OPERATING MANUAL
FENDT
916 Vario
920 Vario
924 Vario
926 Vario
930 Vario
930.000.000.014 Englisch

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 916 Vario and is the answer not in the manual?

Questions and answers

Related Manuals for FENDT 916 Vario

Summary of Contents for FENDT 916 Vario

  • Page 1 OPERATING MANUAL FENDT 916 Vario 920 Vario 924 Vario 926 Vario 930 Vario 930.000.000.014 Englisch...
  • Page 2 OPERATING MANUAL FENDT 916 Vario From chassis number 916 .. 7001 FENDT 920 Vario From chassis number 920 .. 7001 FENDT 924 Vario From chassis number 924 .. 7001 FENDT 926 Vario From chassis number 926 .. 7001 FENDT 930 Vario From chassis number 930 ..

  • Page 3: Authorised Use

    If this Manual is lost or damaged and you need a Any other type of use is considered unauthori- new one, please contact your Fendt dealer, sed. The manufacturer will not be liable for any There you will be able to purchase a replace- damage resulting from such uses, which will be ment.
  • Page 4 NUMERICAL INDEX SAFETY INSTRUCTIONS....9 Cruise control..........44 OPERATION........14 Load limit control........46 Driver seat ..........14 7.10 Storing engine speeds .......47 7.11 Towing instructions ........48 Super deluxe seat ........14 Display instruments and operating Fuel consumption measurement....48 controls.............15 Activating fuel consumption measurement..........48 Front controls ..........15 Glow and starter switch......16 Tractor Management System (TMS)..49 Combination switch........16...
  • Page 5 NUMERICAL INDEX Implement control........120 18.7 Electronic power lift control / double action operation (EPC/DA)........84 29.1 Assigning control terminal......120 18.8 Implement socket........85 29.2 Loading the implement software for implement control ........122 Three-point link ........85 29.3 Setting up the control terminal for 19.1 Lower links ..........85 implement control ........123...
  • Page 6 NUMERICAL INDEX Front PTO ..........149 IMPLEMENTS .......204 Transmission and axle drives....149 Reversing device ........204 10.1 Changing the transmission oil....149 10.2 Checking the transmission oil level..150 10.3 Changing the oil in the axle drives ...151 FAULTS AND REMEDIAL Four-wheel drive axle ......151 ACTIONS........205 11.1 Changing the oil in the front axle...

  • Page 7: Safety Instructions

    SAFETY INSTRUCTIONS Safety and accident prevention regulations WARNING: Before every operation, check the tractor for road worthiness and operational safety. Carefully read the Manual and observe all safety instructions. Safety signs on the machine must be replaced if damaged or lost. General safety and accident Driving the tractor prevention regulations...

  • Page 8: Leaving The Tractor

    Switch off the engine and apply the ballasting at the rear. For additional loading, hand brake! we recommend attaching the Fendt 870 kg additional weight at the three-point link - fit 2. Remove the ignition key and lock the cab if wheel weights and fill the tyres if necessary.

  • Page 9: Maintenance

    SAFETY INSTRUCTIONS Maintenance Advice for front loader maintenance: Text-module 1. Before undertaking maintenance work, lower 1. Before maintenance and repair work, switch Text-module the front loader to the ground, switch off the off the engine and remove the ignition key. engine and remove the ignition key.

  • Page 10: Location Of Safety Signs

    SAFETY INSTRUCTIONS Location of safety signs Operation_Pic_number:1 Operation_Pic_number:1 Fig.4 On the left and right rear mudguards beside the lifting gear control. Operation_Pic_number:1 Fig.1 Inside the cab on the right. Operation_Pic_number:1 Fig.2 Fig.5 Inside the cab on the right. At left front of hydraulic cylinder of front axle Operation_Pic_number:1 suspension.
  • Page 11 SAFETY INSTRUCTIONS Operation_Pic_number:1 Fig.7 Inside the cab on left. Operation_Pic_number:1 Fig.8 Inside the cab, on the cover of the emergency operation controls. Operation_Pic_number:1 Fig.9 On the front loader forks, left and right. Operation_Pic_number:1 Fig.10 Inside the cab, on the left, on the transverse beam of the front windscreen.

  • Page 12: Operation

    OPERATION 1. Driver seat WARNING: Never adjust the seat while the tractor is moving (risk of accident). If a seat belt is available, always attach it. 1.1 Super deluxe seat Operation_Pic_number:1 Fig.1 Text-module = Automatic weight and height adjust- ment. = Swivel mechanism.

  • Page 13: Front Controls

    OPERATION 2. Display instruments and operating controls 2.1 Front controls Operation_Pic_number:1 Fig.2 Text-module = Hand brake = Clutch pedal = Steering wheel adjustment and quick reverse. = Heater and fan controls (see also OPERATION Section 3). = Combination switch = Heater starter switch = Multi-function armrest = Accelerator pedal = Brake pedals...

  • Page 14: Steering Wheel Adjustment

    OPERATION 2.2 Glow and starter switch 2.4 Steering wheel adjustment Operation_Pic_number:1 WARNING: Never adjust the steering wheel while the tractor is moving! Operation_Pic_number:1 Fig.3 Text-module = Ignition off, key can be removed. = General ignition, key cannot be removed + preheating (automatic). = Starting + ignition.
  • Page 15 OPERATION 2.6 Dashboard Operation_Pic_number:1 Fig.7 Text-module = Multiple display = Key pad for rpm indicators (also see OPERATION Section 2.8). = Indication of fluid levels = Key pad for speed display (also see = Operating status display OPERATION Section 2.8). = Indicator lamps = Emergency mode (also see FAULTS = Lights including side lights...
