- Page 1 VLSP-22H21 2x2 HDMI 2.1 Splitter VER 1.0...
- Page 2 Thank you for purchasing this product Please read these instructions carefully for optimum performance and safety before connecting, operating, or adjusting this product. Please keep this manual for future reference. A surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shocks, lightning strikes, etc.
- Page 3 1. Introduction This 8K Two-Input Dual View HDMI Splitter can not only switch any of the two HDMI input signals but also distribute it to two displays simultaneously. It supports video resolution up to 8K@60Hz 4:2:0. As able to be used either as a splitter or a switcher, this multi-functional product can be widely applied in scenarios of demonstration, video conference, multimedia teaching, and other occasions requiring big-screen demonstration.
- Page 4 4. Specifications Technical HDMI Compliance HDMI 2.1 HDCP Compliance HDCP 2.3 Video Bandwidth 40Gbps Up to 8K@60Hz YCBCR 4:2:0 10bit, 8K30 RGB/ Video Resolution YCBCR 4:4:4 10bit or,4K120 RGB/YCBCR 4:4:4 10bit Color Depth 8-bit,10-bit,12-bit Color Space RGB, YCbCr 4:4:4 / 4:2:2. YCbCr 4:2:0 LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master HDMI Audio Formats...
- Page 5 5. Operation Controls and Functions Front Panel Rear Panel Name Function Description POWER LED When the device is powered on, the red LED will be on. When the HDMI IN 1/2 port connects to an active IN LED source device, the corresponding green LED will (1~2) be on.
- Page 6 Note: When the device is powered on, it will start to work. Both OUT1 and OUT2 default to output the source signal from the IN1 port. The device supports memory function in case of power-down. AUTO SWITCH: When there is no input signal, empty switching is allowed; when there is an input signal detected, the device will switch to the latest source signal automatically.
- Page 7 6. Application Example The terms HDMI and HDMI High-Definition Multimedia interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
