Secure Liberty 100 Technical Reference Manual page 108

Key 9: UTRN history
Title 1: Number of accepted UTRNs
Followed by value
Press key 9 to advance to the next display.
Title 2: Number of rejected UTRNs
Followed by value
Press key 9 to advance to the next display.
Title 3: Vend UTRN Details
Followed by Subtitle: Vend 1 transaction
Followed by vend amount
Followed by vend date
Followed by vend time
Page 108 of 116 Liberty 100 Smart Electricity Meter Technical Reference Manual
The 1
the number of UTRNs accepted.
The example shows that the meter has accepted 16
(timeout 2 secs)
UTRNs since manufacture.
(timeout 4 secs)
The 2
The example shows that the meter has rejected 16
UTRNs since manufacture.
(timeout 2 secs)
(timeout 4 secs)
The 3
UTRNs. If there are vend UTRNs then it shows the
vend UTRN transaction details such as vend amount,
vend date, vending time and the UTRN number. The
Or
list displays the last five (5) historical UTRN details.
The example shows the following displays:
(timeout 2 secs)
Vend 1 Meter Transaction is the latest vend UTRN.
(timeout 2 secs)
£11.78 is the vend amount.
(timeout 2 secs)
02/03/2014 is vend input date.
(timeout 2 secs)
00:32:10 is vend input time.
st
set of displays associated with key 9 displays
nd
set displays the number of UTRNs rejected.
rd
set displays 'No UTRN' if there are no vend
BGX501-767-R02
