Propane Rotisserie/Oven
Instructions for use
© 2006 The Coleman Company, Inc.
www.coleman.com
9987 Series
This unit is an accessory for Coleman®
Propane Grill Models 9993 and 9998. Also read
the additional instructions and warnings that are
provided in the manual that came with your
Coleman® Grill.
CONSUMER/USER: This instruction manual
contains important information necessary for the
proper assembly and safe use of the appliance.
Read and follow all warnings and instructions before
assembling and using the appliance. Follow all
warnings and instructions when using the appliance.
Keep this manual for future reference.
If you have questions about assembly, operation, servicing or repair of this
appliance, please call Coleman at 1-800-835-3278 or TDD: 316-832-8707. In
Canada call 1-800-387-6161.
INSTASTART™ Electronic Ignition
ANSI Z21.58a-2006/CSA 1.6a-2006
Outdoor Cooking Gas Appliances
IMPORTANT
®
Advertisement
Table of Contents
Related Manuals for Coleman 9987 Series
Summary of Contents for Coleman 9987 Series
- Page 1 Keep this manual for future reference. If you have questions about assembly, operation, servicing or repair of this appliance, please call Coleman at 1-800-835-3278 or TDD: 316-832-8707. In Canada call 1-800-387-6161. INSTASTART™ Electronic Ignition ®...
- Page 2 If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. Open lid. 4. If odor continues, keep away from the appliance and immediately call your gas supplier or your fire department. Failure to follow these instructions could result in fire or explosion which could cause property damage, personal injury or death.
-
Page 3: Carbon Monoxide Hazard
Only persons who can understand and follow the instructions should use or service this outdoor rotisserie. If you need assistance or outdoor rotisserie information such as an instruction manual or labels, contact The Coleman Company, Inc. DANGER CARBON MONOXIDE HAZARD • This appliance can... -
Page 4: Explosion - Fire Hazard
Your local authorities can advise you about these. • This rotisserie is designed as an accessory for Coleman® Grill models 9993 and 9998. The fuel is regulated through the preset regulator that came with your grill. Do not attempt to adjust. - Page 5 Electrical Attachments The maximum sum total amperage rating of electrical accessories attached to the 9993 or 9998 Series Coleman Grills must not exceed 10 amps. When using an electric attachment with the grill, follow the specification and warning statements accompanying the attachment.
-
Page 6: Technical Characteristics
Technical Characteristics Input: 6,000 BTU/H Category: Pressure regulated propane. Fuel: Uses fuel system on Coleman® grill models 9993 and 9998. Regulator: Uses regulator on Coleman® grill models 9993 and 9998. Ignition: Piezo electronic ignition. Rotisserie Motor: 120V-60HZ, 4 Watts, .033 Amps. -
Page 7: Rotisserie Assembly
Grill NOTE: This Side Solution™ Rotisserie attachment is designed for use only when properly attached to Coleman® grill models 9993 and 9998. Attempted use or setup in a manner not described in this manual is prohibited and will void the warranty. - Page 8 (Fig. 11). Fig. 7 Rotisserie Setup NOTE: To use the rotisserie, the wire oven rack must be removed and set aside. 2. Assemble the meat forks and the collar onto the spit rod (Fig. 12). Adjust the location of the collar with the thumbscrew to support the spit Fig.
-
Page 9: Leak Testing
4. Figure 14 illustrates the spit rod correctly installed. Oven Setup 1. To use the unit as an oven, slide the wire oven rack into the rails (Fig. 15). NOTE: The wire oven rack must be installed correctly. The correct installation is with the lowest side of the heat deflector near the burner. -
Page 10: Operation
Leak Testing CAUTION Inspect the gas supply hose before each use. Look underneath the grill to inspect the hose assembly below the grill. If there are cuts, damage, excessive abrasion or wear, replace the hose prior to operating the appliance. During assembly of the grill and when attaching or replacing the L.P. - Page 11 Rotisserie Burner Lighting INSTASTART™ Electronic Ignition Rotisserie: 1. Open the lid. 2. Make sure all valves are OFF. 3. Turn on the cylinder valve. 4. Push in and turn on the Rotisserie Control Knob counterclockwise to HIGH, then repeatedly press the igniter switch until the flame ignites (Fig 19).
-
Page 12: To Turn Off
■ A good flame should be blue with minimal yellow tip. Some yellow tips on flames are acceptable as long as no carbon or soot deposits appear (Fig. 23). Yellow Blue Yellow Holes in Burner NOTE: If the burner flame is accidentally extinguished, turn off the control knob and wait 5 minutes before relighting the appliance. -
Page 13: Care, Maintenance And Cleaning
If your unit shows indications of insect webs or nests, contact your nearest service center or call Coleman for assistance. Figure 26 shows the areas for a service center to inspect. NOTE: Water or air pressure will not normally clear a spider web. -
Page 14: Parts List
Part Number 9987-5031 “Please Call” Window Assembly 9987-5151 Burner Assembly 9987-2521 Parts List Description Lid Assembly Grease Tray English-13 Part Number Description 9987-5061 Spit Rod w/ Forks 9987-5111 Igniter Assembly 9986-5181 Knob Assembly 9987-2511 Motor Assembly 9987-5131 Wire Oven Rack... -
Page 15: Warranty
Coleman, at its option, will repair or replace this product or any component of the product found to be defective during the warranty period. - Page 16 The Coleman Company, Inc. • 3600 North Hydraulic • Wichita, KS 67219 U.S.A. 1-800-835-3278 • TDD: 316-832-8707 © 2006 The Coleman Company, Inc. All rights reserved. Coleman® and are registered trademarks and INSTASTART™ is a trademark of The Coleman Company, Inc.
