Secure Liberty 100 Technical Reference Manual page 65

Followed by value
Press key 0 to advance to the next display.
Title 3: Current date
Followed by value
Press key 0 to advance to the next display.
Title 4: Current load
Followed by value
Press key 0 to advance to the next display.
Title 5: CO emission data
2
BGX501-767-R02
(timeout 2 secs)
(timeout 4 secs)
(timeout 2 secs)
(timeout 4 secs)
(timeout 2 secs)
Or
Or
Or
(timeout 4 secs)
Liberty 100 Smart Electricity Meter Technical Reference Manual
rd
The 3 set displays current date.
In the example the date in the meter is 1st June
2012.
th
The 4 set displays the current load and its status.
The examples indicate the following:
The current load 10.15 kW is in-between the low and
high active import power thresholds.
The current load 2.15 kW is below the low active
import power threshold.
The current load 22.15 kW is above the high active
import power threshold.
24.10 kW is the power currently being exported.
th
The 5 set initiates CO emission data display.
2
