Table 12: Key '9' Display In Credit Mode - Secure Liberty 100 Technical Reference Manual

Title 5: Import register test display
Followed by value
Press key 9 to advance to the next display
Title 6: Export register test display
Followed by value
Press key 9 to return to the 1
Press key B to scroll back up the display list.
No key press at the end of this display sequence will
cause the auto-cycle display to resume.
Key 0: Display check, Time, Date, Load and Carbon emission data
A short press of key '0' will initiate the associated display sequence. After each set of information comprising a
title followed by its data, either a four (4) seconds wait or short press of the key will advance the display to the
next set of information as described below.
Test Display:
Press key 0 to advance to the next display.
Title 2: Current time
Page 64 of 116 Liberty 100 Smart Electricity Meter Technical Reference Manual
The 5
test display.
The example shows that 2456.228 kWh have been
(timeout 2 secs)
recorded.
(timeout 4 secs)
The 6
test display.
The example shows that 2456.228 kWh have been
(timeout 2 secs)
recorded.
(timeout 4 secs)
st
display.

Table 12: Key '9' display in Credit mode

The 1
display.
(timeout 2 secs)
The 2
In the example the time in the meter is 00:32:10.
th
set displays high resolution import register
th
set displays high resolution export register
st
display associated with key 0 shows the test
nd
set displays the current time in the meter.
