shows that £11.78 was the cost of
electricity used.
st
The 1 set of displays associated with key 3
indicating the cost of electricity used since the 1
the current month.
The example shows that £11.78 was the cost of
electricity used.
nd
set displays the cost of electricity used in the
The 2
previous month.
The example shows that £11.78 was the cost of
electricity used.
st
of
Page 73 of 116
